DV-535
DV-530
Operating Instructions
Istruzioni per l'uso
DVD PLAYER
LETTORE PER DVD
background image
DV-535
DV-530
Operating Instructions
Istruzioni per l'uso
DVD PLAYER
LETTORE PER DVD
background image
En/It
CAUTION
This product contains a laser diode of higher class
than 1. To ensure continued safety, do not remove
any covers or attempt to gain access to the inside of
the product.
Refer all servicing to qualified personnel.
The following caution label appear on your player.
Location: On the rear panel of the player
On the bonnet of the player
This product complies with the Low Voltage Directive
(73/23/EEC), EMC Directives (89/336/EEC, 92/31/
EEC) and CE Marking Directive (93/68/EEC).
WARNING: TO PREVENT FIRE OR SHOCK HAZARD,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
CAUTION :
VORSICHT :
ADVARSEL :
VARNING :
VARO!
:
VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN.
AVOID EXPOSURE TO BEAM.
SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG, WENN
ABDECKUNG GEÖFFNET NICHT DEM STRAHL AUSSETZEN!
SYNLIG OG USYNLIG LASERSTRÅLING VED ÅBNING
UNDGÅ UDSÆTTELSE FOR STRÀLING.
SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA
DEL ÄR ÖPPNAD BETRAKTA EJ STRÅLEN.
AVATTAESSA ALTISTUT NÄKYVÄ JA NÄKYMÄTTÖMÄLLE
LASERSATEIL YLLE. ÄLÄ KATSO SÄTEESEN.
VRW1699
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
IMPORTANT
CAUTION:
TO PREVENT THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER-
SERVICEABLE
PARTS
INSIDE.
REFER
SERVICING
TO
QUALIFIED
SERVICE
PERSONNEL.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
IMPORTANT
FOR USE IN THE UNITED
KINGDOM
The wires in this mains lead are coloured in
accordance with the following code :
Blue
:Neutral
Brown
:Live
If the plug provided is unsuitable for your
socket outlets, the plug must be cut off and a
suitable plug fitted.
The cut-off plug should be disposed of and must not be
inserted into any 13 amp socket as this can result in
electric shock. The plug or adaptor or the distribution
panel should be provided with 5 amp fuse. As the
colours of the wires in the mains lead of this appliance
may not correspond with coloured markings identifying
the terminals in your plug, proceed as follows :
The wire which is coloured blue must be connected to
the terminal which is marked with the letter N or
coloured black.
The wire which is coloured brown must be connected
to the terminal which is marked with the letter L or
coloured red.
Do not connect either wire to the earth terminal of
a three pin plug.
NOTE
After replacing or changing a fuse, the fuse cover in
the plug must be replaced with a fuse cover which
corresponds to the colour of the insert in the base
of the plug or the word that is embossed on the
base of the plug, and the appliance must not be
used without a fuse cover. If lost, replacement fuse
covers can be obtained from your dealer.
This appliance is rated at 13 amps.
Only 5 amp fuses approved to B.S.
1362 A.S.T.A. should be used.
PRECAUZIONE
Questo prodotto contiene un diodo al laser di classe
superiore alla classe 1. Per motivi di sicurezza, non
smontare i coperchi e non procedere ad interventi
sulle parti interne.
Per qualsiasi riparazione rivolgersi a personale
qualificato.
La nota seguente si trova.
Ubicazione: Sul pannello posteriore del lettore
Sul coperchio dell'apparecchio
Questo prodotto è conforme alla direttiva sul basso
voltaggio (73/23/CEE), alle direttive EMC (89/336/
CEE, 92/31/CEE) e alla direttiva sul marchio CE (93/
68/CEE).
AVVERTENZA: PER EVITARE IL RISCHIO DI FIAMME
O SCOSSE ELETTRICHE, NON ESPORRE QUESTO
APPARECCHIO ALLA PIOGGIA O ALL 'UMIDITA'.
CAUTION :
VORSICHT :
ADVARSEL :
VARNING :
VARO!
:
VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN.
AVOID EXPOSURE TO BEAM.
SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG, WENN
ABDECKUNG GEÖFFNET NICHT DEM STRAHL AUSSETZEN!
SYNLIG OG USYNLIG LASERSTRÅLING VED ÅBNING
UNDGÅ UDSÆTTELSE FOR STRÀLING.
SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA
DEL ÄR ÖPPNAD BETRAKTA EJ STRÅLEN.
AVATTAESSA ALTISTUT NÄKYVÄ JA NÄKYMÄTTÖMÄLLE
LASERSATEIL YLLE. ÄLÄ KATSO SÄTEESEN.
VRW1699
CLASS 1
LASER PRODUCT
THE STANDBY/ON BUTTON IS SECONDARY
CONNECTED AND THEREFORE DOES NOT
SEPARATE THE UNIT FROM MAINS POWER IN
STANDBY POSITION.
CLASS 1
LASER PRODUCT
L'INTERRUTTORE STANDBY/ON E'COLLEGATO AD
UN CIRCUITO SECONDARIO E QUINDI, NELLA
POSIZIONE DI ATTESA(STANDBY), NON SCOLLEGA
L'UNITÀ DALLA PRESA DI CORRENTE. FRA NETTET
I STANDBY-STILLINGEN.
background image
En/It
Questo prodotto contiene una tecnologia di
protezione dei diritti di autore, che è a sua volta
protetta dal contenuto di certi brevetti americani e da
altri diritti sulla proprietà intellettuale, posseduti dalla
Macrovision Corporation e da altri possessori di diritti.
L'uso di questa tecnologia di protezione dei diritti
d'autore deve essere autorizzato dalla Macrovision
Corporation, ed è inteso solamente per uso
domestico, o per altri scopi limitati, ove non altrimenti
autorizzato dalla Macrovision Corporation. L'uso di
tecniche di inversione e lo smontaggio sono proibiti.
CONGRATULATIONS ON YOUR PURCHASE OF
THIS FINE PIONEER PRODUCT.
Pioneer is on the leading edge of DVD research for
consumer products and this unit incorporates the latest
technological developments.
We are sure you will be fully satisfied with the DVD
player.
Thank you for your support.
Please read through these operating instructions so
you will know how to operate your model properly.
After you have finished reading the instructions, put
them away in a safe place for future reference.
· This player is not suitable for commercial use.
This product incorporates copyright protection
technology that is protected by method claims of
certain U. S. patents and other intellectual property
rights owned by Macrovision Corporation and other
rights owners. Use of this copyright protection
technology must be Authorized by Macrovision
Corporation, and is intended for home and other
limited viewing uses only unless otherwise
authorized by Macrovision corporation. Reverse
engineering or disassembly is prohibited.
CONGRATULAZIONI PER L'ACQUISTO DI
QUESTO PRODOTTO PIONEER.
Pioneer è all'avanguardia della tecnologia DVD per il
consumatore e quest'unità include i suoi ultimi sviluppi
tecnologici.
Siamo certi che sarete soddisfatti di questo lettore per
DVD.
Vi ringraziamo per la vostra scelta.
Leggere completamente questo manuale per essere
certi di saper usare correttamente il lettore per DVD.
Terminata la lettura, conservare il manuale in un luogo
sicuro per poterlo riutilizzare in caso di bisogno.
· Questo lettore non è adatto all'uso commerciale.
background image
2
En
Features of This Player
Compatible with DVD, Video CD
and CD formats
DVD, Video CD and CD discs that display the logos
shown below can be played back on PIONEER DVD
players. For more information on discs compatible with
this player, refer to the table below.
The disc format logos shown above are found on disc
labels or on disc jackets.
· To prevent malfunction, do not use an 8 cm adaptor
(for CDs).
· Discs other than the ones indicated above cannot be
played on this unit.
· DVDs that have incompatible region numbers, DVD-
Audio, DVD-ROM, and CD-ROM cannot be played on
this unit. The region number of the player can be
found on the rear panel.
*1 Playing recordable CDs
· Note that this unit cannot record onto recordable discs.
· This unit can play music-use CD-R and CD-RW discs.
However, depending on the condition of the CD recorder
and the disc, you may find that not all discs will play
successfully. (For example, if the disc is scratched or
dirty, or if the player's pickup lens is dirty.)
12 cm/
single-sided
12 cm/
double-sided
8 cm/
single-sided
8 cm/
double-sided
1 layer
2 layer
1 layer
2 layer
1 layer
2 layer
1 layer
2 layer
DVD VIDEO
DVD VIDEO
Types of playable
discs and their marks
Diameter/
Playable sides
Playback time
Digital audio
Digital video
(MPEG 2)
133 min.
242 min.
266 min.
484 min.
VIDEO CD
CD
Digital audio
Digital video
(MPEG 2)
DVD VIDEO
VIDEO CD
CD
41 min.
75 min.
82 min.
150 min.
VIDEO CD single
CD single
Digital audio
Digital video
(MPEG 1)
Max. 74
minutes
Digital audio
Digital video
(MPEG 1)
Max. 20
minutes
Digital audio
Max. 74
minutes
12 cm/
single-sided
8 cm
/single-sided
12 cm
/single-sided
8 cm
/single-sided
Digital audio
Max. 20
minutes
*1
*1
background image
3
En
English
Wide range of DVD viewing options
Multi-Angle (page 29)
You can view scenes from different camera angles when
watching movies or other media with multiple angle
playback available.
Multiple Languages (page 31)
You can select the language on when watching movies
or other media that have multiple language and/or audio
soundtracks recorded on them.
Multi-Language Subtitles (page 32)
You can select a subtitle language or turn subtitles off
when watching movies or other media with subtitles
available.
This mark indicates this may not be possible with certain
discs.
Energy-saving design
This unit is designed to use less than 1 W of energy
when this player is in standby mode.
Audio
: 1
English
Dolby Digital
5.1CH
Audio
: 2
Spanish
HELLO
HOLA
Dolby Digital
5.1CH
HELLO!
HOLA!
Subtitle
:1 English
Subtitle
:2 Spanish
ANGLE
: 3/4
ANGLE
: 2/4
Compatible with a wide range of
DVD digital audio output formats
DVDs are recorded in one of four types of digital audio
formats (as of October 1998). The digital audio output
jacks of this player output Dolby Digital
*2, DTS*3,
MPEG, and linear PCM digital bitstreams.
This player has a function that converts Dolby Digital and
MPEG audio formats into the linear PCM format. This
allows playback of DVDs recorded in Dolby Digital and
MPEG without the need for a decoder.
Easy setup and adjustment using
on-screen menus
Press SETUP on the remote control to open the Setup
screen and you'll find setting up and adjusting the
system easy to do with on-screen menus conveniently
organized and arranged. Additionally, on-screen
information ( i )
y appears to clarify the functions and
explain the options available. Below are just a few
examples.
Select the type of TV screen
you are using and the
preferred screen format
you'd like to use when
watching DVDs in the Video
menu (page 27).
*2 Manufactured under license from Dolby Laboratories.
"Dolby" and the double-D symbol are trademarks of Dolby
Laboratories. Confidential unpublished works, © 1992-1997
Dolby Laboratories. All rights reserved.
*3 "DTS" is trademarks of Digital Theater Systems, Inc.
Audio1 Audio2
General
Language
Video
Video Out --
TV Screen
Move
Exit
16:9(Wide)
4:3(Pan&Scan)
4:3(Letter Box)
SETUP
Select your display preference
1
Answer a few questions and
have all the necessary audio,
video, and on-screen
language adjustments set
automatically by the player
using the Setup Navigator
(page 16).
Audio1 Audio2
General
Language
Video
Setup Navigator
Move
Exit
SETUP
Select
ENTER
Setup Navigator
Auto Start Off
Start
y
The on-screen information ( i ) only appears if you
chose [English] as the [OSD Language] (page 17,
30).
While using the Setup Navigator, no on-screen
information ( i ) is displayed.

Reviews

There are no reviews of this manual yet.
