1
www.pioneerelectronics.com
IMPORTANT:
The serial number for this equipment is located on the rear of the
subwoofer. Please write this serial number on the warranty page
and keep it in a secure area for future reference.
BEFORE USE
·
Thank you for buying this Pioneer product.
·Please read through this operating guide before using your
speaker system to optimize performance.
FRONT / CENTER / REAR SPEAKERS
FRONT / CENTER / REAR SPEAKERS
·
The nominal impedance of this speaker system is 8 ohms.
Connect the speaker system to a AV amplifier with a load
impedance rating ranging from 4 to 16 ohms
·In order to prevent damage to the speaker system resulting
from input overload, please observe the following precau-
tions:
·Do not supply signal to the speaker system in excess of the
maximum permissible input.
·
When connecting or disconnecting cables, be sure amplifier
power is OFF.
·Do not use excessive amplifier volume if using a tone control
to emphasize high or low frequencies.
INSTALLATION PRECAUTIONS
·Do not install these units near a stove or other heating
appliance, or put them in a place exposed to the sun. Such
locations may cause the cabinet to change color and the
speaker system to break down.
·If mounting to walls, examine them to confirm that their
strength is sufficient to bear the weight of the speaker system.
·
This system is not provided with any hardware for installa-
tion, so select suitable components corresponding to the
construction of your walls.
·If you are unsure of the quality and strength of the walls,
consult a professional for advice.
CAUTION:
Pioneer will not be responsible for any accidents or damage that
may result from improper installation.
·
The front and center speakers are magnetically shielded
for use near your television. However, in some cases, if
the speaker system is installed extremely close to the
screen of a television set, color distortion may occur. If this
happens, turn off the power switch of the television set,
and turn it on after 15 to 30 minutes. If the problem persists,
place the speaker system away from the television set.
POWERED SUBWOOFER
·
Do not place a TV set on top of the cabinet.
·
Do not spill liquid on the cabinet.
·
Place the subwoofer at least 8 inches from any wall or curtain
in order to avoid heat build-up.
CAUTION:
Do not remove the front plastic cover. This should be performed
by a qualified technician.
Do not attempt to reach the amplifier or speaker driver through
the front openings.
CAUTION
CONTENTS
ACCESSORIES
FRONT LEFT
SPEAKER WIRE
FRONT RIGHT
SPEAKER WIRE
REAR RIGHT
SPEAKER WIRE
RCA CABLE
OPERATING GUIDE
SUBWOOFER
RISK OF ELECTRIC SHOCK
DO NOT OPEN
NON SKID PADS
CENTER
SPEAKER WIRE
OPERATING GUIDE
HOME THEATER
S-FCRW240L-S
LOUDSPEAKER SYSTEM
REAR LEFT
SPEAKER WIRE
FRONT SPEAKERS
CENTER SPEAKER
REAR SPEAKERS
