1
En
Operating Instructions
DVD PLAYER
DVD-V7300D
background image
1
En
Operating Instructions
DVD PLAYER
DVD-V7300D
background image
2
En
IMPORTANT
FOR USE IN THE UNITED
KINGDOM
The wires in this mains lead are coloured
in accordance with the following code:
blue:
neutral
brown:
live
If the plug provided is unsuitable for your
socket outlets, the plug must be cut off and
a suitable plug fitted.
The cut-off plug should be disposed of and
must not be inserted into any 13 amp socket
as this can result in electric shock. The plug
or adaptor of the distribution panel should
be provided with 13 amp fuse. As the col-
ours of the wires in the mains lead of this
appliance may not correspond with coloured
marking identifying the terminals in your
plug, proceed as follows:
The wire which is coloured blue must be
connected to the terminal which is marked
with the letter N or coloured black.
The wire which is coloured brown must be
connected to the terminal which is marked
with the letter L or coloured red.
Do not connect either wire to the earth ter-
minal of a three pin plug.
NOTE
After replacing or changing a fuse, the fuse
cover in the plug must be replaced with a
fuse cover which corresponds to the colour
of the insert in the base of the plug or the
word that is embossed on the base of the
plug, and the appliance must not be used
without a fuse cover. If lost, replacement fuse
covers can be obtained from your dealer.
This appliance is rated approved to B.S.
1362 A.S.T.A. should be used.
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of suffi-
cient magnitude to constitute a risk of electric shock
to persons.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
IMPORTANT
CAUTION:
TO PREVENT THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING
TO
QUALIFIED
SERVICE
PERSONNEL.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of im-
portant operating and maintenance (servicing) in-
structions in the literature accompanying the appli-
ance.
Bij dit product zijn batterijen
geleverd. Wanneer deze leeg
zijn, moet u ze niet weggooien
maar inleveren als KCA.
background image
3
En/Fr
The stand-by/ ON switch is secondary connected and
therefore,does not separate the unit from mains power
in standby position.
CLASS 1
LASER PRODUCT
DRW1995-A
CAUTION :
VORSICHT :
ADVARSEL :
VARNING :
VARO!
:
VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN.
AVOID EXPOSURE TO BEAM.
SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG, WENN
ABDECKUNG GEÖFFNET NICHT DEM STRAHL AUSSETZEN!
SYNLIG OG USYNLIG LASERSTRÅLING VED ÅBNING
UNDGÅ UDSÆTTELSE FOR STRÀLING.
SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA
DEL ÄR ÖPPNAD BETRAKTA EJ STRÅLEN.
AVATTAESSA ALTISTUT NÄKYVÄ JA NÄKYMÄTTÖMÄLLE
LASERSATEIL YLLE. ÄLÄ KATSO SÄTEESEN.
VRW1699
IMPORTANT
CAUTION
This product contains a laser diode of higher class than 1.
To ensure continued safety, do not remove any covers or at-
tempt to gain access to the inside of the product.
Refer all servicing to qualified personnel.
The following caution label appear on the player.
Location: On the bonnet of the player
This product complies with the Low Voltage Directives (73/
23/EEC) . EMC Directives (89/336/EEC, 92/31/EEC) and
CE Marking Directive (93/68/EEC).
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO
NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CONSULT WITHTHE COMPANY SALES REPRESENTA-
TIVE. "USE ONLY SAFETY LICENCED POWER SUP-
PLY CORD."
A CERTIFIED POWER SUPPLY CORD IS TO BE USED
WITH THIS EQUIPMENT. FOR A RATED CURRENT UP
TO 6 A, A TYPE NOT LIGHTER THAN H05VV-F 3G O.75
mm2 SHALL BE USED.
The generation of Acoustial Noise Is Less Than 70 dB.
(ISO 7779/DIN 45635)
IMPORTANT
ATTENTION
Ce produit renferme une diode à laser d'une catégorie
supérieure à 1. Pour garantir une sécurité constante, ne pas
retirer les couvercles ni essayer d'accéder à l'intérieur de
l'appareil.
Pour toute réparation, s'adresser à un personnel qualifié.
La note suivante se trouve sur votre lecteur.
Emplacement : Sur le couvercle du lecteur
Ce produit est conforme à la directive relative aux appareils
basse tension (73/23/CEE), aux directives relarives à la
compatibilité électromagnétique (89/336/CEE,92/31/CEE)
et à la directive CE relative aux marquages (93/68/CEE).
ATTENTION: AFIN DE PREVENIR TOUT RISQUE DE CHOC
ELECTRIQUE OU D'INCENDIE, NE PAS EXPOSER CET
APPAREIL A L'HUMIDITE NI A LA PLUIE.
CLASS 1
LASER PRODUCT
DRW1995-A
CAUTION :
VORSICHT :
ADVARSEL :
VARNING :
VARO!
:
VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN.
AVOID EXPOSURE TO BEAM.
SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG, WENN
ABDECKUNG GEÖFFNET NICHT DEM STRAHL AUSSETZEN!
SYNLIG OG USYNLIG LASERSTRÅLING VED ÅBNING
UNDGÅ UDSÆTTELSE FOR STRÀLING.
SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA
DEL ÄR ÖPPNAD BETRAKTA EJ STRÅLEN.
AVATTAESSA ALTISTUT NÄKYVÄ JA NÄKYMÄTTÖMÄLLE
LASERSATEIL YLLE. ÄLÄ KATSO SÄTEESEN.
VRW1699
CONSULTER UN AGENT COMMERCIAL DE LA
SOCIETE.
"N'UTILISER QU'UN CORDON D'ALIMENTATION
GARANTISSANT LA SECURITE".
UN CORDON D'ALIMENTATION HOMOLOGUE DOIT
ETRE UTILISE AVEC CET APPAREIL. POUR UN
COURANT NOMINAL DE JUSQU'A 6 A, IL FAUT
UTILISER UN TYPE DE CORDON QUI NE SOIT PAS
INFERIEUR A H05VV-F 3G 0,75 mm2 OU H05VVH2-F
3G 0,75 mm2.
La génération de bruit de fond acoustique est inférieure
à 70 dB. [ISO 7779/DIN45635]
L'interrupteur Veille/ON est à raccordement
secondaire et il ne coupe donc pas totalement
l'appareil de l'alimentation secteur sur la position de
veille.
Français
background image
4
Ge/It
WICHTIG
VORSICHT
Dieses Gerät enthält eine Laserdiode mit einer höheren Klasse
als 1. Um einen stets sicheren Betrieb zu gewährleisten, weder
irgendwelche Abdeckungen entfernen, noch versuchen, sich
zum Geräteinneren Zugang zu verschaffen.
Alle Wartungsarbeiten sollten qualifizier tem Kunden-
dienstpersonal überlassen werden.
Die folgenden Warnungsetiketten sind am DVD-Spieler
angebracht.
Lage: Auf der Haube des Players
Dieses Produkt entspricht den Niederspannungsrichtlinien (73/
23/EC), EMV-Richtlinien (89/336/EEC, 92/31/EEC) und
den CE-Markierungsrichtlinien (93/68/EEC).
WARNUNG: UM EINEN BRAND ODER STROMSCHLAG ZU
VERMEIDEN, DIESES GERÄT NICHT REGEN ODER
FEUCHTIGKEIT AUSSETZEN.
CLASS 1
LASER PRODUCT
DRW1995-A
CAUTION :
VORSICHT :
ADVARSEL :
VARNING :
VARO!
:
VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN.
AVOID EXPOSURE TO BEAM.
SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG, WENN
ABDECKUNG GEÖFFNET NICHT DEM STRAHL AUSSETZEN!
SYNLIG OG USYNLIG LASERSTRÅLING VED ÅBNING
UNDGÅ UDSÆTTELSE FOR STRÀLING.
SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA
DEL ÄR ÖPPNAD BETRAKTA EJ STRÅLEN.
AVATTAESSA ALTISTUT NÄKYVÄ JA NÄKYMÄTTÖMÄLLE
LASERSATEIL YLLE. ÄLÄ KATSO SÄTEESEN.
VRW1699
IMPORTANTE
PRECAUZIONE
Questo prodotto contiene un diodo al laser di classe superiore
alla classe1. Per motivi di sicurezza, non smontare i coperchi
e non procedere ad interventi sulle parti interne.
Per qualsiasi riparazione rivolgersi a personale qualificato.
La nota seguente si trova.
Ubicazione: Sul comperchio del lettore
Questo prodotto è conforme alla direttiva sul basso
voltaggio (73/23/CEE), alle direttive EMC (89/336/CEE,92/
31/CEE) e alla direttiva sul marchio CE (93/68/CEE).
AVVERTENZA: PER EVITARE IL RISCHIO DI FIAMME O
SCOSSE ELETTRICHE, NON ESPORRE QUESTO
APPARECCHIO ALLA PIOGGIA O ALL 'UMIDITÀ
CLASS 1
LASER PRODUCT
DRW1995-A
CAUTION :
VORSICHT :
ADVARSEL :
VARNING :
VARO!
:
VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN.
AVOID EXPOSURE TO BEAM.
SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG, WENN
ABDECKUNG GEÖFFNET NICHT DEM STRAHL AUSSETZEN!
SYNLIG OG USYNLIG LASERSTRÅLING VED ÅBNING
UNDGÅ UDSÆTTELSE FOR STRÀLING.
SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA
DEL ÄR ÖPPNAD BETRAKTA EJ STRÅLEN.
AVATTAESSA ALTISTUT NÄKYVÄ JA NÄKYMÄTTÖMÄLLE
LASERSATEIL YLLE. ÄLÄ KATSO SÄTEESEN.
VRW1699
CONSULTARE IL RAPPRESENTANTE DELLA
COMPAGNIA. "USARE SOLTANTO IL CAVO DI
ALIMENTAZIONE BREVETTATO PER LA
SICUREZZA." CON QUESTO APPARECCHIO SI
DEVE USARE UN CAVO DI ALIMENTAZIONE
CERTIFICATO. PER UNA CORRENTE NOMINALE
FINO A 6 A, DEVE ESSERE USATO UN TIPO NON
PIÙ LEGGERO DI H05VV-F 3G 0,75 mm2 O H05VVH2-
F 3G 0,75 mm2.
La generazione di rumore acustico è inferiore a 70 dB.
(ISO 7779/DIN45635)
L'interruttore di attesa/accensione (ON) è collegato
in modo secondario e perciò nella posizione di
attesa non separa l'unità dall'alimentazione della
rete.
"AUSSCHLIESSLICH EIN DEN GELTENDEN
SICHERHEITSBESTIMMUNGEN ENTSPRECHENDES
NETZKABEL VERWENDEN."
DIESES GERÄT MUSS ÜBER EIN DEN GELTENDEN
SICHERHEITSBESTIMMUNGEN ENTSPRECHENDES
NETZKABEL AN DAS STROMNETZ
ANGESCHLOSSEN WERDEN. BEI EINEM
NENNSTROM VON MAXIMAL 6 A MUSS EINE
NETZKABELGARNITUR VON MINDESTENS H05VV-F
3 G 0,75 mm2 ODER H05VVH2-F 3 G 0,75 mm2
VERWENDET WERDEN.
Der Betriebsgeräuschpegel beträgt weniger als 70 dB
[ISO 7779/DIN 45635].
Der Bereitschafts-/Ein-Schalter ist sekundär
angeschlossen, und trennt das Gerät in der
Bereitschaftsstellung nicht vom Stromnetz.
Deutsch
Italiano
background image
5
Sp/En
IMPORTANTE
PRECAUCIÓN
Este producto contiene un diodo de láser de clase superior a
1. Para mantener la seguridad apropiada, no quite ninguna
tapa ni trate de acceder al interior del aparato.
Confíe todo el mantenimiento a personal técnico cualificado.
En su aparato se han aplicado las siguientes etiquetas
precautorias:
Ubicación: En la cubierta del reproductor
Este producto cumple con la Directiva de Bajo Voltaje (73/
23/CEE), Directivas EMC (89/336/CEE, 92/31/CEE) y
Directiva de Marcación CE (93/68/CEE).
ADVERTENCIA: PARA EVITAR INCENDIOS Y DESCARGAS
ELÉCTRICAS, NO EXPONGA ESTE APARATO A LA LLUVIA
NI A LA HUMEDAD.
CLASS 1
LASER PRODUCT
DRW1995-A
CAUTION :
VORSICHT :
ADVARSEL :
VARNING :
VARO!
:
VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN.
AVOID EXPOSURE TO BEAM.
SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG, WENN
ABDECKUNG GEÖFFNET NICHT DEM STRAHL AUSSETZEN!
SYNLIG OG USYNLIG LASERSTRÅLING VED ÅBNING
UNDGÅ UDSÆTTELSE FOR STRÀLING.
SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA
DEL ÄR ÖPPNAD BETRAKTA EJ STRÅLEN.
AVATTAESSA ALTISTUT NÄKYVÄ JA NÄKYMÄTTÖMÄLLE
LASERSATEIL YLLE. ÄLÄ KATSO SÄTEESEN.
VRW1699
CONSULTE AL REPRESENTANTE DE VENTAS DE
LA COMPAÑÍA. "UTILICE SOLAMENTE EL CABLE
DE ALIMENTACIÓN APROBADO Y SEGURO". CON
ESTE EQUIPO DEBERÁ UTILIZARSE UN CABLE DE
ALIMENTACIÓN CERTIFICADO. PARA UNA
CORRIENTE NOMINAL DE HASTA 6 A DEBERÁ
UTILIZARSE UNO CUYO TIPO NO SEA MÁS LIGERO
QUE EL H05VV-F3G DE 0,75 mm2 O EL H05VVH2-
F3G DE 0,75 mm2.
La generación de ruido acústico es inferior a 70 dB.
(ISO 7779/DIN45635)
El interruptor de alimentación en espera/encendido
está conectado en secundario y, por lo tanto, no
desconecta la unidad de la toma de alimentación
cuando está en la posición de alimentación en
espera.
Please read through these operating instructions so you will
know how to operate your model properly. After you have fin-
ished reading the instructions, put them away in a safe place
for future reference.
·
This player is not suitable for commercial use.
Before using
Thank you for buying this Pioneer product.
Please read through these operating instructions so you will
know how to operate your model properly. After you have
finished reading the instructions, put them away in a safe place
for future reference.
Check Accessories
Audio cord ........................................................................... 1
Video cord ........................................................................... 1
AC cord ............................................................................... 2
(Europian model)
(UK model)
Remote control unit ............................................................. 1
Batteries (AA/R6P) .............................................................. 2
Laser barcode sheet ........................................................... 1
Operating Instructions ......................................................... 1
Inserting batteries into
the remote control
While pressing the back cover, pull out in the
direction indicated by the arrow and insert R6P
size dry cell batteries.
÷ Make sure to match the plus (+) and minus (-) polarity guides
in the batteries with the marks inside the battery compart-
ment.
Note
÷ Do not mix old and new batteries.
÷ Even batteries of the same type will differ in voltage.
Do not mix different type of batteries together.
÷ When not using the remote control for a long period of time
(over 1 month), remove the batteries to avoid possible dam-
age from battery corrosion. If battery leakage occurs, wipe
the battery liquid from the battery component, then insert
new batteries.
Español

Reviews

There are no reviews of this manual yet.
