Cover page of KENWOOD DPC-X340 Owner's Manual

Owner's Manual for KENWOOD DPC-X340, downloadable as a PDF file.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 4 pages
  • File size: 0.83 MB
  • Available language versions: Japanese
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
background image
÷
÷
÷
÷
÷
DPC-X340
AP
Precaution for use
This unit is designed for domestic use only, and it is very dangerous to use
the attached AC adaptor abrord. Never use it out of Japan.
Operating instructions
Please refer to the illustrations in the Japanese instruction
when operating this unit. The numbers which appear at the
end of each title are corresponded on each language.
When operating the unit with 2 rechargeable batteries
and 2 alkaline batteries
4
Do not load one rechargeable and one alkaline
batteries together in the same battery case.
Otherwise, battery burst or fluid leak may cause
a fire, injury or damage to the battery case and
its surroundings.
This unit can be operated with 2 rechargeable batteries and
2 alkaline batteries.
÷ When 4 batteries are used, make sure they are arranged
so that batteries of the same type are in line horizontally
(see illustration).
÷ Always use the specially provided rechargeable battery
or a separately sold rechargeable battery NB-3A70.
÷ Exchange the same type of batteries at the same time.
Playback from the first track
5
Connect remote control and headphones.
÷ Accepts the supplied headphones, or other optional
headphones with a mini plug.
1 Slide the OPEN switch in the direction of the arrow
to open the top cover.
2 Insert a disc and close the top cover.
÷ Insert with labeled side up.
÷ Secure the disc by pushing a position near the center
hole unit it clicks.
÷ Close securely by pushing the front center position of
the top cover unit it clicks.
3 Set the HOLD switch to off.
÷ For the Hold function, read "Hold function".
÷ Before any operation, be sure to set the HOLD switch
to off.
4 Press the 38 key.
÷ The power comes on and playback begins.
÷ Certain CD-R/CD-RW (CD-DA) discs may not be played
due to recording conditions of the discs.
÷ The ASP function is activated permanently.
ASP (Anti Skip Protection) :
The audio signals of a certain period is stored in memory so
that, even when the signal from the optical pickup is
interrupted by an external shock, this unit can continue
music without interruption.
5 Use the VOL knob to adjust the volume.
7 To pause playback temporarily
Press the
38 key during playback states.
÷ Pressing the key again resumes playback.
7 To stop playback
Press the
7 key during playback states.
÷ The total number of tracks and the total playing time of
them will be displayed.
7 To turn power Off
After stopping playback, press the
7 key again.
Auto power-Off function:
If no operation key has been pressed for 30 seconds
while the unit is in the stop mode, the power is turned Off
automatically to prevent battery power consumption.
7 Selection by track skip
Press the
4 or ¢ key.
÷ When the ¢ key is pressed, playback will skip to the
start of the subsequent track.
÷ Each time the key is pressed, playback will skip to the
next track.
÷ When the 4 key is pressed, playback will skip to the
start of the track being played back.
÷ Each time the key is pressed, playback will skip to the
previous track.
7 Fast forward, fast reverse
Hold the
4 key or the ¢ key pressed during
playback.
÷ Fast forward is engaged by pressing and holding down
key
¢ while playback is in progress.
÷ Fast reverse is engaged by pressing and holding down
key
4 while playback is in progress.
÷ Playback resumes from the position where the key is
released.
Power Source
Using the AC adaptor
1
Connect to AC power outlet.
Use the enclosed AC adaptor (AC-45060A) for
this product.
Rechargeable battery operation
2
Note:
Rechargeable batteries are not provided with this unit.
Always use the specially separately NB-3A70. Recharge-
able battery models other than the NB-3A70 may be
unable to be recharged.
Loading the batteries
1 Open the battery cover.
2 Insert 2 or 4 rechargeable batteries and close the
cover.
÷ Make sure the positive (+) and negative (-) poles are
properly aligned.
÷ When using two batteries, these can be loaded in
either battery case.
÷ During battery charging or use of the unit, the battery
may become warm. This is normal and does not indicate
a malfunction.
Charging the rechargeable batteries
1 Plug in the AC adaptor.
2 Press and held the 7 key for more than 1 seconds.
3 After the batteries have been charged, remove the
AC adapter.
÷ When using a rechargeable battery which is new or
which has not been used for more than 2 months, the
operating period may be shorter than normal. This is
due to the properties of the battery and not a
malfunction. After recharging, use the battery on the
unit until it is exhausted. The original performance of
the battery can be recovered by repeating this cycle a
few times.
÷ Make sure to close the top cover of the unit before
proceeding to recharging.
÷ Make sure that no alkaline batteries are loaded in the
battery cases before charging the rechargeable
batteries.
÷ Recharging completes in about 10 hours. Do not attempt
to recharge the batteries after this period.
÷ Rechargeable batteries can be recharged . When the
playable time per recharge reduces, please newly
purchase the optional (NB-3A70) rechargeable batteries.
When operating the unit with alkaline batteries
3
Note:
Alkaline batteries are not provided with this unit.
1 Open the battery cover.
2 Insert 2 or 4 alkaline batteries and close the cover.
÷ Make sure the positive (+) and negative (-) poles are
properly aligned.
÷ When using two batteries, these can be loaded in
either battery case.
÷ Use commercially available LR03 batteries. The unit
may not operate normally if manganese batteries are
used.
÷ Replace 2 or 4 alkaline batteries at the same time.
÷
÷
÷
÷
÷
÷
÷
÷
1
2
3
4
÷
Hold function
Slide the HOLD switch in the direction of the arrow to
switch the HOLD function on.
÷ When the HOLD switch on the unit is switched on, the
unit's keys cannot be operated.
÷ When the HOLD switch on the remote control is switched
on, the remote control's keys cannot be operated.
Changing the tone
The low frequencies sound, which is felt in headphone, can
be boosted.
Slide the DBBS switch to select the desired setting:
1 DBBS on position :
Low frequencies are boosted.
2 DBBS off position :
Normal tone reproduction.
Selecting Play Mode
6
Each press of the MODE key switches the mode as
follows: (Press during playback or stop status)
1 One-track repeat ("
1" lights up)
The track being played or the selected track will be
played repeatedly.
÷ To play the next track repeatedly, press the 4
or
¢ key.
2 All-track repeat ("
ALL" lights up)
All tracks on the disc will be played repeatedly.
3 Intro Scan ("INTRO" lights up)
The disc will then begin playing the first ten seconds of
all tracks once and then stops automatically.
4 Random play ("RAND" lights up)
All tracks on the disc will be played in a random order.
5 Normal playback
÷ If Intro Scan or Random Play is selected while playback
is in progress, Intro Scan or Random Play operation will
commence when the track being played back is over.
÷ If Intro Scan or Random Play is selected during stop,
Intro Scan or Random play will start when the
38 key
is pressed.
÷ The program of tracks is also valid in Repeat or Intro
Scan playback.
Program playback
7
Favorite tracks (max. 20 tracks) can be programmed in the
desired order during stop mode for later playback.
1 Press the PROG key during stop status.
÷ Stop status is engaged when the 7 key is pressed
while playback is in progress.
2 Use the 4 or ¢ key to select track and press the
MODE key.
÷ Repeat steps 2 and enter the track into the program in
order
÷ Up to 20 tracks can be programmed in this unit.
3 Press the 38 key
7 To clear the programmed contents
Press the
7 key
÷ The "PROG" indicator is turned off when the program is
cleared. However, the programmed contents are stored.
÷ Program mode can be canceled when the 7 key is
pressed or the top cover is open while stop status is
engaged. The programmed contents are cleared.
Connections 8
Ensure that the power of the all of the components are off
before connecting the cords.
Speakers with built-in amplifier
Listening through an amplifier (with CD input jack)
÷
÷
÷
÷
÷
÷
÷
÷
÷
÷
÷
04.5.12, 4:00 PM
Page 2-3
background image
÷
÷
÷
÷
÷
DPC-X340
AP
Precaution for use
This unit is designed for domestic use only, and it is very dangerous to use
the attached AC adaptor abrord. Never use it out of Japan.
Operating instructions
Please refer to the illustrations in the Japanese instruction
when operating this unit. The numbers which appear at the
end of each title are corresponded on each language.
When operating the unit with 2 rechargeable batteries
and 2 alkaline batteries
4
Do not load one rechargeable and one alkaline
batteries together in the same battery case.
Otherwise, battery burst or fluid leak may cause
a fire, injury or damage to the battery case and
its surroundings.
This unit can be operated with 2 rechargeable batteries and
2 alkaline batteries.
÷ When 4 batteries are used, make sure they are arranged
so that batteries of the same type are in line horizontally
(see illustration).
÷ Always use the specially provided rechargeable battery
or a separately sold rechargeable battery NB-3A70.
÷ Exchange the same type of batteries at the same time.
Playback from the first track
5
Connect remote control and headphones.
÷ Accepts the supplied headphones, or other optional
headphones with a mini plug.
1 Slide the OPEN switch in the direction of the arrow
to open the top cover.
2 Insert a disc and close the top cover.
÷ Insert with labeled side up.
÷ Secure the disc by pushing a position near the center
hole unit it clicks.
÷ Close securely by pushing the front center position of
the top cover unit it clicks.
3 Set the HOLD switch to off.
÷ For the Hold function, read "Hold function".
÷ Before any operation, be sure to set the HOLD switch
to off.
4 Press the 38 key.
÷ The power comes on and playback begins.
÷ Certain CD-R/CD-RW (CD-DA) discs may not be played
due to recording conditions of the discs.
÷ The ASP function is activated permanently.
ASP (Anti Skip Protection) :
The audio signals of a certain period is stored in memory so
that, even when the signal from the optical pickup is
interrupted by an external shock, this unit can continue
music without interruption.
5 Use the VOL knob to adjust the volume.
7 To pause playback temporarily
Press the
38 key during playback states.
÷ Pressing the key again resumes playback.
7 To stop playback
Press the
7 key during playback states.
÷ The total number of tracks and the total playing time of
them will be displayed.
7 To turn power Off
After stopping playback, press the
7 key again.
Auto power-Off function:
If no operation key has been pressed for 30 seconds
while the unit is in the stop mode, the power is turned Off
automatically to prevent battery power consumption.
7 Selection by track skip
Press the
4 or ¢ key.
÷ When the ¢ key is pressed, playback will skip to the
start of the subsequent track.
÷ Each time the key is pressed, playback will skip to the
next track.
÷ When the 4 key is pressed, playback will skip to the
start of the track being played back.
÷ Each time the key is pressed, playback will skip to the
previous track.
7 Fast forward, fast reverse
Hold the
4 key or the ¢ key pressed during
playback.
÷ Fast forward is engaged by pressing and holding down
key
¢ while playback is in progress.
÷ Fast reverse is engaged by pressing and holding down
key
4 while playback is in progress.
÷ Playback resumes from the position where the key is
released.
Power Source
Using the AC adaptor
1
Connect to AC power outlet.
Use the enclosed AC adaptor (AC-45060A) for
this product.
Rechargeable battery operation
2
Note:
Rechargeable batteries are not provided with this unit.
Always use the specially separately NB-3A70. Recharge-
able battery models other than the NB-3A70 may be
unable to be recharged.
Loading the batteries
1 Open the battery cover.
2 Insert 2 or 4 rechargeable batteries and close the
cover.
÷ Make sure the positive (+) and negative (-) poles are
properly aligned.
÷ When using two batteries, these can be loaded in
either battery case.
÷ During battery charging or use of the unit, the battery
may become warm. This is normal and does not indicate
a malfunction.
Charging the rechargeable batteries
1 Plug in the AC adaptor.
2 Press and held the 7 key for more than 1 seconds.
3 After the batteries have been charged, remove the
AC adapter.
÷ When using a rechargeable battery which is new or
which has not been used for more than 2 months, the
operating period may be shorter than normal. This is
due to the properties of the battery and not a
malfunction. After recharging, use the battery on the
unit until it is exhausted. The original performance of
the battery can be recovered by repeating this cycle a
few times.
÷ Make sure to close the top cover of the unit before
proceeding to recharging.
÷ Make sure that no alkaline batteries are loaded in the
battery cases before charging the rechargeable
batteries.
÷ Recharging completes in about 10 hours. Do not attempt
to recharge the batteries after this period.
÷ Rechargeable batteries can be recharged . When the
playable time per recharge reduces, please newly
purchase the optional (NB-3A70) rechargeable batteries.
When operating the unit with alkaline batteries
3
Note:
Alkaline batteries are not provided with this unit.
1 Open the battery cover.
2 Insert 2 or 4 alkaline batteries and close the cover.
÷ Make sure the positive (+) and negative (-) poles are
properly aligned.
÷ When using two batteries, these can be loaded in
either battery case.
÷ Use commercially available LR03 batteries. The unit
may not operate normally if manganese batteries are
used.
÷ Replace 2 or 4 alkaline batteries at the same time.
÷
÷
÷
÷
÷
÷
÷
÷
1
2
3
4
÷
Hold function
Slide the HOLD switch in the direction of the arrow to
switch the HOLD function on.
÷ When the HOLD switch on the unit is switched on, the
unit's keys cannot be operated.
÷ When the HOLD switch on the remote control is switched
on, the remote control's keys cannot be operated.
Changing the tone
The low frequencies sound, which is felt in headphone, can
be boosted.
Slide the DBBS switch to select the desired setting:
1 DBBS on position :
Low frequencies are boosted.
2 DBBS off position :
Normal tone reproduction.
Selecting Play Mode
6
Each press of the MODE key switches the mode as
follows: (Press during playback or stop status)
1 One-track repeat ("
1" lights up)
The track being played or the selected track will be
played repeatedly.
÷ To play the next track repeatedly, press the 4
or
¢ key.
2 All-track repeat ("
ALL" lights up)
All tracks on the disc will be played repeatedly.
3 Intro Scan ("INTRO" lights up)
The disc will then begin playing the first ten seconds of
all tracks once and then stops automatically.
4 Random play ("RAND" lights up)
All tracks on the disc will be played in a random order.
5 Normal playback
÷ If Intro Scan or Random Play is selected while playback
is in progress, Intro Scan or Random Play operation will
commence when the track being played back is over.
÷ If Intro Scan or Random Play is selected during stop,
Intro Scan or Random play will start when the
38 key
is pressed.
÷ The program of tracks is also valid in Repeat or Intro
Scan playback.
Program playback
7
Favorite tracks (max. 20 tracks) can be programmed in the
desired order during stop mode for later playback.
1 Press the PROG key during stop status.
÷ Stop status is engaged when the 7 key is pressed
while playback is in progress.
2 Use the 4 or ¢ key to select track and press the
MODE key.
÷ Repeat steps 2 and enter the track into the program in
order
÷ Up to 20 tracks can be programmed in this unit.
3 Press the 38 key
7 To clear the programmed contents
Press the
7 key
÷ The "PROG" indicator is turned off when the program is
cleared. However, the programmed contents are stored.
÷ Program mode can be canceled when the 7 key is
pressed or the top cover is open while stop status is
engaged. The programmed contents are cleared.
Connections 8
Ensure that the power of the all of the components are off
before connecting the cords.
Speakers with built-in amplifier
Listening through an amplifier (with CD input jack)
÷
÷
÷
÷
÷
÷
÷
÷
÷
÷
÷
04.5.12, 4:00 PM
Page 2-3
background image
÷
÷
÷
÷
÷
DPC-X340
AP
Precaution for use
This unit is designed for domestic use only, and it is very dangerous to use
the attached AC adaptor abrord. Never use it out of Japan.
Operating instructions
Please refer to the illustrations in the Japanese instruction
when operating this unit. The numbers which appear at the
end of each title are corresponded on each language.
When operating the unit with 2 rechargeable batteries
and 2 alkaline batteries
4
Do not load one rechargeable and one alkaline
batteries together in the same battery case.
Otherwise, battery burst or fluid leak may cause
a fire, injury or damage to the battery case and
its surroundings.
This unit can be operated with 2 rechargeable batteries and
2 alkaline batteries.
÷ When 4 batteries are used, make sure they are arranged
so that batteries of the same type are in line horizontally
(see illustration).
÷ Always use the specially provided rechargeable battery
or a separately sold rechargeable battery NB-3A70.
÷ Exchange the same type of batteries at the same time.
Playback from the first track
5
Connect remote control and headphones.
÷ Accepts the supplied headphones, or other optional
headphones with a mini plug.
1 Slide the OPEN switch in the direction of the arrow
to open the top cover.
2 Insert a disc and close the top cover.
÷ Insert with labeled side up.
÷ Secure the disc by pushing a position near the center
hole unit it clicks.
÷ Close securely by pushing the front center position of
the top cover unit it clicks.
3 Set the HOLD switch to off.
÷ For the Hold function, read "Hold function".
÷ Before any operation, be sure to set the HOLD switch
to off.
4 Press the 38 key.
÷ The power comes on and playback begins.
÷ Certain CD-R/CD-RW (CD-DA) discs may not be played
due to recording conditions of the discs.
÷ The ASP function is activated permanently.
ASP (Anti Skip Protection) :
The audio signals of a certain period is stored in memory so
that, even when the signal from the optical pickup is
interrupted by an external shock, this unit can continue
music without interruption.
5 Use the VOL knob to adjust the volume.
7 To pause playback temporarily
Press the
38 key during playback states.
÷ Pressing the key again resumes playback.
7 To stop playback
Press the
7 key during playback states.
÷ The total number of tracks and the total playing time of
them will be displayed.
7 To turn power Off
After stopping playback, press the
7 key again.
Auto power-Off function:
If no operation key has been pressed for 30 seconds
while the unit is in the stop mode, the power is turned Off
automatically to prevent battery power consumption.
7 Selection by track skip
Press the
4 or ¢ key.
÷ When the ¢ key is pressed, playback will skip to the
start of the subsequent track.
÷ Each time the key is pressed, playback will skip to the
next track.
÷ When the 4 key is pressed, playback will skip to the
start of the track being played back.
÷ Each time the key is pressed, playback will skip to the
previous track.
7 Fast forward, fast reverse
Hold the
4 key or the ¢ key pressed during
playback.
÷ Fast forward is engaged by pressing and holding down
key
¢ while playback is in progress.
÷ Fast reverse is engaged by pressing and holding down
key
4 while playback is in progress.
÷ Playback resumes from the position where the key is
released.
Power Source
Using the AC adaptor
1
Connect to AC power outlet.
Use the enclosed AC adaptor (AC-45060A) for
this product.
Rechargeable battery operation
2
Note:
Rechargeable batteries are not provided with this unit.
Always use the specially separately NB-3A70. Recharge-
able battery models other than the NB-3A70 may be
unable to be recharged.
Loading the batteries
1 Open the battery cover.
2 Insert 2 or 4 rechargeable batteries and close the
cover.
÷ Make sure the positive (+) and negative (-) poles are
properly aligned.
÷ When using two batteries, these can be loaded in
either battery case.
÷ During battery charging or use of the unit, the battery
may become warm. This is normal and does not indicate
a malfunction.
Charging the rechargeable batteries
1 Plug in the AC adaptor.
2 Press and held the 7 key for more than 1 seconds.
3 After the batteries have been charged, remove the
AC adapter.
÷ When using a rechargeable battery which is new or
which has not been used for more than 2 months, the
operating period may be shorter than normal. This is
due to the properties of the battery and not a
malfunction. After recharging, use the battery on the
unit until it is exhausted. The original performance of
the battery can be recovered by repeating this cycle a
few times.
÷ Make sure to close the top cover of the unit before
proceeding to recharging.
÷ Make sure that no alkaline batteries are loaded in the
battery cases before charging the rechargeable
batteries.
÷ Recharging completes in about 10 hours. Do not attempt
to recharge the batteries after this period.
÷ Rechargeable batteries can be recharged . When the
playable time per recharge reduces, please newly
purchase the optional (NB-3A70) rechargeable batteries.
When operating the unit with alkaline batteries
3
Note:
Alkaline batteries are not provided with this unit.
1 Open the battery cover.
2 Insert 2 or 4 alkaline batteries and close the cover.
÷ Make sure the positive (+) and negative (-) poles are
properly aligned.
÷ When using two batteries, these can be loaded in
either battery case.
÷ Use commercially available LR03 batteries. The unit
may not operate normally if manganese batteries are
used.
÷ Replace 2 or 4 alkaline batteries at the same time.
÷
÷
÷
÷
÷
÷
÷
÷
1
2
3
4
÷
Hold function
Slide the HOLD switch in the direction of the arrow to
switch the HOLD function on.
÷ When the HOLD switch on the unit is switched on, the
unit's keys cannot be operated.
÷ When the HOLD switch on the remote control is switched
on, the remote control's keys cannot be operated.
Changing the tone
The low frequencies sound, which is felt in headphone, can
be boosted.
Slide the DBBS switch to select the desired setting:
1 DBBS on position :
Low frequencies are boosted.
2 DBBS off position :
Normal tone reproduction.
Selecting Play Mode
6
Each press of the MODE key switches the mode as
follows: (Press during playback or stop status)
1 One-track repeat ("
1" lights up)
The track being played or the selected track will be
played repeatedly.
÷ To play the next track repeatedly, press the 4
or
¢ key.
2 All-track repeat ("
ALL" lights up)
All tracks on the disc will be played repeatedly.
3 Intro Scan ("INTRO" lights up)
The disc will then begin playing the first ten seconds of
all tracks once and then stops automatically.
4 Random play ("RAND" lights up)
All tracks on the disc will be played in a random order.
5 Normal playback
÷ If Intro Scan or Random Play is selected while playback
is in progress, Intro Scan or Random Play operation will
commence when the track being played back is over.
÷ If Intro Scan or Random Play is selected during stop,
Intro Scan or Random play will start when the
38 key
is pressed.
÷ The program of tracks is also valid in Repeat or Intro
Scan playback.
Program playback
7
Favorite tracks (max. 20 tracks) can be programmed in the
desired order during stop mode for later playback.
1 Press the PROG key during stop status.
÷ Stop status is engaged when the 7 key is pressed
while playback is in progress.
2 Use the 4 or ¢ key to select track and press the
MODE key.
÷ Repeat steps 2 and enter the track into the program in
order
÷ Up to 20 tracks can be programmed in this unit.
3 Press the 38 key
7 To clear the programmed contents
Press the
7 key
÷ The "PROG" indicator is turned off when the program is
cleared. However, the programmed contents are stored.
÷ Program mode can be canceled when the 7 key is
pressed or the top cover is open while stop status is
engaged. The programmed contents are cleared.
Connections 8
Ensure that the power of the all of the components are off
before connecting the cords.
Speakers with built-in amplifier
Listening through an amplifier (with CD input jack)
÷
÷
÷
÷
÷
÷
÷
÷
÷
÷
÷
04.5.12, 4:00 PM
Page 2-3
background image
8
÷
÷
LINE OUT
]
]
]
]
]
]
]
]
]
]
]
]
]
]
]
]
÷
7
38/7
PROG
MODE
PROG
VOL
1
÷
7
2 4 ¢
PROG
ASP
÷
2
÷
3 38
7
÷
÷
7
4
¢
÷
¢
÷
4
÷
÷
÷
÷
6
38
MODE
MODE
PROG
VOL
1
1
÷
4
¢
2
3
4
5
÷
÷
38
÷
HOLD
OPEN
VOL
DBBS
7 / 38
1
2
÷
÷
÷
3
÷
÷
4 38
÷
÷
÷
ASP
5
38
÷
7
÷
7
4
¢
÷¢
÷
÷4
÷
5
DC IN 4.5V
1
2
1
2
÷
÷
÷
÷
÷
÷
÷
÷
1
2 7
3
Å
i
Ç
Î
7
38
MODE
PROG
VOL
Ï
Ì
Î
Åi
Ç
Å
¬
i
Ç
Ì
Ï
Ó
Î
Å
i
38
4 ¢
7
Ç
38/7/4/¢
HOLD
VOL +/-
MODE
PROG
VOL
Ï
Ì
Ó
¬
4
÷
÷
÷
÷
÷
÷
÷
3
1
2
]
]
Ni-MH
Î
Ï
Ì
DBBS
PROG
INTRO
RAND
1ALL HOLD ASP
Å
i
Ç
Î
ÓÌ
Ï
Å
i
Ç
Î
Ï
Ì
Ó
04.5.12, 4:00 PM
Page 4-5
background image
8
÷
÷
LINE OUT
]
]
]
]
]
]
]
]
]
]
]
]
]
]
]
]
÷
7
38/7
PROG
MODE
PROG
VOL
1
÷
7
2 4 ¢
PROG
ASP
÷
2
÷
3 38
7
÷
÷
7
4
¢
÷
¢
÷
4
÷
÷
÷
÷
6
38
MODE
MODE
PROG
VOL
1
1
÷
4
¢
2
3
4
5
÷
÷
38
÷
HOLD
OPEN
VOL
DBBS
7 / 38
1
2
÷
÷
÷
3
÷
÷
4 38
÷
÷
÷
ASP
5
38
÷
7
÷
7
4
¢
÷¢
÷
÷4
÷
5
DC IN 4.5V
1
2
1
2
÷
÷
÷
÷
÷
÷
÷
÷
1
2 7
3
Å
i
Ç
Î
7
38
MODE
PROG
VOL
Ï
Ì
Î
Åi
Ç
Å
¬
i
Ç
Ì
Ï
Ó
Î
Å
i
38
4 ¢
7
Ç
38/7/4/¢
HOLD
VOL +/-
MODE
PROG
VOL
Ï
Ì
Ó
¬
4
÷
÷
÷
÷
÷
÷
÷
3
1
2
]
]
Ni-MH
Î
Ï
Ì
DBBS
PROG
INTRO
RAND
1ALL HOLD ASP
Å
i
Ç
Î
ÓÌ
Ï
Å
i
Ç
Î
Ï
Ì
Ó
04.5.12, 4:00 PM
Page 4-5

Reviews

There are no reviews of this manual yet.
