PIONEER S-DV88SW/NVXJI Service Manual

Cover page of PIONEER S-DV88SW/NVXJI Service Manual

Service Manual for PIONEER S-DV88SW/NVXJI, downloadable as a PDF file.

We also have owner's manual to this model.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 32 pages
  • File size: 2.22 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2001
c
RRV2474
T ­ ZZR JUNE 2001 Printed in Japan
POWERED SUBWOOFER
This product is component of system.
Component
System
Service Manual
Remarks
DVD SURROUND SYSTEM
DVD/CD TUNER
XV-DV88
RRV2480
POWERED SUBWOOFER
S-DV88SW
RRV2474
This service manual
S-DV88ST
RRV2486
1. SAFETY INFORMATION .............................................................................. 2
2. EXPLODED VIEWS AND PARTS LIST ........................................................ 4
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ...................................... 10
4. PCB CONNECTION DIAGRAM .................................................................. 20
5. PCB PARTS LIST ....................................................................................... 28
6. ADJUSTMENT ............................................................................................ 30
7. GENERAL INFORMATION ........................................................................ 31
7.1 DISASSEMBLY .................................................................................... 31
8. SPECIFICATIONS ...................................................................................... 32
CONTENTS
S-DV88SW
SATELLITE SPEAKER
Type
Model
Power Requirement
Remarks
S-DV88SW
MYXJI
AC220-230V
NVXJI
AC230V
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2001
c
RRV2474
T ­ ZZR JUNE 2001 Printed in Japan
POWERED SUBWOOFER
This product is component of system.
Component
System
Service Manual
Remarks
DVD SURROUND SYSTEM
DVD/CD TUNER
XV-DV88
RRV2480
POWERED SUBWOOFER
S-DV88SW
RRV2474
This service manual
S-DV88ST
RRV2486
1. SAFETY INFORMATION .............................................................................. 2
2. EXPLODED VIEWS AND PARTS LIST ........................................................ 4
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ...................................... 10
4. PCB CONNECTION DIAGRAM .................................................................. 20
5. PCB PARTS LIST ....................................................................................... 28
6. ADJUSTMENT ............................................................................................ 30
7. GENERAL INFORMATION ........................................................................ 31
7.1 DISASSEMBLY .................................................................................... 31
8. SPECIFICATIONS ...................................................................................... 32
CONTENTS
S-DV88SW
SATELLITE SPEAKER
Type
Model
Power Requirement
Remarks
S-DV88SW
MYXJI
AC220-230V
NVXJI
AC230V
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
background image
2
S-DV88SW
1. SAFETY INFORMATION
This service manual is intended for qualified service technicians ; it is not meant for the casual do-it-
yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained
to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to cause
cancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 ­ Proposition 65
NOTICE
(FOR CANADIAN MODEL ONLY)
Fuse symbols
(fast operating fuse) and/or
(slow operating fuse) on PCB indicate that replacement parts must
be of identical designation.
REMARQUE
(POUR MODÈLE CANADIEN SEULEMENT)
Les symboles de fusible
(fusible de type rapide) et/ou
(fusible de type lent) sur CCI indiquent que les pièces
de remplacement doivent avoir la même désignation.
ANY MEASUREMENTS NOT WITHIN THE LIMITS
OUTLINED ABOVE ARE INDICATIVE OF A POTENTIAL
SHOCK HAZARD AND MUST BE CORRECTED BEFORE
RETURNING THE APPLIANCE TO THE CUSTOMER.
2. PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in the appliance
have special safety related characteristics. These are
often not evident from visual inspection nor the protection
afforded by them necessarily can be obtained by using
replacement components rated for voltage, wattage, etc.
Replacement parts which have these special safety
characteristics are identified in this Service Manual.
Electrical components having such features are identified
by marking with a
on the schematics and on the parts list
in this Service Manual.
The use of a substitute replacement component which does
not have the same safety characteristics as the PIONEER
recommended replacement one, shown in the parts list in
this Service Manual, may create shock, fire, or other hazards.
Product Safety is continuously under review and new
instructions are issued from time to time. For the latest
information, always consult the current PIONEER Service
Manual. A subscription to, or additional copies of, PIONEER
Service Manual may be obtained at a nominal charge from
PIONEER.
1. SAFETY PRECAUTIONS
The following check should be performed for the
continued protection of the customer and service
technician.
LEAKAGE CURRENT CHECK
Measure leakage current to a known earth ground (water
pipe, conduit, etc.) by connecting a leakage current tester
such as Simpson Model 229-2 or equivalent between the
earth ground and all exposed metal parts of the appliance
(input/output terminals, screwheads, metal overlays, control
shaft, etc.). Plug the AC line cord of the appliance directly
into a 120V AC 60Hz outlet and turn the AC power switch
on. Any current measured must not exceed 0.5mA.
(FOR USA MODEL ONLY)
Leakage
current
tester
Reading should
not be above
0.5mA
Device
under
test
Test all
exposed metal
surfaces
Also test with
plug reversed
(Using AC adapter
plug as required)
Earth
ground
AC Leakage Test
background image
3
S-DV88SW
WARNING!
Lithium batteries. Danger of explo-
sion. Replacement must be done by
qualified personnel and only by fol-
lowing the instructions given in the
service manual.
This warning is stated on the product or in
the operating instructions. When replacing the
lithium batteries, follow the note below.
Dispose of the used battery promptly. Keep
away from children. Do not disassemble and
do not dispose of in fire.
The battery used in this device may present a
fire or chemical hazard if mistreated. Do not
recharge, disassemble, heat above 100
°C or
incinerate. Replace only with the same Part
Number. Use of another battery may present a
risk of fire or explosion.
Note: The lithium battery installation po-
sition is shown in the exploded views.
ADVARSEL!
Lithiumbatteri
- Eksplosionsfare ved
fejlagtig håndtering. Udskiftning må
kun ske med batteri af samme fabrikat
og type. Levér det brugte batteri tilbage
til leverandøren.
Denne advarsel or angivet på produktet
eller i brugsvejledningen. Ved udskiftning
af lithium batterierne følges nedenstående
anveisning.
Batterierne må kun udskiftes med batteri-
er af samme type og mærke.
LITHIUM BATTERY NOTICE
background image
4
S-DV88SW
1
21
33
18
2
5
3
19
16
4(2/2)
4(1/2)
23
22
26
24
25
28
31
30
32
20
29
15
17
27
14
13
7
6
10
7
9
8
11
12
6
MYXJI Only
NVXJI Only
2. EXPLODED VIEWS AND PARTS LIST
NOTES:
· Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
· The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
· Screws adjacent to mark on the product are used for disassembly.
2.1 PACKING
background image
5
S-DV88SW
(1) PACKING PARTS LIST
Part No.
Remarks
Mark
S-DV88SW
S-DV88SW
(2) CONTRAST TABLE
S-DV88SW/MYXJI and S-DV88SW/NVXJI are constructed the same except for the following:
2
Packing Case
SHG2341
SHG2380
8
Operating Instructions
ARC7335
Not used
(Dutch/Spanish)
9
Operating Instructions
ARC7340
Not used
(Setting up : Dutch/Spanish)
10
Operating Instructions
ARC7334
Not used
(German/Italian)
11
Operating Instructions
ARC7339
Not used
(Setting up : German/Italian)
12
Operating Instructions
ARC7336
Not used
(Portuguese/Swedish)
13
Operating Instructions
ARC7341
Not used
(Setting up : Portuguese/Swedish)
20
AC Power Cord
ADG1154
ADG1156
NSP
21
Accessary Set
SME3156
SME3235
No.
Symbol and Description
/MYXJI
/NVXJI
1
Poly Bag S6
SHL1292
2
Packig Case
See Contrast table (2)
3
Protector (Top)
SHA2313
4
Protector (Bottom)
SHA2314
5
Protector
SHB1097
6
Operating Instructions
ARE7276
(English/French)
7
Operating Instructions
ARE7280
(Setting up : English/French)
8
Operating Instructions
See Contrast table (2)
(Dutch/Spanish)
9
Operating Instructions
See Contrast table (2)
(Setting up : Dutch/Spanish)
10
Operating Instructions
See Contrast table (2)
(German/Italian)
11
Operating Instructions
See Contrast table (2)
(Setting up : German/Italian)
12
Operating Instructions
See Contrast table (2)
(Portuguese/Swedish)
13
Operating Instructions
See Contrast table (2)
(Setting up : Portuguese/Swedish)
14
FM Antenna
ADH7005
15
AM Loop Antenna
ATB7009
16
Remote Control
AXD7305
NSP
17
Lithium Battery (CR2025)
VEM1011
18
Polyethylene Bag S3
SHL1293
19
Battery Cover
103RRC14701R
20
AC Power Cord
See Contrast table (2)
Mark No.
Description
Part No.
NSP
21
Accessary Set
See Contrast table (2)
22
Speaker Cord(5m:Red)
SDS1115
23
Speaker Cord(5m:White)
SDS1116
24
Speaker Cord(5m:Green)
SDS1117
25
Speaker Cord(10m:Blue)
SDS1118
26
Speaker Cord(10m:Gray)
SDS1119
27
Non-Skid Pads
SEC1541
28
Non-Skid Pads
SEC1563
29
Cord With Plug
VDE1053
30
20P Cable
ADE7079
31
10P Cable
ADE7077
32
12P Cable
ADE7064
33
Packing Case(Accessary)
SHG2342
Mark No.
Description
Part No.

Reviews

There are no reviews of this manual yet.
