Cat. No. 001605
MD 431 II
Microphones | Dynamic Microphone
General Description
By virtue of its design and features, the MD 431 II ranks amongst
Sennheiser's most exceptional microphones and is suitable for vocal,
speech and broadcasting applications. Colour: black.
Features
j Exceptionally good feedback rejection
j Shock mounted capsule provides very good rejection of handling noise
j Hum compensating coil
j Integral pop filter
j On/off switch (reed switch) can be locked in the `ON' position if required
j Delivery includes: 1 MD 431 II
1 MZA 4031 quick release clamp
Recommended Accessories
j MZT 100 table stand
Cat. No. 001883
j MZT 441 table stand
Cat. No. 000799
j MZT 14 mounting bolt
Cat. No. 001895
j MZW 4032 foam windshield
Cat. No. 002978
j MZW 416-1 foam windshield
Cat. No. 001536
Technical Data
Pick-up pattern ...........................................................super-cardioid
Frequency response ................................................. 40 ­ 16,000 Hz
Sensitivity (free field, no load, 1 kHz)................. 2 mV/Pa ± 3 dB
Nominal impedance ................................................................. 250
Min. terminating impedance ..................................................... 1 k
Dimensions ................................... Ø 49 x 200 mm, body Ø 31 mm
Weight ...........................................................................approx. 250 g
Cable pictured is an accessory not supplied with the microphone
Profile
Super-cardioid stage microphone, hum compensating coil,
integral popshield, reed on/off switch, frequency response
40 ­ 16,000 Hz, sensitivity (free field, no load) 2 mV/Pa
± 3 dB at 1 kHz, nominal impedance 250
, min. terminating
impedance 1 k
, dimensions Ø 49 x 200 mm, body Ø 31 mm,
weight approx. 250 g.
