Cover page of PIONEER S-ST330/XJM/E Service Manual

Service Manual for PIONEER S-ST330/XJM/E, downloadable as a PDF file.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 5 pages
  • File size: 0.42 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2007
Front
Surround
Center
S-ST330
RRV3690
SPEAKER SYSTEM
S-ST330
XJM/E
" All of service parts except Packing Case are compatible with S-ST330/XJC/E.
1. REASSEMBLY AND DISASSEMBLY PRECAUTIONS
1.1 FRONT / SURROUND / CENTER SPEAKERS
GRILLE ASSY
The grille assy is attached to the cabinet by 4 external screws.
To detach it, unfasten those screws.
SPEAKER UNIT
The speaker unit, together with the grille assy, is attached to the
cabinet by 4 external screws.
To detach it, first unfasten those screws. Next remove the cabinet.
Then remove the cable.
When re-attaching it, face its terminal downward.
T-ZZA OCT. 2007 printed in Japan
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2007
Front
Surround
Center
S-ST330
RRV3690
SPEAKER SYSTEM
S-ST330
XJM/E
" All of service parts except Packing Case are compatible with S-ST330/XJC/E.
1. REASSEMBLY AND DISASSEMBLY PRECAUTIONS
1.1 FRONT / SURROUND / CENTER SPEAKERS
GRILLE ASSY
The grille assy is attached to the cabinet by 4 external screws.
To detach it, unfasten those screws.
SPEAKER UNIT
The speaker unit, together with the grille assy, is attached to the
cabinet by 4 external screws.
To detach it, first unfasten those screws. Next remove the cabinet.
Then remove the cable.
When re-attaching it, face its terminal downward.
T-ZZA OCT. 2007 printed in Japan
background image
S-ST330
2
12
34
1
234
C
D
F
A
B
E
2. EXPLODED VIEWS AND PARTS LIST
2.1 PACKING
PACKING Parts List
NOTES : · Parts marked by " NSP " are generally unavailable because they are not in our Master Spare Parts List.
· The
> mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
14
Accesorry Set B
Accesorry Set A
1
2
12
12
3
13
Accesorry Set B
Accesorry Set A
11
(x2)
(x8)
15
(x2)
-1
-2
Mark No.
Description
Part No.
NSP 1
Front Speaker
SMW6267
NSP 2
Center Speaker
SMW6268
NSP 3
Surround Speaker
SMW6269
4
Speaker Cable (FL: White)
SDS6052
5
Speaker Cable (FR: Red)
SDS6053
6
Speaker Cable (SL: Blue)
SDS6054
7
Speaker Cable (SR: Gray)
SDS6055
8
Speaker Cable (C: Green)
SDS6056
9
Non Skid Pad (Small)
SEP6036
10
Screw (for Mounting Bracket)
BMZ50P120FTB
11
Spiral Wrap
SEP6035
12
Protector
SHA6161
13
Protection Sheet
SHC6074
14
Packing Case
SHG6331
15
Bracket
SXG6024
Mark No.
Description
Part No.
background image
S-ST330
3
56
7
8
56
7
8
C
D
F
A
B
E
2.2 SPEAKER SYSTEM (FRONT)
SPEAKER SYSTEM (FRONT) Parts List
Model Label
Absorbent
Plastic Cap
Packing
Packing
Logo Badge
Packing
Cabinet
Cosmetic Frame
4
3
5
2
(x 4)
1
6
Mark No.
Description
Part No.
1
Grille Assy
SMG6140
2
Speaker
K77DR55-54C
3
Connecting Cord
SDD6019
4
Input Terminal
SKX6034
5
Screw (for Input Terminal)
BPZ35P080FTC
6
Screw (for Cabinet)
BPZ35P110FTB
background image
S-ST330
4
12
34
1
234
C
D
F
A
B
E
2.3 SPEAKER SYSTEM (CENTER and SURROUND)
SPEAKER SYSTEM (CENTER and SURROUND) Parts List
Model Label
Absorbent
Plastic Cap
Packing
Packing
Packing
Cabinet
Cosmetic Frame
4
3
5
2
(x 4)
1
6
Mark No.
Description
Part No.
1
Grille Assy
SMG6139
2
Connecting Cord
SDD6019
3
Input Terminal
SKX6034
4
Speaker (for Center)
K77DR55-58F
4
Speaker (for Surround)
K77DR55-54C
5
Screw (for Input Terminal)
BPZ35P080FTC
6
Screw (for Cabinet)
BPZ35P110FTB
background image
S-ST330
5
56
7
8
56
7
8
C
D
F
A
B
E
3. SCHEMATIC DIAGRAM
Connecting Cord (SDD6019)
INPUT
Speaker
White
Red
