PIONEER GEX-P900DAB Service Manual

Cover page of PIONEER GEX-P900DAB Service Manual

Service Manual for PIONEER GEX-P900DAB, downloadable as a PDF file.

We also have owner's manual to this model.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 63 pages
  • File size: 5.56 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
PIONEER ELECTRONIC CORPORATION
4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE INC.
P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER ELECTRONIC [EUROPE] N.V.
Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 501 Orchard Road, #10-00, Wheelock Place, Singapore 238880
C PIONEER ELECTRONIC CORPORATION 1998
K-FES. JULY 1998 Printed in Japan
ORDER NO.
CRT2193
HIDE-AWAY DAB TUNER
GEX-P900DAB
EW
CONTENTS
1. SAFETY INFORMATION ............................................2
2. EXPLODED VIEWS AND PARTS LIST .......................2
3. SCHEMATIC DIAGRAM .............................................6
4. PCB CONNECTION DIAGRAM ................................24
5. ELECTRICAL PARTS LIST ........................................28
6. ADJUSTMENT..........................................................35
7. GENERAL INFORMATION .......................................37
7.1 IC ........................................................................37
7.2 TEST MODE........................................................52
7.3 EXPLANATION ...................................................54
7.3.1 CIRCUIT DESCRIPTION ............................54
7.3.2 BLOCK DIAGRAM .....................................59
8. OPERATIONS AND SPECIFICATIONS.....................60
Service
Manual
background image
PIONEER ELECTRONIC CORPORATION
4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE INC.
P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER ELECTRONIC [EUROPE] N.V.
Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 501 Orchard Road, #10-00, Wheelock Place, Singapore 238880
C PIONEER ELECTRONIC CORPORATION 1998
K-FES. JULY 1998 Printed in Japan
ORDER NO.
CRT2193
HIDE-AWAY DAB TUNER
GEX-P900DAB
EW
CONTENTS
1. SAFETY INFORMATION ............................................2
2. EXPLODED VIEWS AND PARTS LIST .......................2
3. SCHEMATIC DIAGRAM .............................................6
4. PCB CONNECTION DIAGRAM ................................24
5. ELECTRICAL PARTS LIST ........................................28
6. ADJUSTMENT..........................................................35
7. GENERAL INFORMATION .......................................37
7.1 IC ........................................................................37
7.2 TEST MODE........................................................52
7.3 EXPLANATION ...................................................54
7.3.1 CIRCUIT DESCRIPTION ............................54
7.3.2 BLOCK DIAGRAM .....................................59
8. OPERATIONS AND SPECIFICATIONS.....................60
Service
Manual
background image
2
GEX-P900DAB
1. SAFETY INFORMATION
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely; you should not risk trying to do so
and refer the repair to a qualified service technician.
2. EXPLODED VIEWS AND PARTS LIST
2.1 PACKING
9
5
11
4
2
3
16
18
8
7
6
6
12
13
10
14
17
15
1
background image
3
GEX-P900DAB
1 Cord
CDE5445
2 Screw
BNC40P120FZK
*
3 Polyethylene Bag
CEG1158
4 Screw
HMF40P060FZK
5 Cord Clamper Assy
CEA2444
6 Cord Clamper
CNV5468
*
7 Polyethylene Bag
E36-615
*
8 Polyethylene Bag
CEG1101
9-1 Owner's Manual
CRD2721
9-2 Owner's Manual
CRD2722
9-3 Installation Manual
CRD2723
*
9-4 Warranty Card
CRY1087
9-5 Fastener(x2)
CNM3728
9-6 Polyethylene Bag
CEG1116
10 Polyethylene Bag
CEG1190
11 Carton
CHG3514
12 Contain Box
CHL3514
13 Protector
CHP2057
14 Protector
CHP2058
15 Spacer
CHW1713
16 Angle
CNB2351
17 Antenna Assy
CXB2841
18 Clamper
CNV1343
Mark No. Description
Part No.
Mark No. Description
Part No.
NOTE:
- Parts marked by "*"are generally unavailable because they are not in our Master Spare Parts List.
- Screws adjacent to
mark on the product are used for disassembly.
- PACKING SECTION PARTS LIST
- Owner's Manual, Installation Manual
Part No.
Language
CRD2721
English, Spanish, German
CRD2722
French, Italian, Dutch
CRD2723
English, Spanish, German,
French, Italian, Dutch
background image
4
GEX-P900DAB
2.2 EXTERIOR
background image
5
GEX-P900DAB
- EXTERIOR SECTION PARTS LIST
1 Screw
BSZ26P060FMC
2 Screw
BSZ30P060FMC
3 Screw
BSZ30P060FZK
4 Plate
CAH1654
5 Cord
CDE5445
6 IC(IC803)
PQ3RF23
7 IC(IC802)
PQ30RV1
8 Screw
HMF40P060FZK
9 Chassis
CNA2014
10 Angle
CNB2351
11 Case
CNB2268
12 Shield
CNC7513
13 Shield
CNC7514
14 Shield
CNC7515
15 Shield
CNC7516
16 Transistor(Q803)
2SB945
17 IC(IC804)
NJM7805FA
18 Insulator
CNM5804
19 Terminal(CN802)
CKF1059
20 Main Unit
CWM5731
21 Screw
BMZ26P060FMC
22 Nut
CBN1026
23 Plug(CN801)
CKS-460
24 Connector(CN222)
CKS2104
25 Connector(CN221)
CKS2600
26 Connector(CN262)
CKS3409
27 Connector(CN261)
CKS3414
28 Shield
CNC7512
29 Holder
CNC7518
30 Antenna Jack(CN401)
CKX1059
31 Holder
CNC7519
32 Holder
CNC7517
33,34 ·····
35 Holder
CNC7520
36 ·····
37 Screw
ISS26P060FMC
Mark No. Description
Part No.
Mark No. Description
Part No.
