background image
KDC-Z939
©B64-2263-00 (MV)
COMPACT
DIGITAL AUDIO
CD-RECEIVER
INSTRUCTION MANUAL
KDC-Z939(M)_ Cover
02.3.11
11:53 AM
Page 1
background image
KDC-Z939
©B64-2263-00 (MV)
COMPACT
DIGITAL AUDIO
CD-RECEIVER
INSTRUCTION MANUAL
KDC-Z939(M)_ Cover
02.3.11
11:53 AM
Page 1
background image
-- 2 --
English
Contents
Safety precautions......................3
About RDS ..................................4
About CDs...................................5
Notes on playing MP3/WMA.......6
General features .........................8
Power
Selecting the Source
Volume
Attenuator
Loudness
System Q
Audio Control
Speaker & Woofer Setting
Switching Display Type
Display switching part for "Display Type
A" and "Display Type B"
Display switching part for "Display Type
C" and "Display Type D"
Wallpaper selecting
Picture downloading
Auxiliary Input Display Setting
Non-fading Output
Theft Deterrent Faceplate
TEL Mute
Dual Zone System
Tuner features ...........................20
Tuning
Direct Access Tuning
Station Preset Memory
Auto Memory Entry
Preset Tuning
SNPP (Station Name Preset Play)
RDS features .............................22
Traffic Information
Radio Text Scroll
PTY (Program Type)
Program Type preset
Changing Language for PTY Function
CD/MP3/WMA/External disc
control features .....................26
Playing CD & MP3/WMA
Playing External Disc
Fast Forwarding and Reversing
Track Search
Album Search
Direct Track Search
Direct Album Search
Track/Album Repeat
Track Scan
Random Play
Magazine Random Play
Album Select
Disc Naming (DNPS)
Text/Title Scroll
DNPP (Disc Name Preset Play)
External TV control features ....31
Tuning
Preset Tuning
Main audio/auxiliary audio switching
Menu system.............................32
Menu System
Security Code
Touch Sensor Tone
Manual Clock Adjustment
Date Adjustment
Date Mode
Synchronize Clock
DSI (Disabled System Indicator)
Selectable Illumination
Contrast Adjustment
Dimmer
System Q
Built-in Amp Mute Setting
Dual Zone System Setting
B.M.S. (Bass Management System)
B.M.S. Frequency Offset
News Bulletin with Timeout Setting
Local Seek
Tuning Mode
Auto Memory Entry
AF (Alternative Frequency)
Restricting RDS Region
(Region Restrict Function)
Auto TP Seek
Monaural Reception
Text Scroll
Built-in Auxiliary input Setting
Picture downloading
Basic Operations of remote......39
Accessories ...............................41
Installation Procedure ..............41
Connecting Wires to Terminals 42
Installation ................................44
Troubleshooting Guide .............46
Specifications ...........................51
KDC-Z939(M)_U.S_r2
02.3.11
11:51 AM
Page 2
background image
-- 3 --
Safety precautions
To prevent injury or fire, take the
following precautions:
· Insert the unit all the way in until it is fully
locked in place. Otherwise it may fall out of
place when jolted.
· When extending the ignition, battery, or
ground wires, make sure to use automotive-
grade wires or other wires with a 0.75mm2
(AWG18) or more to prevent wire
deterioration and damage to the wire
coating.
·To prevent a short circuit, never put or leave
any metallic objects (such as coins or metal
tools) inside the unit.
· If the unit starts to emit smoke or strange
smells, turn off the power immediately and
consult your Kenwood dealer.
· Make sure not to get your fingers caught
between the faceplate and the unit.
· Be careful not to drop the unit or subject it to
strong shock.
The unit may break or crack because it
contains glass parts.
The marking of products using lasers
(Except for some areas)
The label is attached to the chassis/case and
says that the component uses laser beams
that have been classified as Class 1. It
means that the unit is utilizing laser beams
that are of a weaker class. There is no
danger of hazardous radiation outside the
unit.
CLASS 1
LASER PRODUCT
2WARNING
To prevent damage to the machine,
take the following precautions:
· Make sure to ground the unit to a negative
12V DC power supply.
· Do not open the top or bottom covers of the
unit.
· Do not install the unit in a spot exposed to
direct sunlight or excessive heat or humidity.
Also avoid places with too much dust or the
possibility of water splashing.
· Do not subject the faceplate to excessive
shock, as it is a piece of precision
equipment.
· When replacing a fuse, only use a new one
with the prescribed rating. Using a fuse with
the wrong rating may cause your unit to
malfunction.
·To prevent a short circuit when replacing a
fuse, first disconnect the wiring harness.
· Do not place any object between the
faceplate and the unit.
· Do not use your own screws. Use only the
screws provided. If you use the wrong
screws, you could damage the unit.
· Do not apply excessive force to the moving
faceplate. Doing so will cause damage or
malfunction.
· Do not apply excessive force to the open
faceplate or place objects on it. Doing so will
cause damage or breakdown.
2CAUTION
IMPORTANT INFORMATION
About the disc changer/CD player to
be connected:
To connect a disc changer having the "O-N"
switch to this unit, set the "O-N" switch to "N".
Precautions when connecting disc
changers/CD players released in 1997 or
earlier.
When you connect a model with no "O-N"
switch, the converter cord CA-DS100
available as an option may be required. For
details, consult your Kenwood dealer.
A disc changer doesn't work when it is
connected without using these options.
If a model with no "O-N" switch is
connected, some unavailable functions and
information that cannot be displayed are
generated.
Note that none of the KDC-C100, KDC-C302,
C205, C705, and non-Kenwood CD changers
can be connected.
You can damage both your unit and the CD
changer if you connect them incorrectly.
Do Not Load 3-in. CDs in the CD slot
If you try to load a 3 in. CD with its adapter
into the unit, the adapter might separate from
the CD and damage the unit.
KDC-Z939(M)_U.S_r2
02.3.11
11:51 AM
Page 3
background image
-- 4 --
English
Safety precautions
· If you experience problems during
installation, consult your Kenwood dealer.
· If the unit fails to operate properly, press the
Reset button. The unit returns to factory
settings when the Reset button is pressed.
If the unit still fails to operate properly after
the Reset button has been pressed, contact
your local KENWOOD dealer for assistance.
·Press the reset button if the disc auto
changer fails to operate correctly. Normal
operation should be restored.
·We recommend the use of the Security
Code function (see p. 33) to prevent theft.
· The illustrations of the display and the panel
appearing in this manual are examples used
to explain more clearly how the controls are
used. Therefore, what appears on the display
in the illustrations may differ from what
appears on the display on the actual
equipment, and some of the illustrations on
the display may represent something
impossible in actual operation.
NOTE
Lens Fogging
Right after you turn on the car heater in cold
weather, dew or condensation may form on
the lens in the CD player of the unit. Called
lens fogging, CDs may be impossible to play.
In such a situation, remove the disc and wait
for the condensation to evaporate. If the unit
still does not operate normally after a while,
consult your Kenwood dealer.
Cleaning the Faceplate Terminals
If the terminals on the unit or faceplate get
dirty, wipe them with a dry, soft cloth.
Cleaning the Unit
If the faceplate of this unit is stained, wipe it
with a dry soft cloth such as a silicon cloth.
If the faceplate is stained badly, wipe the stain
off with a cloth moistened with neutral
cleaner, then wipe neutral detergent off.
Applying spray cleaner directly to the unit may
affect its mechanical parts. Wiping the
faceplate with a hard cloth or using a volatile
liquid such as thinner or alcohol may scratch
the surface or erases characters.
Cleaning the CD Slot
As dust tends to accumulate in the CD slot,
clean it every once in a while. Your CDs can
get scratched if you put them in a dusty CD
slot.
RDS (Radio Data System)
When listening to an RDS station, the program
service name of the station is displayed,
advising you quickly which station is being
received.
RDS (Radio Data System) stations also
transmit frequency data for the same station.
When you are making long trips, this function
automatically alternative switches to the
particular frequency with the best reception
for the particular network of stations that you
want to listen to. The data is automatically
stored, allowing you to switch quickly to
another RDS stations, broadcasting the same
program, that has better reception. These
include stations stored in the station preset
memory that you often listen to.
Enhanced Other Network
Stations that offer <Enhanced Other
Network> also transmit information about
other RDS stations that have traffic
information. When you are tuned to a station
that is not transmitting traffic information, but
another RDS station starts transmitting a
traffic bulletin, the tuner automatically
switches to the other station for the duration
of the bulletin.
Alarm
When an emergency transmission (announcing
disasters, etc.) is sent, all current functions are
interrupted to allow the warning to be
received.
About RDS
Reset button
KDC-Z939(M)_U.S_r2
02.3.11
11:51 AM
Page 4
background image
-- 5 --
About CDs
Handling CDs
· Don't touch the recording surface of the CD.
· CD-R and CD-RW are easier to damage than
a normal music CD. Use a CD-R or a CD-RW
after reading the caution items on the
package etc.
· Don't stick tape etc. on the CD.
Also, don't use a CD with tape stuck on it.
When using a new CD
If the CD center hole or outside rim has burrs,
use it after removing them with a ball pen etc.
CD accessories
Don't use disc type accessories.
CD cleaning
Clean from the center of the disc and move
outward.
Removing CDs
When removing CDs from this unit pull them
out horizontally.
CDs that can't be used
· CDs that aren't round can't be used.
· CDs with coloring on the recording surface
or that are dirty can't be used.
· Don't use CDs without disc mark
.
·A CD-R or CD-RW that hasn't been finalized
can't be played. (For the finalization process
refer to your CD-R/CD-RW writing software,
and your CD-R/CD-RW recorder instruction
manual.)
CD storage
· Don't place them in direct sunlight (On the
seat or dashboard etc.) and where the
temperature is high.
· Store CDs in their cases.
Burrs
Burrs
KDC-Z939(M)_U.S_r2
02.3.11
11:51 AM
Page 5

Reviews

There are no reviews of this manual yet.
