SENNHEISER HME 100-SE-3 Owner's Manual

Cover page of SENNHEISER HME 100-SE-3 Owner's Manual

Owner's Manual for SENNHEISER HME 100-SE-3, downloadable as a PDF file.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 20 pages
  • File size: 0.96 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
1
Instructions for use
HME 100/105/110/120
HMD 120
_83566_1006_6. 1 , 4. 2008 1:42 13
background image
1
Instructions for use
HME 100/105/110/120
HMD 120
_83566_1006_6. 1 , 4. 2008 1:42 13
background image
2
_83566_1006_6. 2 , 4. 2008 1:42 13
background image
3
Contents
Safety tips ............................................................................................................. 4
Headset features ................................................................................................. 5
Product variants ......................................................................................................................... 6
Delivery includes .................................................................................................. 8
Preparing the headsets for use......................................................................... 9
Connecting the headsets .......................................................................................................... 9
Adjusting the headband .........................................................................................................10
Positioning the microphone ................................................................................................... 11
Using the headsets ............................................................................................ 13
Mono/Stereo selection (HME 100 only)............................................................................... 13
Adjusting the volume .............................................................................................................. 13
Adjusting the microphone gain ............................................................................................. 14
Folding up the headphones .................................................................................................... 14
Spare parts .......................................................................................................... 15
Replacing the wind screen ......................................................................................................15
Replacing the ear cushions .....................................................................................................15
Connector assignment...................................................................................... 16
In case of difficulty ............................................................................................ 17
Technical data .................................................................................................... 18
Manufacturer declarations .............................................................................. 20
_83566_1006_6. 3 , 4. 2008 1:42 13
background image
4
The HME 100, HME 105, HME 110, HME 120 and HMD 120 are pilot headsets with closed ear
protector headphones for use in helicopters, propeller and turboprop aircraft.
Safety requirements
When using a headset, typical aircraft sounds (for example, those from engines, propellers,
warning alarms, etc.) may sound different to you. Before operating any aircraft, make sure
that, while wearing a headset, you can hear and recognize these sounds. Set the volume to safe
levels that do not interfere with your ability to hear informational sounds and warning alarms.
Do not attempt to repair the headset yourself. If problems occur, contact your Sennheiser agent
for assistance.
Only replace parts of the headset whose replacement is described in this manual. All other parts
of the headset must be replaced by your Sennheiser agent.
Do not immerse the headset in water! For information on how to clean the headset, contact
your Sennheiser agent.
_83566_1006_6. 4 , 4. 2008 1:42 13
background image
5
Headset features
HME 100 headset
New passive headset with excellent noise attenuation
Excellent comfort due to very low weight, soft ear cushions STANDARD and padded headband
as well as best possible freedom of movement due to unilateral connecting cable
Foldable headband for easy and space-saving storage
Clear communications due to MKE 45-1 electret microphone with adjustable sensitivity
(sensitivity adjustment must be carried out by authorized personnel)
Microphone can be easily positioned and worn on either left or right side due to flexible
microphone boom with quick-fixing device
Optimum radio reception due to headphone systems with wide frequency response
Integrated volume control
Adaption to the aircraft intercom system via Mono/Stereo switch
JTSO approval
Made in Germany,
five-year warranty
Personalization of the headset
Name:
_83566_1006_6. 5 , 4. 2008 1:42 13
