background image
Operating Instructions
HDTV PROJECTION MONITOR
PRO-730HDI
PRO-530HDI
ARB1557A_En_001.P65
8/8/03, 16:16
1
background image
Operating Instructions
HDTV PROJECTION MONITOR
PRO-730HDI
PRO-530HDI
ARB1557A_En_001.P65
8/8/03, 16:16
1
background image
2
Progressive Scan/HDTV monitor
All SDTV and HDTV signals are converted to 1080i and displayed at
high resolution.
HDMI (High-Definition Multimedia Interface) with
Copy Protection system
The combination of High-Definition Multimedia Interface (HDMI) and
High-bandwidth Digital Content Protection (HDCP) is important for
viewing copy-protected digital contents through SAT/CATV BOX or
DVD player. DIGITAL input terminal receives the signal in the form of
digital information. In this way, all signals coming into this interface
have a very high resolution and less noise compared to an analog
interface.
Dual System Component Input for NTSC/
Progressive
Connection to a DVD player using the component output terminals
makes possible a high picture-quality display, superior to that of a S-
VIDEO terminal connection. This also handles high resolution
component input (1080i, 480p), which will function as an interface
for high-quality images in future.
Dual Tuner (Split Screen and CH Search screen
function)
Two TV tuners are provided, making it possible to split the screen
vertically in two areas in order to display moving images
simultaneously on each of them. In addition, the channel search
function makes it possible to check and perform other functions etc.,
on the program that you choose to run in the background, while
viewing the foreground program. This adds remarkable convenience
when you are concerned with viewing two programs.
Pioneer PureCinema III Format Converter
An advanced and exclusive I/P (Interlace/Progressive) third generation
format converter called "PureCinema III", delivers a high-resolution
progressive picture (480p) or Interlaced picture(1080i). *This is USER
SELECTABLE
It reproduces film material in a very smooth and film-like image.
This is perfect technology for movie lovers.
Anti-Reflective Tinted Protection Panel
The accompanying protective panel is AR (Anti-Reflective) coated
and tinted.
This is not only to protect the screen, but to present a more natural
and high contrast image with less light reflection. This AR coating is
very durable against scratching.
Lens System for HDTV
The adoption of a specialized lens system for high-resolution HDTV
which faithfully reproduces HDTV 1080i signals allows for highly color-
saturated images to be displayed at high resolution. Also, by
incorporating an "achromatic coated" lens for the blue CRT, the
picture image is reproduced with less halo and appears sharp.
Reference Theater mode and PRO mode
<Reference Theater Mode>
This mode reproduce film material just like a real film image. By
cutting video enhancement circuits, the picture becomes more natural
and looks film-like.
<PRO Mode>
This mode offers pro level video adjustment to the user. You can go
into several areas such as: LTI (Luminance Transient Improvement),
Gamma, CONTRAST EXP, SHARP MODE, White Balance.
Fully Illuminated Remote Control Unit
A fully illuminated universal remote control is used that makes it
possible to operate other devices. Remote operations can thus be
performed easily even in dark rooms and similar environments.
Multi-Point Convergence System
Convergence of the red, green, blue guns* in the TV is critical to a
good picture. Thanks to new convergence system digital technology,
not only can the center of the screen be adjusted, so can an amazing
72 other points across the entire viewing area. This ensures color
accuracy throughout the screen. The adjustment is easily done from
the remote control. (*guns = cathode ray tubes)
Program Block (V-CHIP)
You can block selected programs based on the established rating
system for television programs and movies. The rating systems are
defined below:
<U.S.A. RATING SYSTEM>
The TV parental Guidelines are used to rate television programming:
<TV-Y>, <TV-Y7>, <TV-G>, <TV-PG>, <TV-14> and <TV-MA>.
The Motion Picture Association of America(MPAA) guidelines are used
to rate movies: <G>, <PG>, <PG-13>, <R>, <NC-17>, <X> and <NR>.
<CANADIAN RATING SYSTEM>
The Canadian English Language Rating System is used to rate
television programming: <C>, <C8+>, <G>, <PG>, <14+> and <18+>.
The Canadian French Language Rating system is used to rate
television programming: <G>,<8+>,<13+>,<16+> and <18+>.
In order to block programming you feel is inappropriate, rating limits
can be set on both systems using the remote control and a password.
Definitions:
SDTV Standard Definition Television
HDTV High Definition Television
CH
TV channel
Read and understand these 'Operating Instructions'
before operating your Monitor.
Follow the 'IMPORTANT SAFETY INSTRUCTIONS
AND WARNINGS' section and all the warnings on
the product.
FEATURES
This HDTV monitor has the
capability to display an HDTV
(1080i) picture in its 16 x 9 viewing
area.
HDMI, the HDMI logo and High-Definition Multimedia Interface
are trademarks or registered trademarks of HDMI Licensing LLC.
background image
3
INTRODUCTION
Thank you for purchasing this PIONEER HDTV Projection
Monitor.
Please read the precautionary instructions enclosed with these
operating instructions please do so before proceeding.
After learning how to operate the Projection Monitor, be sure
to keep this manual handy for future reference.
[For U.S. model]
IMPORTANT NOTICE
H006AEn
The serial number for this equipment is located in the Rear
panel. Please write this serial number on your enclosed
warranty card and keep it in a secure area. This is for your
security.
In this manual, we refer to the 'HDTV PROJECTION MONITOR',
as the 'Projection Monitor' or the 'Monitor'.
Note on the SPLIT screen and SEARCH screen functions
The SPLIT screen and SEARCH screen functions provided in
this monitor are intended for private viewing only.
Use of the above video processing functions for profitmaking
purpose or for public viewing (clubs, hotels, etc.) without prior
authorization from the transmitter and/or owner of the video
program (s) may be an infringement of existing copyright laws.
NOTICE ON ADVERSE EFFECTS TO TV TUBE
Image Burn-in :
Displaying the same images on your Monitor (such as still or paused images, TV/video games,
close-captioning, computer programs, on-screen displays, or other images with static or virtually static portions)
for a prolonged period of time may cause permanent residual images to appear on your Monitor.
Avoid displaying the same image continuously over a long period of time. If the same image is displayed
continuously for several hours, or for shorter periods of time over several days, a permanent after-image may
remain on the screen due to burning of the phosphorous materials contained in your Monitor. Such images
may become less noticeable if moving images are later displayed, but they will not disappear completely. For
Games, please select the Game Mode (page 52), and do not view static or virtually static images on your
Monitor for more than two hours. After displaying static or virtually static images on your Monitor, it is
recommended that you view a normal moving picture in the "WIDE" or "FULL" screen setting for three (3)
times longer than the time the static or virtually static images were displayed.
WARNING: Handling the cord on this product or cords
associated with accessories sold with the product will
expose you to lead, a chemical known to the State of
California and other governmental entities to cause cancer
and birth defects or other reproductive harm.
Wash hands after handling.
background image
4
WARNING
IMPORTANT SAFETY INSTRUCTIONS AND WARNINGS
· Read all of these instructions.
· Keep these instructions for later use.
· Follow all warnings and instructions marked on the Monitor.
1.
This Monitor is equipped with a
polarized alternating current line
plug (a plug having one blade
wider than the other).
This plug will fit into the power
outlet only one way. This is a
safety feature.
If you are unable to insert the plug
fully into the outlet, try reversing
the plug. If the plug should still fail
to fit, contact your electrician to
replace your obsolete outlet. Do
not defeat the safety purpose of
the polarized plug.
2.
If the power cord or plug becomes
damaged or frayed, unplug this
Monitor from the wall outlet and
refer
to
qualified
service
personnel for servicing.
3.
Do not overload wall outlets and
extension cords as this can result
in fire or electrical shock.
4.
Do not allow anything to rest on
or roll over the power cord, and
do not place the Monitor where
the power cord maybe subject to
traffic or abuse. This may result
in electrical or fire hazard.
5.
Do not attempt to service this
Monitor yourself as opening or
removing covers may expose you
to dangerous voltage or other
hazards. Refer all servicing to
qualified personnel.
6.
Never push the objects of any kind
into this Monitor through cabinet
slots
as
they
may
touch
dangerous voltage points or short
out parts that could result in a fire
or electric shock. Never spill liquid
of any kind on the Monitor.
7.
If the Monitor has been dropped
or the cabinet has been damaged,
unplug this Monitor from the wall
outlet and refer to qualified service
personnel for servicing.
8.
If liquid has been spilled into the
Monitor, unplug the Monitor from
the wall outlet and refer servicing
to qualified service personnel.
The following symbols are found in this
manual and on the labels on the product.
They alert the operators and service
personnel of this equipment to potentially
dangerous conditions.
WARNING
This symbol refers to a hazard or unsafe
practice which can result in severe personal
injury or death.
CAUTION
This symbol refers to a hazard or unsafe
practice which can result in personal injury
or property damage.
This symbol indicates an action that is
prohibited.
FOR YOUR PERSONAL SAFETY
background image
5
INTRODUCTION
9.
Do not subject your Monitor to
impact of any kind. Be particularly
careful not to damage the screen
surface.
10.
Unplug the Monitor from the wall
outlet before cleaning. Do not use
liquid cleaners or spray-type
cleaners. Use a damp cloth for
cleaning.
11-1. Do not place this Monitor on an
unstable, uneven or an inclined
location. The Monitor may
overturn, causing serious injury
(to a person), and serious damage
to the appliance.
11-2. Be careful when placing the
Monitor on a cart to move it.
Quick stops, excessive force, and
uneven surfaces may cause the
Monitor and cart to overturn.
12.
· Do not use the Monitor near
water, for example, near a
bathtub, washbowl, kitchen sink,
or laundry tub, in a wet basement,
or near a swimming pool, etc.
· Never expose the Monitor to rain
water.
If the Monitor system has been
exposed to rain or water, unplug
the Monitor from the wall outlet
and refer servicing to qualified
service personnel.
13.
Choose a place where light (artificial
or sunlight) does not shine directly
on the screen.
14.
Avoid dusty places since the
buildup of dust inside the Monitor's
chassis
may
result
in
the
malfunctioning,
when
high
humidity persists.
15.
· The Monitor has slots, or
openings in the cabinet for
ventilation purposes to ensure the
reliable operation of the Monitor,
and to protect it from overheating.
These openings must not be
blocked or covered.
· Nevercovertheslotsoropenings
with cloth or other material.
· Never block the bottom
ventilation slots of the Monitor by
placing it on a bed, sofa, rug, etc.
· Never place the Monitor near or
over a radiator or heat register.
· NeverplacetheMonitorinabuilt-
in enclosure such as a bookcase,
unless proper ventilation is
provided.
PROTECTION AND LOCATION OF YOUR HDTV PROJECTION MONITOR
16.
If an outside antenna is connected through other
equipment, be sure the antenna system is grounded so
as to provide protection against voltage surges and built-
up static charges. In the U. S. A., section 810 of the
National Electrical Code, ANSI/NFPA 70, provides
information on proper grounding of the mast and
supporting structure, grounding of the lead-in wire to
an antenna-discharge unit, size of grounding
conductors, location of antenna-discharge unit,
connection to grounding electrode, and requirements
for the grounding electrode.
EXAMPLE OF ANTENNA GROUNDING IN
NATIONAL ELECTRICAL CODE INSTRUCTIONS
ANTENNA
LEAD IN WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUNDING CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
GROUND
CLAMP
ELECTRIC
SERVICE
EQUIPMENT
FIG. A
NEC-NATIONAL
ELECTRICAL CODE

Reviews

There are no reviews of this manual yet.
