The front grille is attached to the cabinet by catches. Detach it by
pulling toward you.
·
The woofers are attached to the baffle by external screws. To
detach them, unfasten those screws. When attaching, face its
terminal downward.
·
The midrange is attached to the baffle by external screws. To
detach it, unfasten those screws. When attaching, face its terminal
downward.
·
The tweeter is attached to the baffle by external screws. To detach
it, unfasten those screws. When attaching, face its terminal
downward.
HOW TO REASSEMBLE AND
DISASSEMBLE
This service manual is intended for qualified service technicians; it is
not meant for the casual do-it- your selfer. Qualified technicians have
the necessary test equipment and tools, and have been trained to
properly and safely repair complex products such as those covered by
this manual.
Improperly performed repairs can adversely affect the safety and
reliability of the product and may void the warranty. If you are not
qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service
technician.
SPEAKER SYSTEM
S-H452F-K
Service
Manual
background image
1
CS-G405-K/Q
ORDER NO.
PET01004
PIONEER CORPORATION
4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC.
P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V.
Haven 1087, Keetberglaan 1 B-9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 501 Orchard Road, #10-00, Wheelock Place, Singapore 238880
©PIONEER CORPORATION 2001
2001 Printed in U.S.A.
·
The front grille is attached to the cabinet by catches. Detach it by
pulling toward you.
·
The woofers are attached to the baffle by external screws. To
detach them, unfasten those screws. When attaching, face its
terminal downward.
·
The midrange is attached to the baffle by external screws. To
detach it, unfasten those screws. When attaching, face its terminal
downward.
·
The tweeter is attached to the baffle by external screws. To detach
it, unfasten those screws. When attaching, face its terminal
downward.
HOW TO REASSEMBLE AND
DISASSEMBLE
This service manual is intended for qualified service technicians; it is
not meant for the casual do-it- your selfer. Qualified technicians have
the necessary test equipment and tools, and have been trained to
properly and safely repair complex products such as those covered by
this manual.
Improperly performed repairs can adversely affect the safety and
reliability of the product and may void the warranty. If you are not
qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service
technician.
SPEAKER SYSTEM
S-H452F-K
Service
Manual
background image
2
CS-G405-K/Q
PARTS LIST
NOTES: · Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
· The "
"mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Mark No. Description
Parts No.
Mark No. Description
Parts No.
For Packing
SCHEMATIC DIAGRAM
S-H452F-K
Low Frequency Transducer
276455
Packing Case
276653
Low Frequency Passive Transducer
276935
Corner Pad Assy, Top
276668
Mid Frequency Transducer
276648
Corner Pad Assy, Bottom
276673
High Frequency Transducer
276480
Poly Bag
276693
Front Grille Assembly
276722
Center Divider
276688
Crossover Assembly
276742
Screw (for Tweeter)
M3x18PB
Screw (for Woofer)
M4x18PB
Instruction Manual
276871
Catch
276519
