Cleaning the headphones
To clean the headphones, use a soft, damp cloth. If necessary, the headphones can be cleaned with
a cloth that has been dipped in soapy water (use a mild cleanser such as washing-up liquid).
Do not immerse the headphones in water or allow the capsules to become wet.
Never use solvent-containing cleansers.
Available accessories and spare parts
Replacing the ear cushions
Grasp behind the ear cushions and pull them up and away from the earcups.
Slide the new ear cushions onto the earcups.
Replacing the headband padding
Pull the Ziploc type fastening strips of the headband padding apart, as shown in the diagram
on the left, and remove the worn headband padding.
Put the new headband padding around the headband.
Pull the two edges of the headband padding together so that the fastening strips slightly
Join the fastening strips.
Replacing the connecting cable
Remove the ear cushion. Grasp behind the ear cushion and pull it up and away from the earcup.
Loosen the screw
and remove it.
Remove the cover from the earcup
Pull the connector
out of the socket.
Remove the strain relief of the connecting cable from the holding device
Insert the strain relief of the new connecting cable into the holding device.
Plug the connector
of the new connecting cable into the socket as shown in the diagram on
Put the cover back onto the earcup
Replace the screw
and tighten it.
Slide the ear cushion onto the earcup.
