This service manual is intended for qualified service technicians; it is not meant
for the casual do-it-yourselfer. Qualified technicians have the necessary test
equipment and tools, and have been trained to properly and safely repair complex
products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability
of the product and may void the warranty. If you are not qualified to perform the
repair of this product properly and safely, you should not risk trying to do so and
refer the repair to a qualified service technician.
This product contains lead in solder and certain electrical parts contain chemicals
which are known to the state of California to cause cancer, birth defects or other
Health & Safety Code Section 25249.6 Proposition 65
FOR PRECAUTION OF
REASSEMBLY AND DISASSEMBLY
The grille is attached to the baffle by welding. It is not able to
The woofer is attached to the baffle by 4 internal screws.
To detach it, unfasten those screws. When attaching the
woofer, face its small terminal upward.
The tweeter is attached to the baffle by 2 internal screws.
To detach it, unfasten those screws. When attaching it, face its
The choke coil of the Network Assy is attached to the cabinet
by an internal screw with adhesive. To detach it, unfasten its
