PIONEER S-2EX-QL/SXTW/EW5 Service Manual

Cover page of PIONEER S-2EX-QL/SXTW/EW5 Service Manual

Service Manual for PIONEER S-2EX-QL/SXTW/EW5, downloadable as a PDF file.

We also have owner's manual to this model.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 10 pages
  • File size: 1.35 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2006
SPEAKER SYSTEM
S-2EX-QL
XDCN5
S-2EX-WXDCN5
PRT-134
CONTENTS
1. PARTS LIST ................................................................................. 2
2. FOR PRECAUTION OF REASSEMBLY AND DISASSEMBLY ... 5
3. SCHEMATIC DIAGRAM ............................................................... 9
4. JIG .............................................................................................. 10
T ­ ZZS FEB. 2006
NOTE
For better audio quality, the receptacle terminals and terminal fittings of the speaker unit are
soldered. When disassembling/reassembling the speaker unit, be sure to follow the instructions
in this manual. If you will be working on the speaker unit with it turned on its side, lay it on a
piece of soft cloth, etc., to protect the cabinet from being scratched.
Even though the suffix is different between /XDCN5 and /SXTW/EW5,
both models are completely same product.
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2006
SPEAKER SYSTEM
S-2EX-QL
XDCN5
S-2EX-WXDCN5
PRT-134
CONTENTS
1. PARTS LIST ................................................................................. 2
2. FOR PRECAUTION OF REASSEMBLY AND DISASSEMBLY ... 5
3. SCHEMATIC DIAGRAM ............................................................... 9
4. JIG .............................................................................................. 10
T ­ ZZS FEB. 2006
NOTE
For better audio quality, the receptacle terminals and terminal fittings of the speaker unit are
soldered. When disassembling/reassembling the speaker unit, be sure to follow the instructions
in this manual. If you will be working on the speaker unit with it turned on its side, lay it on a
piece of soft cloth, etc., to protect the cabinet from being scratched.
Even though the suffix is different between /XDCN5 and /SXTW/EW5,
both models are completely same product.
background image
2
1
23
4
12
3
4
C
D
F
A
B
E
S-2EX
1. PARTS LIST
7
8
4
9 (x4)
10 (x4)
1
5
3
2
6
22
Speaker system
Serial
number
1.1 PACKING
NOTES :
÷ Parts marked by " NSP " are generally unavailable because they are not in our Master Spare Parts List.
÷ The > mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
NSP
8
Accessory Set (for grille holes)
SME6047
Caps (for grille holes)
SEC2068
Polyethylene Bag S0
SHL1259
9
Speaker Spikes
SBA6053
10
Spike Bases
SLA1057
1
Top Protector
SHA6088
2
Bottom Protector
SHA6089
3
Protection Sheet
SHC1844
4
Protection Sheet
SHC6039
5
Protection Sheet
SHC6043
for S-2EX-QL type
6
Carton Box
SHG6146
for S-2EX-W type
6
Carton Box
SHG6144
NSP
7
Accessory Set
SME6060
NSP
Accessory Set
SME6045
Finishing Screws (for grille) SLH6013
Short Fastening Screws (for grille) SLH6016
Long Fastening Screws (for grille) SLH6017
Polyethylene Bag S0
SHL1259
Operating Instructions
SRD6043
Warranty Card
SRY6029
Polyethylene Bag S2
SHL6012
PACKING Parts List
Mark
No.
Description
Part No.
Mark
No.
Description
Part No.
background image
3
1
23
4
1
2
3
4
C
D
F
A
B
E
S-2EX
Lower side for the LPF input terminals
Upper side for the HPF input terminals
Connect the cords with
white tape to the
midrange unit.
Connect the cords with
black tape to the tweeter.
30
21
39
38
40
(x6 /unit)
34
33
41 (x8)
29
42 (x4)
35 (x4)
A
B
A'
: Refer to the adhesive points on page 7
(30)
A-A' Sectional view
1.2 SPEAKER SYSTEM
for S-2EX-QL type
NSP
21
Cabinet
SMM2031
NSP
Fung Nut M5 (for stand)
SBN1065
NSP
Fung Nut M4 (for grille)
SBN1066
NSP
Fung Nut M6 (for spike)
SBN1068
for S-2EX-W type
NSP
21
Cabinet
SMM2028
NSP
Fung Nut M5 (for stand)
SBN1065
NSP
Fung Nut M4 (for grille)
SBN1066
NSP
Fung Nut M6 (for spike)
SBN1068
29
Network Assy (low pass)
SWN1762
30
Network Assy (high pass)
SWN1763
NSP
33
Gasket (for MID/TW)
SEC2031
NSP
34
Gasket (for WF)
SEC2032
NSP
35
Gasket (cabinet-input terminals) SEC2065
38
Speaker (WF)
B18IU60-52D
39
Speaker (MID/TW)
A14GR55-52DX
Mark
No.
Description
Part No.
SPEAKER SYSTEM Parts List
40
Hexagon Socket Screw
SBA1225
(for WF, MID/TW)
41
Screw (for NW assy)
SBA1260
42
Screw (for closure panel)
SBA1261
NSP
Acoustic Absorbent
SMT1313
(behind chamber, WF)
NSP
Acoustic Absorbent (inside chamber) SMT1314
NSP
Acoustic Absorbent (inside chamber) SMT1316
NSP
Acoustic Absorbent (under chamber) SMT1319
NSP
Acoustic Absorbent
SMT1320
(chamber/holes, input terminals)
NSP
Acoustic Absorbent
SMT1322
(input terminals)
NSP
Acoustic Absorbent
SMT1323
(behind WF, black)
NSP
Acoustic Absorbent
SMT1324
(duct board side, right side board)
NSP
Acoustic Absorbent
SMT1325
(upper short side of duct board)
Mark
No.
Description
Part No.
background image
4
1
23
4
12
3
4
C
D
F
A
B
E
S-2EX
32
32
HPF input (+)
LPF input (+)
HPF input (-)
LPF input (-)
Arrow view B: Detail of the input terminal board
23
24
25
27
28
26
No.22 Grille
Front View
Back View
37
31
43
44
36
The direction of the cord
holes must be vertical.
The direction of the cord
holes must be vertical.
22
Grille
SMG6097
23
Badge
FRAM-048
24
Packing
SEC6060
NSP
25
Grille Assy
SMG6098
NSP
26
Fung Nut
SBN6019
NSP
27
Grille Frame
SMC6004
NSP
28
Punching Net
SNH6015
NSP
31
Stiker
SAN6328
32
Cord
SDS1192
36
Input Terminal (Red)
SKX6027
37
Input Terminal (Black)
SKX6028
SPEAKER SYSTEM Parts List
Mark
No.
Description
Part No.
Mark
No.
Description
Part No.
for S-2EX-QL type
NSP
43
Model Name Plate
SAL6008
for S-2EX-W type
NSP
43
Model Name Plate
SAL6005
NSP
44
Country Label
SAN6327
background image
5
1
23
4
1
2
3
4
C
D
F
A
B
E
S-2EX
3
4
35
5
8.5
4
(4.6)
Screw (SBA1225)
3
4
8.3
2.5
30
4.2
max.
4.2 max.
Screw (SBA1260)
4.2 max.
8.3
3
4
40
2.5
4.2
max.
Screw (SBA1261)
2. FOR PRECAUTION OF REASSEMBLY AND DISASSEMBLY
2.1 GRILLE
How to disassemble
1 Loosen the finishing screws. Then remove the grille.
Note 1:
You may remove the fastening screws if they impede
disassembly.
How to reassemble
Finishing Screws
Finishing
Screws
2 Place the grille with the badge located at the lower part,
aligning the 4 holes of the grille with the fastening screws
inserted in Step
1.
3 Tighten the supplied finishing screws into the fastening
screws to secure the grille.
Note 2:
Do not use a flathead screwdriver or a hexagonal wrench to
tighten the screws. Securing the screws too tightly may
damage the cabinet.
1 Insert the supplied fastening screws (upper: long, lower:
short) into the screw holes at the four corners of the
speaker front.
Fastening
Screws
(long)
Fastening
Screws
(short)
