1
En
S -MS500CR
SPEAKER SYSTEM
OPERATING GUIDE
SISTEMA DE ALTAVOCES
GUÍA DE OPERACIÓN
BEFORE OPERATION
· Thank you for buying this PIONEER product.
· Read the operating instructions carefully before using these
speakers so that you can operate them properly. After you have
finished reading the instructions, put them away in a safe place for
future reference.
· The rated impedance of these speakers is 8
. They must be
connected to a stereo amplifier which accepts this type of load
(miminum and maximum impedances accepted by the amplifier are
generally indicated near the loudspeaker outlets: for example "4-16
" or "6-16 ").
· To guard against damage to these speakers due to an electric
power overload, take the following precaustions:
] Do not supply more than the maximum permitted power to the
speakers (see Specifications).
] Any connection or switching on or off of part of the audio
system (CD player, tuner etc.) must be carried out after
switching off the amplifier or at least with the loudspeaker
outlets disconnected (if the amplifier allows). Interference
caused by these operations will otherwise reach the speakers
and may damage the treble loudspeaker units.
] When boosting particular frequencies using a graphic equaliser
or bass and treble controls, make sure that you do not increase
the amplifier volume excessively, as the speakers will be
overloaded more quickly.
] Do not force a low-power amplifier to produce a high level of
sound as harmonic distortion increases rapidly in this situation
and may pose a danger to the treble loudspeaker units.
· Avoid touching the diaphragms and suspensions of loudspeakers as
they are fragile.
The loudspeaker units in these speakers are magnetically shielded.
However, colours may blur if the speakers are positioned too close
to a television screen. If this happens, switch off the television and
switch it back on again after 15 to 30 minutes. If the problem
persists, move the speakers away from the television set.
INSTALLATION PRECAUTIONS
· Do not install these speakers close to an oven or heating appliance.
Avoid exposing them to direct sunlight. High temperatures can
distort the structure of the enclosure and adversely affect the
sound.
· These speakers are heavy and fragile, and it is therefore dangerous
to install them in an unstable position.
· For optimum effect, install the rear speakers slightly above ear
level. Install the senter speaker above or below the TV so that the
sound of the center channel is localized at the TV screen. For low
frequencies, it is possible to increase the level of bass sounds by
positioning the speakers close to a wall (the maximum increase
being obtained for a position in a corner of the listening room).
CONNECTIONS
Each speaker has two terminals; one red (+), the other black (­).
These need to be matched up to the red and black terminals on the
amplifier for proper stereo sound.
1. Make sure your amplifier is switched off.
2. Strip the insulation at the tip of the cord and twist the strands.
3. Connect one end of the speaker cord to the speaker terminals.
Depress the input terminal lever, and insert the tip of the cord into
the hole and then release the lever so that it springs back into
position.
4. Connect the other end of the speaker cord to the amplifier terminals.
Make sure that the red amplifier terminal is connected to the red
speaker terminal, and the black amplifier terminal is connected to
the black speaker terminal.
REMARKS:
·
Check that the cables are securely connected to the terminals. A
loose connection may cause not just intermittent or distorted sound
but short-circuiting and breakdown of the amplifier.
·
If the cables of one of the speakers have been connected with the
wrong polarities, you will find when listening to a stereo recording
that bass sounds are weakened and the stereo effect normally
obtained between the two speakers does not exist.
MAINTENANCE OF THE ENCLOSURE
· Use a cloth to wipe away dust and dirt.
· If the enclosure is very dirty, wipe with a soft cloth dipped in a
neutral detergent diluted five to six times with water, then wipe
again with the dry cloth. Do not use thinner, benzene, cleaning
sprays or other chemical products on or near the enclosures as the
surfaces could be adversely affected.
SPECIFICATIONS
Enclosure ........................................................ bass-reflex compact type
(magnetically shielded)
System
Center speaker ............................... 1-way, 2 loudspeaker units
Surround speaker .............................. 1-way, 1 loudspeaker unit
Loudspeaker units ........................................................ 10 cm cone type
Nominal impedance ........................................................................... 8
Frequency range
Center speaker ................................................... 60 ­ 20000 Hz
Surround speaker ................................................ 60 ­ 20000 Hz
Sensitivity ....................................................... 88 dB/W at 1 m distance
Maximum power
Center speaker ................................................................ 120 W
Surround speaker ............................................................. 120 W
External dimensions
Center speaker .................... 350 X 130 X 140 mm (W X H X D)
Surround speaker ................. 180 X 130 X 140 mm (W X H X D)
Weight
Center speaker ................................................................. 2.5 kg
Surround speaker .............................................................. 1.3 kg
Accessories
Speaker cords ........................................................................................ 3
Operating instructions
REMARK:
The specifications and design of this product are subject to change
without notice, in the interests of improvements.
Published by Pioneer Corporation.
Copyright © 2005 Pioneer Corporation.
All rights reserved.
English
This system is comprised of 1 center speaker and 2 surround speakers.
