AUDIO/VIDEO MULTI-CHANNEL
RECEIVER
VSX-49TXi
Operating Instructions
background image
AUDIO/VIDEO MULTI-CHANNEL
RECEIVER
VSX-49TXi
Operating Instructions
background image
2
IMPORTANT NOTICE
H006AEn
The serial number for this equipment is located in the
rear panel. Please write this serial number on your
enclosed warranty card and keep it in a secure area. This
is for your security.
Thank you for buying this Pioneer product.
Please read through these operating instructions
so you will know how to operate your model
properly. After you have finished reading the
instructions, put them away in a safe place for
future reference.
background image
3
background image
4
Selecting fine audio equipment such as the unit you've
just purchased is only the start of your musical enjoyment.
Now it's time to consider how you can maximize the fun
and excitement your equipment offers. This manufacturer
and the Electronic Industries Association's Consumer
Electronics Group want you to get the most out of your
equipment by playing it at a safe level. One that lets the
sound come through loud and clear without annoying
blaring or distortion-and, most importantly, without
affecting your sensitive hearing.
Sound can be deceiving. Over time your hearing
"comfort level" adapts to higher volumes of sound. So
what sounds "normal" can actually be loud and harmful
to your hearing. Guard against this by setting your
equipment at a safe level BEFORE your hearing adapts.
To establish a safe level:
· Start your volume control at a low setting.
· Slowly increase the sound until you can hear it
comfortably and clearly, and without distortion.
Once you have established a comfortable sound level:
· Set the dial and leave it there.
Taking a minute to do this now will help to prevent
hearing damage or loss in the future. After all, we want
you listening for a lifetime.
EST 1924
EIA
E
L
E
C
T
R
O
N I
C
I N D
U
S
T
R
IE
S
·
A
S
S O
C I A T
I O
N
·
We
Want You
LISTENING
For A Lifetime
We Want You Listening For A
Lifetime
Used wisely, your new sound equipment will provide a
lifetime of fun and enjoyment. Since hearing damage from
loud noise is often undetectable until it is too late, this
manufacturer and the Electronic Industries Association's
Consumer Electronics Group recommend you avoid
prolonged exposure to excessive noise. This list of sound
levels is included for your protection.
Decibel
Level
Example
30
Quiet library, soft whispers
40
Living room, refrigerator, bedroom away from
traffic
50
Light traffic, normal conversation, quiet office
60
Air conditioner at 20 feet, sewing machine
70
Vacuum cleaner, hair dryer, noisy restaurant
80
Average city traffic, garbage disposals, alarm clock
at two feet.
THE FOLLOWING NOISES CAN BE
DANGEROUS UNDER CONSTANT EXPOSURE
90
Subway, motorcycle, truck traffic, lawn mower
100
Garbage truck, chain saw, pneumatic drill
120
Rock band concert in front of speakers, thunderclap
140
Gunshot blast, jet plane
180
Rocket launching pad
Information courtesy of the Deafness Research Foundation.
EST 1924
EIA
E
L
E
C
T
R
O
N I
C
I N D
U
S
T
R
IE
S
·
A
S
S O
C I A T
I O
N
·
We
Want You
LISTENING
For A Lifetime
Power cord CAUTION!
Handle the power cord by the plug. Do not pull out the plug by tugging the cord and never touch the power cord
when your hands are wet as this could cause a short circuit or electric shock. Do not place the unit, a piece of
furniture, etc., on the power cord, or pinch the cord. Never make a knot in the cord or tie it with other cords. The
power cords should be routed such that they are not likely to be stepped on. A damaged power cord can cause
a fire or give you an electrical shock. Check the power cord once in a while. When you find it damaged, ask your
nearest PIONEER authorized service center or your dealer for a replacement.
background image
5
PREP
ARA
TION
PREP
ARA
TION
PREP
ARA
TION
Features
Advanced Multichannel Stereophonic Concept
The VSX-49TXi receiver is constructed with Pioneer's industry-leading advanced multichannel stereophonic
concept. This means it is designed to reproduce music and movie soundtracks as close as possible to the
intentions of the producer during mastering. The receiver uses a revolutionary 3-D Frame Construction
technique and a Symmetrical Power Train Design, with high-performance Advanced Direct Energy MOS-FET
output devices, generating 160 watts (FTC 6
) of power for 7 independent channels. True 32-bit Tri Digital Signal
Processing is used for ultra realistic sound.
i.LINK Digital Interface
The i.LINK interface makes it possible to connect the receiver to i.LINK-equipped components such as a DVD
player with a single cable and enjoy multichannel digital audio from SACD and DVD-A discs (if the player is
compatible with these outputs), as well as digital audio from DVD-Video, CD and Video CD discs.
In addition to simplified connection, jitterless audio is possible with Pioneer's PQLS* technology when playing
audio CDs and SACDs. By supressing jitter, deterioration of audio quality is minimized and digital audio of the
highest quality is realized.
*PQLS (Precision Quartz Lock System) [rate control]
Technology for high-precision transmission of digital audio over the i.LINK interface enabling jitterless
digital-to-analog conversion using a precision quartz in this receiver.
To make this feature work, it is only necessary that this receiver and one rate-control-compatible player are
alive on the i.LINK network.
Other advantages of using i.LINK include `smart' features such as automatic configuration and automatic
function selection--start playback on a i.LINK-equipped component and the receiver automatically selects the
component for input.
"i.LINK" and the i.LINK logo are trademarks of Sony Corporation.
Multi-Channel Acoustic Calibration System (MCACC)
In order to make setting up as easy as possible for users we have created the MCACC system. This unique and
convenient way of getting good surround sound from the receiver makes trouble-free setup a snap. With the
included microphone plugged into the front panel the MCACC system creates a monitoring environment to establish
the parameters of the sound for the specific room you are using. The MCACC system adjusts the parameters to
establish excellent surround sound effects and offers you studio quality home theater sound with minimum effort.
Universal Player Compatibility (DVD Audio)
This receiver features eight discrete channels of analog inputs, each with 96kHz/24bit A/D converters. This
makes it ideal for use with all audio formats, including DVD-A, and allows very high quality digital processing.
Furthermore, using the MCACC system you can setup this receiver for optimal DVD-A playback.
Next Generation THX Standards and New Digital Formats
The VSX-49TXi is THX Ultra2 certified. Among the new THX technologies is ASA (Advanced Speaker Array),
which can process any 5.1 channel source for 7.1 channel playback (THX Ultra2 Cinema and THX MusicMode), or
6.1 channel playback (THX Surround EX). THX technologies are also available when listening through an i.LINK
interface. Naturally, you can also play all existing audio formats, including the recently developed Dolby Digital
Surround EX, Dolby Pro Logic II, DTS 96/24 soundtracks and DTS-ES Extended Surround formats. On the video
side, the component video output is fully compatible with high definition, progressive-scan digital video (720p).
Manufactured under license from Dolby Laboratories.
"Dolby", "Pro Logic", "Surround EX" and double-D
symbol are trademarks of Dolby Laboratories.
"DTS", "DTS-ES Extended Surround" and "Neo:6" are
trademarks of Digital Theater Systems, Inc.
Lucasfilm and THX are trademarks or registered
trademarkes of Lucasfilm Ltd. & TM. Surround EX is a
jointly developed technology of THX and Dolby
Laboratories and is a trademark of Dolby Laboratories.
All rights reserved. Used under authorization.
Pioneer Video Converter
The Pioneer Video Converter allows more flexibility in hooking up video components as you can use a wide
range of cords interchangeably.
The Energy-saving Design
This receiver is designed to use 0.65 W of energy when in standby mode.
