OWNER'S MANUAL
MANUEL DU PROPRIETAIRE
9A09453801
EX-M1
CD RECEIVER SYSTEM
?
Thank you for choosing TEAC. Read this manual carefully to get the best performance from this unit.
Nous vous remercions pour l'achat d'un appareil TEAC. Lire ce manuel avec attention pour obtenir les
meilleures performances possibles de cet appareil.
background image
OWNER'S MANUAL
MANUEL DU PROPRIETAIRE
9A09453801
EX-M1
CD RECEIVER SYSTEM
?
Thank you for choosing TEAC. Read this manual carefully to get the best performance from this unit.
Nous vous remercions pour l'achat d'un appareil TEAC. Lire ce manuel avec attention pour obtenir les
meilleures performances possibles de cet appareil.
background image
2
Important Safety Instructions 1
Y
AC POWER CORD CONNECTION
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG
TO WIDE SLOT, FULLY INSERT.
CORDE DE CONNEXION CA
ATTENTION:
POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA
LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE
CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU'AU
FOND.
For CANADA
Pour le CANADA
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
· Reorient or relocate the equipment and/or the receiving
antenna.
· Increase the separation between the equipment and
receiver.
· Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
· Consult the dealer or an experienced radio/TV technician for
help.
CAUTION
Changes or modifications to this equipments not expressly
approved by TEAC CORPORATION for compliance will void the
user's warranty.
For U.S.A.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance
with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
9) Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the
apparatus. When a cart is used, use
caution
when
moving
the
cart/apparatus combination to avoid
injury from tip-over.
13) Unplug this apparatus during lightning storms or when
unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
< Do not expose this apparatus to dripps or splashes.
< Do not place any objects filled with liquids, such as vases,
on the apparatus.
< Do not install this apparatus in a confined space such as a
book case or similar unit.
< The apparatus draws nominal non-operating power from the
AC outlet with its POWER switch in the off position.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
E
R
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated "dangerous voltage" within
the product's enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
WARNING : TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
background image
3
Contents
Important Safety Instructions ....................................................... 2
Before Use ........................................................................................ 4
Compact Disc ................................................................................... 5
Cassette Tape .................................................................................. 5
Maintenance .................................................................................... 6
Battery Installation .......................................................................... 6
Remote Control Unit ........................................................................ 7
Connections ..................................................................................... 7
Names of Each Control ................................................................... 8
Basic Operation ............................................................................. 10
Listening to CDs ............................................................................. 11
Repeat Playback - CD ................................................................... 12
Shuffle Playback - CD ................................................................... 12
Programmed Playback - CD ........................................................ 13
Listening to Radio Programs ....................................................... 14
Storing Preset Stations ................................................................ 14
Lustening to Tapes ........................................................................ 15
Tape Recording ............................................................................. 16
Clock Adjustment .......................................................................... 17
Timer Setting .................................................................................. 18
Trouble Shooting ........................................................................... 19
Specifications ................................................................................ 19
Optical pickup:
Type
:
SF-P200Z
Manufacturer :
SANYO Electric Co., Ltd.
Laser output
:
Less than 0.5 mW on the objective lens
Wavelength
:
765 - 815 nm
This product has been designed and manufactured according to
FDA regulations "title 21, CFR, chapter 1, subchapter J, based on
the Radiation Control for Health and Safety Act of 1968", and is
classified as class 1 laser product. There is not hazardous
invisible laser radiation during operation because invisible laser
radiation emitted inside of this product is completely confined in
the protective housings.
The label required in this regulation is shown
x.
For U.S.A.
x
Important Safety Instructions 2
Sommaire
Avant l'utilisation ........................................................................... 20
Disque compact ............................................................................. 21
Magnétophone à cassette ........................................................... 21
Entretien .......................................................................................... 22
Installation des piles ..................................................................... 22
Télécommande .............................................................................. 23
Connexions ..................................................................................... 23
Nomenclature des controles ....................................................... 24
Opération de base ......................................................................... 26
Écoute des CD ................................................................................ 27
Lecture répétée - CD .................................................................... 28
Lecture aléatoire - CD .................................................................. 28
Lecture programmée - CD ........................................................... 29
Écoute de la radio ......................................................................... 30
Entreposage de postes pré-réglés ............................................. 30
Écoute de cassettes ..................................................................... 31
Enregistrement de cassette ........................................................ 32
Réglage de l'horloge ..................................................................... 33
Réglage de la minuterie ............................................................... 34
Dépannage ..................................................................................... 35
Spécifications ................................................................................ 35
CAUTION
< DO NOT REMOVE THE PROTECTIVE HOUSING USING
SCREWDRIVER.
< USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION EXPOSURE.
< IF YOU SHOULD EXPERIENCE ANY PROBLEMS WITH THIS
PRODUCT THAT CANNOT BE RESOLVED WITH THE
"TROUBLESHOOTING" SECTION LATER IN THIS MANUAL,
CONTACT A TEAC AUTHORIZED SERVICE AGENCY. DO NOT
CONTINUE TO USE THE PRODUCT UNTIL THE PROBLEM IS
RESOLVED.
background image
4
Before Use
Read this before operation
< As the unit may become hot during operation, always leave
sufficient space around the unit for ventilation.
< The voltage supplied to the unit should match the voltage as
printed on the rear panel. If you are in any doubt regarding this
matter, consult an electrician.
< Choose the installation location of your unit carefully. Avoid
placing it in direct sunlight or close to a source of heat. Also
avoid locations subject to vibrations and excessive dust, heat,
cold or moisture.
< Do not place the unit on any high heat-producing units like
your amplifier/receiver.
< Do not open the cabinet as this might result in damage to the
circuitry or electrical shock. If a foreign object should get into
the set, contact your dealer or service agency.
< When removing the power plug from the wall outlet, always
pull directly on the plug, never yank the cord.
< To keep the laser pickup clean, do not touch it, and do not
forget to close the flap lid when not using the CD player.
< Do not attempt to clean the unit with chemical solvents as this
might damage the finish. Use a clean, dry cloth.
< Keep this manual in a safe place for future reference.
DO NOT MOVE THE UNIT DURING CD PLAYBACK
During playback, the disc rotates at high speed. Do NOT lift or
move the unit during playback. Doing so may damage the disc.
WHEN MOVING THIS UNIT
When changing places of installation or packing the unit for
moving, be sure to remove the disc. Then, press the power
switch to turn the power off, and disconnect the power cord.
Moving this unit with the disc loaded may result in damage to
this unit.
Beware of condensation
When the unit (or a disc) is moved from a cold to a warm place,
or used after a sudden temperature change, there is a danger
of condensation; vapor in the air could condense on the
internal mechanism, making correct operation impossible. To
prevent this, or if this occurs, leave the unit for one or two
hours with the power turned on. The unit will stabilize at the
temperature of its surroundings.
CAUTION Regarding Placement
To maintain proper ventilation, be sure to leave a space
around the unit (from the largest outer dimensions including
projections) equal to, or greater than, shown below.
Left and Right Sides
: 4" (10 cm)
Rear Panel
: 4" (10 cm)
Top Panel
: 20" (50 cm)
background image
5
ENGLISH
< Should the disc become dirty, wipe the
surface radially (from the center out
towards the edge) with a soft, dry
cloth. Do not wipe in a circular motion :
Compact Disc
Discs which can be used with this unit:
Conventional audio CDs
Properly finalized CD-R discs
Note:
Depending on the quality of the disc and/or the condition of the
recording, some CD-R discs may not be playable.
CD-RW discs cannot be played on this unit.
< Always put the disc in place with the label side facing you.
(Compact discs can be played or recorded only on one side.)
< To remove a disc from its storage case, press down on the
center of the case and lift the disc out, holding it carefully by
the edges.
< Never use such chemicals as record sprays, antistatic sprays
or fluid, benzine or thinner to clean the discs. Such chemicals
will do irreparable damage to the disc's plastic surface.
< Discs should be returned to their cases after use to avoid dust
and scratches that could cause the laser pickup to "skip."
< Do not expose discs to direct sunlight or high humidity and
temperature for extended periods. Long exposure to high
temperatures will warp the disc.
< CD-R discs are more sensitive to the effects of heat and
ultraviolet rays than ordinary CDs. It is important that they are
not stored in a location where direct sunlight will fall on them,
and which is away from sources of heat such as radiators or
heat-generating electrical devices.
< Printable CD-R discs aren't recommended, as the label side
might be sticky and damage the unit.
< Do not stick papers or protective sheets on the discs and do
not use any protective coating spray.
< Use a soft oil-based felt-tipped pen to write the information on
the label side. Never use a ball-point or hard-tipped pen, as
this may cause damage to the recorded side.
< Never use a stabilizer. Using commercially available CD
stabilizers with this unit will damage the mechanisms and
cause them to malfunction.
< Do not use irregular shape CDs (octagonal, heart-shape, etc.).
CDs of this sort can damage the unit:
How to remove the disc
How to hold the disc
< If you are in any doubt as to the care and handling of a CD-R
disc, read the precautions supplied with the disc, or contact
the disc manufacturer directly.
Cassette Tape
Tape Selection:
Metal and chrome (cobalt) tapes have identification holes.
< You can use only normal (Type!) tapes.
Normal(Type!)
CrO2(Type@)
Metal(Type!%)
Tape Handling:
c
b
a
Use your finger or a pencil to turn the cassette's hub and take up
any slack tape.
< Avoid touching the tape. Fingerprints attract dust and dirt.
< Do not store tapes in the following places:
On top of heaters, exposed to direct sunlight or in any other
places with high temperatures.
Near speakers, on TV sets or amplifiers or where they would
be exposed to strong magnetic fields.
Where humidity is high and in dirty, dusty places.
< Avoid dropping or subjecting cassettes to excessive shocks.
< As C-120 tapes are physically weak and could become
entangled in the transport mechanism, do not use them.
b
c
a

Reviews

There are no reviews of this manual yet.
