Cover page of PIONEER S-C709/XMA/E Service Manual

Service Manual for PIONEER S-C709/XMA/E, downloadable as a PDF file.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 3 pages
  • File size: 0.09 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2000
c
S-C709
RRV2358
T ­ ZZV JULY 2000 Printed in Japan
SPEAKER SYSTEM
XMA/E
FOR PRECAUTION OF
REASSEMBLY AND DISASSEMBLY
The grille is attached to the cabinet by catches. Detach by pull-
ing it toward you.
The eatch Woofer is attached to the baffle by 4 external screws.
To detach it ,unfasten those screws. When attaching it, face its
terminal downward and fit the boss of the Woofer flange back-
side into the hollow on the baffle.
The Tweeter is attached to the baffle by 4 external screws. To
detach it ,unfasten those screws. When attaching it, fit the boss
of the Tweeter flange into the hollow on the baffle.
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2000
c
S-C709
RRV2358
T ­ ZZV JULY 2000 Printed in Japan
SPEAKER SYSTEM
XMA/E
FOR PRECAUTION OF
REASSEMBLY AND DISASSEMBLY
The grille is attached to the cabinet by catches. Detach by pull-
ing it toward you.
The eatch Woofer is attached to the baffle by 4 external screws.
To detach it ,unfasten those screws. When attaching it, face its
terminal downward and fit the boss of the Woofer flange back-
side into the hollow on the baffle.
The Tweeter is attached to the baffle by 4 external screws. To
detach it ,unfasten those screws. When attaching it, fit the boss
of the Tweeter flange into the hollow on the baffle.
background image
S-C709
2
NSP
Cabinet
SMM1867
Grille ASSY
SMG1670
NSP
Badge
SAM1443
NSP
Grille Cloth
SAS1466
NSP
Grille Frame
SMH1005
Network ASSY
SWN1614
Capacitor 1.0
CES41R0KA
Input Terminal Board
SKX1059
NSP
Stamped Model Label
SME3088
NSP
Label Back
SAN2872
NSP
Paper Port Tube
SMR1304
NSP
Absorbent
SMV1953
NSP
Shield Plate
SNE1025
Catch
SNK2002
Speaker (Woofer)
P13DN73-51L
Speaker (Tweeter)
ASY-260A
NSP
Insulation Tape
SEH1037
(for Tweeter-Network Assy)
Screw (for Woofer,Tweeter)
SBA1180
Mark No.
Description
Part No.
For Packing
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The
mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
NOTES:
PARTS LIST
Mark No.
Description
Part No.
NSP
Accessories Set
SME3089
Instruction Manual
SRD1224
(English/Chinese/Spanish/Portuguese)
Speaker Wire
SDS1072
Velcro (Hook)
SED1097
Velcro (Loop)
SED1098
NSP
Polyethylene Bag
SHL-185
Protector
SHA2187
Packing Case
SHG2305
NSP
Packing Bag
SHL1242
Network ASSY (SWN1614)
SCHEMATIC DIAGRAM
Woofer 1
Tweeter
Woofer 2
1.0
µF
Red
Blue
Blue
Red
Black
White
White
White
INPUT
background image
S-C709
3
PRODUCT APPEARANCE
12
11
10
9
8
7
6
6
5
4
2
1
3
RED
WHITE
RED
WHITE
BLUE
WHITE
BLUE
WHITE
WIRING
8
9
10
1
Screw
12
11
Insulating
Tape
2
12
Catch
74
2
2
Woofer
Tweeter
Label
Back
Shield
Plate
Paper
Port
Tube
Network
Assy
Grille
Cabinet
1
1
2
1
1
6
5
4
3
2
1
Part
name
Num.
No.
Part
No.
Part
name
Num.
No.
Part
No.
1
Acoustic
Absorbent
SNE1025
P13DN73-51L
ASY-260A
SMM1867
SMG1670
SBA1180
SEH1037
SWN1614
SAN2872
SMR1304
SMV1953
SNK2002
