ORDER NO.
DBR-S100NL
DIGITAL SATELLITE RECEIVER
ORDER NO.
ARP3033
O- ZZS APR. 1999 Printed in Japan
c
PIONEER ELECTRONIC CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER ELECTRONIC CORPORATION 1999
Refer to the service manual ARP3003 for TS3/NYXK.
Type
Model
Power Requirement
Remarks
DBR-S100NL
NYXK/NL
AC230V
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
background image
2
DBR-S100NL
PACKING SECTION
P3-3
INSTRUCTION MANUAL
BRC1003
BRC1013
(French)
(Dutch)
P3-4
CE DECLARATION CARD
BRM1011
Not Used
NSP
WARRANTY CARD
Not Used
BRY1024
NSP
BROCHURE(NL)
Not Used
BRY1025
NSP
REGISTRATION FORM
Not Used
BRY1026
NSP
SERIAL PAPER
Not Used
RRW-168
P3-6
REMOTE CONTROL UNIT
BXD1010
BXD1038
P3-7
MODEM CABLE
BDH1014
BDH1015
NSP
MODEM ADAPTER
Not Used
BKP1140
NSP
SECA SMART CARD KIT
Not Used
BPK1020
P3-14
PACKING CASE(PAP)
BHD1369
BHD1452
EXTERIOR SECTION
P5-1
FRONT PANEL ASSY
BMB1071
BMB1091
P5-9
REAR PANEL (MET)
BNC1124
BNC1136
P5-14
BONNET CASE
BNE1080
BNE1086
DISPLAY PANEL(PLS)
BAK1140
BAK1155
PIONEER BADGE(AL)
Not Used
BAM1004
MODEM HOLDER (MET)
Not Used
ANG2037 *1
*1 Refer to page 3.
P5-6
NSP
NAME LABEL
BAL1321
BAL1363
NSP
BARCODE LABEL
Not Used
BAL1310
P5-19
NSP
MODEM LABEL (PAP)
BAX1173
Not Used
PCB SECTION
P5-2
MAIN ASSY
BWE1049
BWE1076
NSP
DMXCPU BLOCK
B2E1049
B2E1076
NSP
IO BLOCK
B8E1049
B8E1050
NSP
MODEM BLOCK
B9E1049
Not Used
MODEM ASSY
Not Used
BXY1022 *2
*2 BXY1022 have no
service part.
1. CONTRAST OF MISCELLANEOUS PARTS
NOTES:
·Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
·The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
·When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
560
56
× 101
561 ........................................................ RD1/4PU 5 6 1 J
47k
47
× 103
473 ........................................................ RD1/4PU 4 7 3 J
0.5
R50 ..................................................................................... RN2H R 5 0 K
1
1R0 ..................................................................................... RS1P 1 R 0 K
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
5.62k
562
× 101
5621 ...................................................... RN1/4PC 5 6 2 1 F
CONTRAST OF DBR-S100NL/NYXK/NL AND TS3/NYXK
DBR-S100NL/NYXK/NL and TS3/NYXK are constructed the same except for the following:
Mark
Symbol and Description
Part No.
Remarks
TS3/NYXK
DBR-S100NL/NYXK/NL
Ref. No.
background image
3
DBR-S100NL
DMXCPU BLOCK
B2E1049
B2E1076
IC2002
V53C518165AK50
HYB5118165BSJ-50
IC2004
PDK034B
PDL013A
IO BLOCK
B8E1049
B8E1050*
* Refer to page 6,7.
C2806,C2808,C2809,C2810,C2811,
Not Used
CCSQCH221J50
C2812,C2813,C2814,C2819
Not Used
CCSQCH221J50
C2807,C2820
Not Used
CKSQYB102K50
R2812,R2813
Not Used
RS1/10S820J
R2859,R2860
Not Used
RS1/10S102J
R2857,R2858
Not Used
RS1/10S392J
R2834,R2835
BCN1046
Not Used
CN2801
Not Used
9604S-12C
OTHERS
S/N LABEL(PAP)
BAX1145
BAX1258
3P HOUSING ASSY
Not Used
BDX1540
MAIN ASSY
BWE1076 and BWE1049 are constructed the same except for the following:
Symbol & Description
Part No.
Remarks
BWE1076
BWE1049
Mark
A
MODEM HOLDER
ANG2037
BBZ30P080FZK
REAR PANEL
background image
DBR-S100NL
4
A
B
C
D
1
23
4
12
3
4
(
,
,
)
Note : When ordering service parts, be sure to refer to "EXPLODED
VIEWS and PARTS LIST" or "PCB PARTS LIST".
2. SCHEMATIC DIAGRAM
2.1 OVERALL CONNECTION DIAGRAM
CARD ASSY (BWZ1847)
7/9
1/9 -
F8/9
9/9
MAIN ASSY
(BWE1076 )
F
A
A
A
A
A
D
