PIONEER DVR-S706/XV/CN Service Manual

Cover page of PIONEER DVR-S706/XV/CN Service Manual

Service Manual for PIONEER DVR-S706/XV/CN, downloadable as a PDF file.

We also have owner's manual to this model.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 23 pages
  • File size: 3 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2004
DVR-S706
RRV3031
DVD/CD WRITER
DVR-S706
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model
Type
Power Requirement
Remarks
DVR-S706
KBXV
DC Power supply from AC Adapter
DVR-S706
XV/CN
DC Power supply from AC Adapter
NECESSARY INFORMATION FOR DHHS RULES MARKED ON THE
TOP COVER BELOW:
DANGER-VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN.
AVOID DIRECT EXPOSURE TO BEAM.
For details, refer to "Important Check Points for Good Servicing".
T-ZZY SEPT. 2004 printed in Japan
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2004
DVR-S706
RRV3031
DVD/CD WRITER
DVR-S706
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model
Type
Power Requirement
Remarks
DVR-S706
KBXV
DC Power supply from AC Adapter
DVR-S706
XV/CN
DC Power supply from AC Adapter
NECESSARY INFORMATION FOR DHHS RULES MARKED ON THE
TOP COVER BELOW:
DANGER-VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN.
AVOID DIRECT EXPOSURE TO BEAM.
For details, refer to "Important Check Points for Good Servicing".
T-ZZY SEPT. 2004 printed in Japan
background image
DVR-S706
2
12
34
12
3
4
C
D
F
A
B
E
SAFETY INFORMATION
IMPORTANT
THIS
PIONEER
APPARATUS
CONTAINS
INVISIBLE LASER OF CLASS 3b and VISIBLE
LASER OF CLASS 2.
SERVICING OPERATION OF THE APPARATUS
SHOULD
BE
DONE
BY
A
SPECIALLY
INSTRUCTED PERSON.
LASER DIODE CHARACTERISTICS
MAXIMUM OUTPUT POWER: 25 mW
WAVELENGTH: 654 - 662 nm
LASER DIODE CHARACTERISTICS
MAXIMUM OUTPUT POWER: 36 mW
WAVELENGTH: 780 - 787 nm
This service manual is intended for qualified service technicians; it is not meant for the
casual do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and
have been trained to properly and safely repair complex products such as those covered by this
manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely,
you should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
cause cancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 ­ Proposition 65
(DRW2230)
(DRW2220)
Bottom
· KBXV type
· XV/CN type
background image
DVR-S706
3
56
78
56
7
8
C
D
F
A
B
E
[Important Check Points for Good Servicing]
In this manual, procedures that must be performed during repairs are marked with the below symbol.
Please be sure to confirm and follow these procedures.
1. Product safety
Please conform to product regulations (such as safety and radiation regulations), and maintain a safe servicing environment by
following the safety instructions described in this manual.
1 Use specified parts for repair.
Use genuine parts. Be sure to use important parts for safety.
2 Do not perform modifications without proper instructions.
Please follow the specified safety methods when modification(addition/change of parts) is required due to interferences such as
radio/TV interference and foreign noise.
3 Make sure the soldering of repaired locations is properly performed.
When you solder while repairing, please be sure that there are no cold solder and other debris.
Soldering should be finished with the proper quantity. (Refer to the example)
4 Make sure the screws are tightly fastened.
Please be sure that all screws are fastened, and that there are no loose screws.
5 Make sure each connectors are correctly inserted.
Please be sure that all connectors are inserted, and that there are no imperfect insertion.
6 Make sure the wiring cables are set to their original state.
Please replace the wiring and cables to the original state after repairs.
In addition, be sure that there are no pinched wires, etc.
7 Make sure screws and soldering scraps do not remain inside the product.
Please check that neither solder debris nor screws remain inside the product.
8 There should be no semi-broken wires, scratches, melting, etc. on the coating of the power cord.
Damaged power cords may lead to fire accidents, so please be sure that there are no damages.
If you find a damaged power cord, please exchange it with a suitable one.
9 There should be no spark traces or similar marks on the power plug.
When spark traces or similar marks are found on the power supply plug, please check the connection and advise on secure
connections and suitable usage. Please exchange the power cord if necessary.
0 Safe environment should be secured during servicing.
When you perform repairs, please pay attention to static electricity, furniture, household articles, etc. in order to prevent injuries.
Please pay attention to your surroundings and repair safely.
2. Adjustments
To keep the original performance of the products, optimum adjustments and confirmation of characteristics within specification.
Adjustments should be performed in accordance with the procedures/instructions described in this manual.
4. Cleaning
For parts that require cleaning, such as optical pickups, tape deck heads, lenses and mirrors used in projection monitors, proper
cleaning should be performed to restore their performances.
3. Lubricants, Glues, and Replacement parts
Use grease and adhesives that are equal to the specified substance.
Make sure the proper amount is applied.
5. Shipping mode and Shipping screws
To protect products from damages or failures during transit, the shipping mode should be set or the shipping screws should be
installed before shipment. Please be sure to follow this method especially if it is specified in this manual.
background image
DVR-S706
4
12
34
12
3
4
C
D
F
A
B
E
CONTENTS
1. SPECIFICATIONS ............................................................................................................................................ 5
2. EXPLODED VIEWS AND PARTS LIST ............................................................................................................ 6
2.1 PACKING ................................................................................................................................................... 6
2.2 EXTERIOR SECTION................................................................................................................................ 8
2.3 DVD/CD DRIVE SECTION....................................................................................................................... 10
3. GENERAL INFORMATION ............................................................................................................................. 11
3.1 DIAGNOSIS ............................................................................................................................................. 11
3.1.1 EMERGENCY DISC REMOVAL........................................................................................................ 11
3.1.2 DISASSMBLY .................................................................................................................................... 11
3.1.3 PICKUP LENS CLEANING ............................................................................................................... 12
3.1.4 Failure Test (Diagnosis) Method ........................................................................................................ 14
3.1.5 How to Write the GUID ...................................................................................................................... 17
3.1.6 How to Check and Update the Version of the Firmware .................................................................... 21
background image
DVR-S706
5
56
78
56
7
8
C
D
F
A
B
E
1. SPECIFICATIONS
Accessories
· AC adapter ..... x 1
(DWX2404)
· AC power cord ..... x 1 (ADG7083)
· IEEE 1394 cable (6p - 4p) ..... x 1
(DDC1011) (1.5 m)
· USB 2.0 cable (USB - USB2) ..... x 1
(DDC1014) (1.0 m)
· IEEE 1394 cable (6p - 6p) ..... x 1
(DDC1012) (1.5 m)
· Vertical stand ..... x2
(DXB1778)
· Operating instructions ..... x 1
KBXV type : (DRC1230)
XV/CN type : (DRC1236)
· Manual eject pin ..... x1
(DEX1008)
4p
6p
USB
6p
6p
USB2
[Setting]
This drive is Horizontal and Vertical Use.
· Use the supplied stand to place the unit in vertical position.
[Interface]
USB 2.0 or IEEE 1394a
[Disc Size]
· 12 cm (4.72") / 8 cm (3.15")*
* 8 cm (3.15") discs cannot be used at upright position.
[Data Transfer Rate]
Data Read (Sustained)
DVD : Max. 16.62 MBytes/sec.
CD
: Max. 6.15 MBytes/sec.
(17.1 ­ 40X CAV Mode over 16 block transfer)
Data Write (Sustained)
DVD : Ave. 11.08 MBytes/sec. (8X DVD-R)
CD
: Ave. 3.69 MBytes/sec. (24X CD-R)
· The data transfer rate may not be output due to disc conditions
(scratches, etc.).
[Access Time/ Seek Time]
Access time (Random average)
DVD-ROM
: 140 ms
CD-ROM
: 130 ms
Seek time (Random average)
DVD-ROM
: 120 ms
CD-ROM
: 100 ms
[Power Supply]
AC adapter (supplied)
: +12 V DC / 0.8 A, +5 V DC / 1.4 A
[AC Adapter]
Power source
: 100 ­ 240 V AC, 50 / 60 Hz
Rated output
: +12 V DC / 2 A, +5 V DC / 2 A
[Power Consumption]
When playing DVD-ROM
: 24 W (100 V) ­ 37 W (240 V)
Idle
: 8 W (100 V) ­ 17 W (240 V)
[Other]
Supported operating systems: Windows 98SE, Windows 2000, Windows Me,
Windows XP
Dimensions
: 167 (W) x 56.2 (H) x 272.8 (D) mm
(including front panel)
: 6-9/16 (W) x 2-7/32 (H) x 10-3/4 (D) in.
Weight
: 2.1 kg (4.63 lb)
Operation temperature
: +5
°C to +35°C (41°F to 95°F)
Operation humidity
: 5% to 85% (no condensation)
Storage temperature
: ­ 40
°C to +60°C (­ 40°F to 140°F)
Storage humidity
: 5% to 90% (no condensation)
XV/CN type
[Accessories]
AC power cord ................................................ 1
AC adapter ...................................................... 1
USB cable (1.0 m) ........................................... 1
IEEE 1394 cable (1.5 m) ................................. 2
Vertical stand ................................................... 2
Manual eject pin .............................................. 1
Operating instructions ..................................... 1
NOTE:
· Specifications and design subject to possible modifications without notice, due to improvements.
DVR-S706/ KBXV, XV/CN
KBXB type
[Accessories]
AC adapter ...................................................... 1
USB cable (1.0 m) ........................................... 1
IEEE 1394 cable (1.5 m) ................................. 2
Vertical stand ................................................... 2
Manual eject pin .............................................. 1
Operating instructions ..................................... 1
XV/CN type
only
