PIONEER PDK-5013/WL6 Owner's Manual

Cover page of PIONEER PDK-5013/WL6 Owner's Manual

Owner's Manual for PIONEER PDK-5013/WL6, downloadable as a PDF file.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 12 pages
  • File size: 0.42 MB
  • Available language versions: French, English, Spanish, Dutch, German, Italian
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
Operating instructions
Mode d'emploi
Bedienungsanleitung
Istruzioni per l'uso
Gebruiksaanwijzing
Manual de instrucciones
HUNG ON WALL UNIT
ECRAN MURAL
WANDBEFESTIGUNGSEINHEIT
UNITA DA PARETE
EENHEID VOOR WANDBEVESTIGING
UNIDAD PARA COLGAR DE LA PARED
PDK-5013
background image
Operating instructions
Mode d'emploi
Bedienungsanleitung
Istruzioni per l'uso
Gebruiksaanwijzing
Manual de instrucciones
HUNG ON WALL UNIT
ECRAN MURAL
WANDBEFESTIGUNGSEINHEIT
UNITA DA PARETE
EENHEID VOOR WANDBEVESTIGING
UNIDAD PARA COLGAR DE LA PARED
PDK-5013
background image
2
Ja
1
3
2
4
background image
3
Ja
1
2
1
2
3
4
5
6
1
2
background image
4
Ja
7
6-6 x 63
17-6 x 120
910
714
1218
98
32
396
15
940
400
455
496
540
120
120
225
150
150
27
135
45
135
45
94.5
682.5
425
(
)
60
2-
background image
5
En
¶ Thank you for purchasing this Pioneer product.
¶ To ensure safe and proper usage, please read the
accompanying Operating Instructions carefully
before using the product.
¶ Keep the Operating Instructions stored in an
accessible place.
Usage Precautions
1. This product is exclusively for use with the plasma display.
2. It should not be used for any other purpose, such as for
holding a plasma display, or remodeled in any way.
3. The installation site should
(a) be strong enough to support the weight of the plasma
display,
(b) not allow people to easily hang from or bump into the
setup,
(c) not be outdoors or in proximity to hot springs or the
ocean, and
(d) not be subjected to vibration or shock.
(e) In addition, a professional construction company
should be consulted in the event that the walls are
not structurally sound enough to permit installation.
(f) Make sure to thoroughly read the Operating
Instructions for the plasma display and heed all other
cautions pertaining to the installation site.
4. Assembly and Installation
(a) Follow the assembly procedure and tighten screws
in all of the specified places.
Failure to do so could cause an unexpected accident,
such as the display breaking or falling down after it
has been installed.
(b) For safety reasons, have two or more people perform
the work.
(c) Prior to starting the work, make sure to turn OFF the
plasma display's main power switch and to unplug
the power plug from its outlet.
Pioneer shall not be liable in any way for any accidents or
damage resulting from other than the specified assembly,
mounting and usage, from remodeling, or from natural
disasters or the like.
Note to Construction Companies
Prior to installing this product, please read Pioneer's
technical manual thoroughly and heed its content.
Installation Work
÷ This product is sold on the premise that it will be installed
by a professional with sufficient technique and skills.
Make sure to request installation and mounting from a
professional construction company or your sales agent.
÷ Pioneer shall not be liable in any way for any accidents
or damage resulting from improper installation or
mounting, incorrect usage, remodeling, natural disasters
or the like.
7 Confirming the parts provided
Before assembly, check to make sure that none of the parts
provided are missing.
* Screws to be used for wall installation are not included.
Obtain them separately.
Prepare a Phillips head (+) screw driver.
5. Do not loosen any of the screws, as doing so could cause
the display to fall down or a similar accident.
6. If you detect any abnormalities or poor performance,
immediately contact a professional construction company
for repairs.
7. As damage that is not readily visible, such as to the interior
of the display's metal fixtures or the parts mounted against
walls, could cause the display to fall down, make sure to
contact a professional construction company for related
inspection when having the display inspected or repaired
or when having interior finishing done.
We recommend having a professional construction
company make periodic inspections, when possible.
8. With long-term use, the display's metal fixtures could lose
their strength, depending on the environment. To promote
problem-free use, we thus recommend having a
professional construction company inspect the installation
every five years, as a rule.
1 Hung on wall unit
2 Bolts M8 (6)
3 Hexagon wrench (1)
(Opposite side 6 mm for M8 use)
4 Stencil
