1 SPECIFICATIONS
2
DVD Player
Signal system ................................................................PAL/NTSC
Laser ......................Semiconductor laser, wavelength 650/790 nm
Frequency range ............................DVD: 4 Hz to 22 kHz (fs:48kHz)
DVD: 4 Hz to 44 kHz (fs:96kHz)
CD: 4 Hz to 20 kHz
Signal-to-noise rating (DVD) ..............................................105 dB
Audio dynamic range (DVD) ..................................................90 dB
Harmonic distortion (DVD) ................................................0.006 %
Wow and flutter ........................................Below measurable level
(less than ± 0.001% (W.PEAK))
Operating conditions ........Temperature: 5°C to 35°C (40°F to 95°F)
Operation status: Horizontal
Outputs
Video output ..............................................................RCA jack x 1
1.0 Vp-p, 75 , negative sync.
S-video output ......................................................S-video jack x 1
(Y) 1.0 Vp-p, 75 , negative sync.
(C) 0.286 Vp-p, 75
Component output ......................................................RCA jack x 1
(Y) 1.0 Vp-p, 75 , negative sync.
(PB, PR) 0.7 Vp-p, 75
Audio output (digital audio) ............RCA jack x 1, 1.15 Vp-p, 75
OPTICAL digital jack x 1
Audio output (analog audio) ............................RCA jack x 1 (2CH)
2.0 Vrms (1 kHz, 0 dB)
RCA jack x 1 (6CH)
General
Power supply ........................................................AC 120 V, 60 Hz
Power consumption ..............................................................18 W
Weight ......................................................................3.3 kg (7.3 lb)
External dimensions (W x H x D) ..................435 x 62 x 327.5 mm
(17-1/8" x 2-7/16" x 12-15/16")
Accessories
Audio cable (RCA) x 1
Video cable (RCA) x 1
Optical cable x 1
Owner's manual x 1
Remote control x 1
Battery (AAA) x 2
AC cord x 1
· Design and specifications are subject to change without notice.
· Weight and dimensions are approximate.
SAFETY INFORMATION
This product has been designed and manufactured according to FDA
regulations "title 21, CFR, chapter 1, subchapter J, based on the Radiation
Control for Health and Safety Act of 1968", and is classified as a class 1
laser product. There is no hazardous invisible laser radiation during
operation because invisible laser radiation emitted inside of this product
is completely confined in the protective housings.
The label required in this regulation is shown 1.
OCAUTION
USE OF CONTROLS OR ADJUSTMENT OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
Optical pickup:
Type
: SF-HD60
Manufacturer
: SANYO Electronics Co., Ltd.
Laser output
: Less than 0.3 mW on the objective lens
Wavelength
: 780 ± 25 nm (CD), 650 ± 15 nm (DVD)
1 For U.S.A.
