Cover page of PIONEER RRV2588 Service Manual

Service Manual for PIONEER RRV2588, downloadable as a PDF file.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 4 pages
  • File size: 0.1 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2002
RRV2588
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
T ­ ZZK MAR. 2002 Printed in Japan
Model No.
Order No.
Remarks
VSX-D511/KUXJI
RRV2581
¶ This service manual should be used together with the following manual(s):
AUDIO/VIDEO MULTI-CHANNEL RECEIVER
VSX-D411
VSX-D411-S
Type
Model
Power Requiremen
Remarks
VSX-D411
VSX-D411-S
KUXJI
­­
AC120V
KUXJICA
­­
AC120V
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2002
RRV2588
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
T ­ ZZK MAR. 2002 Printed in Japan
Model No.
Order No.
Remarks
VSX-D511/KUXJI
RRV2581
¶ This service manual should be used together with the following manual(s):
AUDIO/VIDEO MULTI-CHANNEL RECEIVER
VSX-D411
VSX-D411-S
Type
Model
Power Requiremen
Remarks
VSX-D411
VSX-D411-S
KUXJI
­­
AC120V
KUXJICA
­­
AC120V
background image
VSX-D411, VSX-D411-S
2
jp
f
y
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
Part No.
Ref. No. Mark
Symbol and Description
VSX-D511
VSX-D411
VSX-D411-S
Remarks
/KUXJI
/KUXJI
/KUXJICA
PCB ASSEMBLIES
NSP
AMP&PS ASSY
XWK3052
XWK3071
XWK3071
P9 - 7
BOARD TO BOARD ASSY
XWZ3527
Not used
Not used
NSP
COMPLEX ASSY
XWK3037
XWK3070
XWK3070
P9 - 10
S. VIDEO ASSY
XWZ3521
Not used
Not used
P11 - 1
FRONT ASSY
XWZ3492
XWZ3587
XWZ3587
PACKING SECTION
P7 - 13
Packing Case
XHD3200
XHD3209
XHD3219
EXTERIOR SECTION
P9 - 36
Rubber sheet
AEB1111
AEB1111
Not used
P9 - 40
Rear Panel
XNC3139
XNC3164
XNC3164
P9 - 41
Bonnet
XZN3112
XZN3112
XZN3123
Insulator
Not used
Not used
PNW2766
No. 1
Screw
FBT40P080FZK
FBT40P080FZK
FBT40P080FNI
No. 2
NSP
N Label 411/KU
Not used
XAL3110
Not used
*1
FRONT PANEL SECTION
P11 - 6
Front Panel
XMB3060
XMB3061
XMB3086
P11 - 7
Sub Button
XAD3125
XAD3125
XAD3133
P11 - 9
Pioneer Badge
XAM3006
XAM3006
VAM1129
P11 - 11
Select Knob
XAB3023
XAB3023
XAB3024
P11 - 12
Volume Knob
XAB3025
XAB3025
XAB3026
P11 - 13
Power Button
XAD3123
XAD3123
XAD3129
P11 - 14
Sub Panel R5B
XAK3272
XAK3338
XAK3339
P11 - 15
Jog Button
XAD3124
XAD3124
XAD3131
P11 - 18
D Panel R5 W
XAK3274
XAK3342
XAK3342
1. CONTRAST OF MISCELLANEOUS PARTS
CONTRAST TABLE
VSX-D411/KUXJI, VSX-D411-S/KUXJICA and VSX-D511/KUXJI are constructed the same except for the following :
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The
mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to
mark on product are used for disassembly.
Reference Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
560
47k
0.5
1
RD1/4PU
J
RD1/4PU
J
RN2H
K
RS1P
K
56
x 101
47
x 103
R50
1R0
561
473
5.62k
RN1/4PC
F
562
x 101
5621
Notes : For PCB ASSEMBLIES, Refer to "CONTRAST OF PCB ASSEMBLIES" and "2. SCHEMATIC DIAGRAM".
The numbers in the remarks column correspond to the numbers on the " EXPLODED VIEWS ".
*1 Stick N Label on the Rear Panel.
background image
VSX-D411, VSX-D411-S
3
XWZ3587 and XWZ3492 are constructed the same except for the following :
FRONT ASSY
Mark
Symbol and Description
Part No.
Remarks
XWZ3492
XWZ3587
R428
Not used
RS1/16S472J
R429
RS1/16S0R0J
RS1/16S123J
F
O
CONTRAST OF PCB ASSEMBLIES
2
Bonnet
Under Base
2
Screw
BBZ30P080FMC
1
EXPLODED VIEWS (VSX-D411-S/KUXJICA ONLY)
background image
VSX-D411, VSX-D411-S
4
1
23
4
12
3
4
C
D
F
A
B
E
2. SCHEMATIC DIAGRAM
2.1 FRONT ASSY
Note : When ordering service parts, be sure to refer to "EXPLODED VIEWS and PARTS LIST" or "PCB PARTS LIST"
O F
FRONT ASSY
(XWZ3587)
