Operating Instructions
COMPACT DISC PLAYER
CDJ-800MK2
background image
Operating Instructions
COMPACT DISC PLAYER
CDJ-800MK2
background image
2
Thank you for buying this Pioneer product.
Please read through these operating instructions so you will know how to operate your
model properly. After you have finished reading the instructions, put them away in a safe
place for future reference.
In some countries or regions, the shape of the power plug and power outlet may some-
times differ from that shown in the explanatory drawings. However the method of con-
necting and operating the unit is the same.
K015 En
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
The lightning flash with arrowhead symbols,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
CAUTION:
TO PREVENT THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
D1-4-2-3_En
NOTE: THE NO USER-SERVICEABLE PARTS COMPARTMENT WARNING IS LOCATED ON THE APPLIANCE BOTTOM.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
­ Reorient or relocate the receiving antenna.
­ Increase the separation between the equipment and receiver.
­ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
­ Consult the dealer or an experienced radio/TV technician for help.
D8-10-1-2_En
READ INSTRUCTIONS -- All the safety and
operating instructions should be read before the
product is operated.
RETAIN INSTRUCTIONS -- The safety and
operating instructions should be retained for
future reference.
HEED WARNINGS -- All warnings on the product
and in the operating instructions should be
adhered to.
FOLLOW INSTRUCTIONS -- All operating and use
instructions should be followed.
CLEANING -- The product should be cleaned only
with a polishing cloth or a soft dry cloth. Never
clean with furniture wax, benzine, insecticides
or other volatile liquids since they may corrode
the cabinet.
ATTACHMENTS -- Do not use attachments not
recommended by the product manufacturer as
they may cause hazards.
WATER AND MOISTURE -- Do not use this
product near water -- for example, near a
bathtub, wash bowl, kitchen sink, or laundry
tub; in a wet basement; or near a swimming
pool; and the like.
ACCESSORIES -- Do not place this product on an
unstable cart, stand, tripod, bracket, or table.
The product may fall, causing serious injury to a
child or adult, and serious damage to the
product. Use only with a cart, stand, tripod,
bracket, or table recommended by the
manufacturer, or sold with the product. Any
mounting of the product should follow the
manufacturer's instructions, and should use a
mounting accessory recommended by the
manufacturer.
CART -- A product and cart combination should be
moved with care. Quick stops, excessive force,
and uneven surfaces may cause the product
and cart combination to overturn.
VENTILATION -- Slots and openings in the cabinet
are provided for ventilation and to ensure
reliable operation of the product and to protect
it from overheating, and these openings must
not be blocked or covered. The openings should
never be blocked by placing the product on a
bed, sofa, rug, or other similar surface. This
product should not be placed in a built-in
installation such as a bookcase or rack unless
proper ventilation is provided or the
manufacturer's instructions have been adhered
to.
POWER SOURCES -- This product should be
operated only from the type of power source
indicated on the marking label. If you are not
sure of the type of power supply to your home,
consult your product dealer or local power
company.
LOCATION ­ The appliance should be installed in a
stable location.
NONUSE PERIODS ­ The power cord of the
appliance should be unplugged from the outlet
when left un-used for a long period of time.
GROUNDING OR POLARIZATION
· If this product is equipped with a polarized
alternating current line plug (a plug having one
blade wider than the other), it will fit into the
outlet only one way. This is a safety feature. If
you are unable to insert the plug fully into the
outlet, try reversing the plug. If the plug should
still fail to fit, contact your electrician to replace
your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.
· If this product is equipped with a three-wire
grounding type plug, a plug having a third
(grounding) pin, it will only fit into a grounding
type power outlet. This is a safety feature. If you
are unable to insert the plug into the outlet,
contact your electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the
grounding type plug.
POWER-CORD PROTECTION -- Power-supply
cords should be routed so that they are not likely
to be walked on or pinched by items placed
upon or against them, paying particular
attention to cords at plugs, convenience
receptacles, and the point where they exit from
the product.
OUTDOOR ANTENNA GROUNDING -- If an
outside antenna or cable system is connected to
the product, be sure the antenna or cable
system is grounded so as to provide some
protection against voltage surges and built-up
static charges. Article 810 of the National
Electrical Code, ANSI/NFPA 70, provides
information with regard to proper grounding of
the mast and supporting structure, grounding of
the lead-in wire to an antenna discharge unit,
size of grounding conductors, location of
antenna-discharge unit, connection to
grounding electrodes, and requirements for the
grounding electrode. See Figure A.
LIGHTNING -- For added protection for this
product during a lightning storm, or when it is
left unattended and unused for long periods of
time, unplug it from the wall outlet and
disconnect the antenna or cable system. This
will prevent damage to the product due to
lightning and power-line surges.
POWER LINES -- An outside antenna system
should not be located in the vicinity of overhead
power lines or other electric light or power
circuits, or where it can fall into such power
lines or circuits. When installing an outside
antenna system, extreme care should be taken
to keep from touching such power lines or
circuits as contact with them might be fatal.
OVERLOADING -- Do not overload wall outlets,
extension cords, or integral convenience
receptacles as this can result in a risk of fire or
electric shock.
OBJECT AND LIQUID ENTRY -- Never push
objects of any kind into this product through
openings as they may touch dangerous voltage
points or short-out parts that could result in a
fire or electric shock. Never spill liquid of any
kind on the product.
SERVICING -- Do not attempt to service this
product yourself as opening or removing covers
may expose you to dangerous voltage or other
hazards. Refer all servicing to qualified service
personnel.
DAMAGE REQUIRING SERVICE -- Unplug this
product from the wall outlet and refer servicing
to qualified service personnel under the
following conditions:
· When the power-supply cord or plug is
damaged.
· If liquid has been spilled, or objects have fallen
into the product.
· If the product has been exposed to rain or water.
· If the product does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions as an improper adjustment of other
controls may result in damage and will often
require extensive work by a qualified technician
to restore the product to its normal operation.
· If the product has been dropped or damaged in
any way.
· When the product exhibits a distinct change in
performance -- this indicates a need for service.
REPLACEMENT PARTS -- When replacement parts
are required, be sure the service technician has
used replacement parts specified by the
manufacturer or have the same characteristics
as the original part. Unauthorized substitutions
may result in fire, electric shock, or other
hazards.
SAFETY CHECK -- Upon completion of any service
or repairs to this product, ask the service
technician to perform safety checks to
determine that the product is in proper
operating condition.
WALL OR CEILING MOUNTING -- The product
should not be mounted to a wall or ceiling.
HEAT -- The product should be situated away from
heat sources such as radiators, heat registers,
stoves, or other products (including amplifiers)
that produce heat.
GROUND
CLAMP
ELECTRIC
SERVICE
EQUIPMENT
ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
NEC -- NATIONAL ELECTRICAL CODE
Fig. A
D1-4-2-2_En
WARNING
This equipment is not waterproof. To prevent a fire
or shock hazard, do not place any container filed
with liquid near this equipment (such as a vase or
flower pot) or expose it to dripping, splashing, rain
or moisture.
D3-4-2-1-3_A_En
IMPORTANT NOTICE ­ THE SERIAL NUMBER FOR
THIS EQUIPMENT IS LOCATED ON THE BOTTOM.
PLEASE WRITE THIS SERIAL NUMBER ON YOUR
ENCLOSED WARRANTY CARD AND KEEP IN A
SECURE AREA. THIS IS FOR YOUR SECURITY.
D1-4-2-6-1_En
CAUTION : USE OF CONTROLS OR ADJUSTMENTS
OR PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED
HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
CAUTION : THE USE OF OPTICAL INSTRUMENTS
WITH THIS PRODUCT WILL INCREASE
EYE HAZARD.
D6-8-2-1_En
This Class B digital apparatus complies with
Canadian ICES-003.
Cet appareil numérique de la Classe B est conforme
à la norme NMB-003 du Canada.
D8-10-1-3_EF
Information to User
Alteration or modifications carried out without
appropriate authorization may invalidate the user's
right to operate the equipment.
D8-10-2_En
CAUTION: This product satisfies FCC regulations
when shielded cables and connectors are used to
connect the unit to other equipment. To prevent
electromagnetic interference with electric appliances
such as radios and televisions, use shielded cables
and connectors for connections.
D8-10-3a_En
CAUTION
­ PREVENT ELECTRIC SHOCK DO
NOT USE THIS (POLARIZED) PLUG
WITH AN EXTENSION CORD.
RECEPTACLE OR OTHER OUTLET
UNLESS THE BLADES CAN BE
FULLY INSERTED TO PREVENT
BLADE EXPOSURE.
ATTENTION ­ POUR PREVENIR LES CHOCS
ELECTRIQUES NE PAS UTILISER
CETTE FICHE POLARISEE AVEC UN
PROLONGATEUR UNE PRISE DE
COURANT OU UNE AUTRE SORTIE
DE COURANT, SAUF SI LES LAMES
PEUVENT ETRE INSEREES A FOND
SANS EN LAISSER AUCUNE PARTIE
A DECOUVVERT.
D2-4-4-1_EF
WARNING: Handling the cord on this product or
cords associated with accessories sold with the
product will expose you to chemicals listed on
proposition 65 known to the State of California and
other governmental entities to cause cancer and
birth defect or other reproductive harm.
Wash hands after handling
D36-P4_A_En
WARNING
To prevent a fire hazard, do not place any naked
flame sources (such as a lighted candle) on the
equipment.
D3-4-2-1-7a_A_En
VENTILATION CAUTION
When installing this unit, make sure to leave space
around the unit for ventilation to improve heat
radiation (at least 5 cm at rear, and 5 cm at each
side).
WARNING
Slots and openings in the cabinet are provided for
ventilation to ensure reliable operation of the
product, and to protect it from overheating. To
prevent fire hazard, the openings should never be
blocked or covered with items (such as newspapers,
table-cloths, curtains) or by operating the
equipment on thick carpet or a bed.
D3-4-2-1-7b_A_En
POWER-CORD CAUTION
Handle the power cord by the plug. Do not pull out the
plug by tugging the cord and never touch the power
cord when your hands are wet as this could cause a
short circuit or electric shock. Do not place the unit, a
piece of furniture, etc., on the power cord, or pinch the
cord. Never make a knot in the cord or tie it with other
cords. The power cords should be routed such that they
are not likely to be stepped on. A damaged power cord
can cause a fire or give you an electrical shock. Check
the power cord once in a while. When you find it
damaged, ask your nearest PIONEER authorized
service center or your dealer for a replacement.
S002_En
background image
3
Contents
Specifications
1. General
System ................................ Compact disc digital audio system
Power requirements ........................................ AC 120 V, 60 Hz
Power consumption .......................................................... 20 W
Operating temperature ..................................... +5 °C to +35 °C
Operating humidity ................................................. 5 % to 85 %
(There should be no condensation of moisture.)
Weight .................................................................. 4.0 kg (8.8 lb)
Dimensions ....................... 305 (W) x 344.1 (D) x 108.5 (H) mm
12 (W) x 13­9/16 (D) x 4­1/4 (H) in
2. Audio section
Frequency response ........................................... 4 Hz to 20 kHz
Signal-to-noise ratio ............................... 115 dB or more (JEITA)
Distortion .......................................................... 0.006 % (JEITA)
3. Accessories
÷ Operating instructions ......................................................... 1
÷ Power cord .......................................................................... 1
÷ Audio cable .......................................................................... 1
÷ Control cord ......................................................................... 1
÷ Forced eject pin
(housed in a groove in the bottom panel) ............................ 1
÷ Limited warranty .................................................................. 1
NOTE:
Specifications and design are subject to possible modification
without notice.
Before Operating
Specifications ........................................................................... 3
Features ................................................................................... 4
Handling Precautions ............................................................... 5
Discs Usable with This Unit ..................................................... 6
Connections ............................................................................. 8
Names and Functions of Parts ............................................... 10
Basic Operations
Loading and Removing Discs ................................................. 13
DJ Player Operation ............................................................... 14
Auto cueing ...................................................................... 14
Starting playback .............................................................. 14
To stop playback ............................................................... 14
To pause playback ............................................................ 14
Fast forward / Fast reverse .............................................. 14
Track search ...................................................................... 15
Folder search (MP3 only) .................................................. 15
Cue point settings ............................................................ 15
To change the playing speed ............................................ 16
Applying master tempo .................................................... 16
Jog dial functions ............................................................. 16
Mixing different tracks ..................................................... 17
About TEXT display .......................................................... 17
Advanced Operations
Advanced Operations ............................................................. 18
Scratch play ...................................................................... 18
Spin play ........................................................................... 18
Braking ............................................................................. 18
Quick return ...................................................................... 18
Loop playback ................................................................... 18
Reverse play ..................................................................... 19
About fader start play ....................................................... 19
Relay play using two players ............................................ 20
Cue point / loop point memory ......................................... 20
Copying recorded data to another player ......................... 20
Other
Troubleshooting ...................................................................... 21
Contents/Specifications
background image
4
Features
Features
The CDJ-800MK2 compact disc player is designed for use by
DJs providing all the functions and performance required in disco
clubs while offering performance, sound quality and functional-
ity superior to any analog player.
JOG DIAL
The large 206 mm diameter jog dial enables better handling
than an analog turntable.
¶ PITCH BEND
This function changes the music tempo depending on direction
of jog dial rotation and speed of movement.
¶ SCRATCH PLAY
In the VINYL mode when the surface of the jog dial is pressed
playback is discontinued and then continues according to the
direction and speed the dial is rotated. You can also adjust the
startup when the jog dial is touched and released to create new
DJ techniques.
¶ FRAME SEARCH
Moves the disc from pause position in frame increments (1/75
sec) when the jog dial is rotated in pause mode.
¶ SUPER FAST SEARCH
Rotate the jog dial while holding depressed the SEARCH button,
TRACK SEARCH button, or FOLDER SEARCH button. When this
is done, search will be performed faster than the normal search,
track search, or folder search operations.
ON JOG DISPLAY
The center of the jog dial displays information regarding disc sta-
tus, cue point position, sound memory status, jog dial touch-
detection, and VINYL mode.
CUE/LOOP MEMORY
This player is equipped with an internal memory that permits the
recording of one disc cue point or loop point per disc; the re-
corded points can later be recalled as desired.
QUICK RETURN
In the VINYL mode, merely touching the Jog dial's top surface
will initiate a quick return to the cue point.
REVERSE PLAY
When the reverse button (REV) is pressed so that the button's
indicator lamp lights, play is performed in the reverse direction.
TEMPO CONTROL
100 mm high-precision slider coupled with a 0.05 % incre-
ment digital display (within a ±10 % range) allows exact control
of speed to make tempo adjustments easy and accurate.
¶ TEMPO CONTROL RANGE
The maximum variable range can be set to two variable ranges:
±10 % and WIDE to facilitate adjustment.
¶ MASTER TEMPO
Changes music tempo without changing pitch.
MP3 DJ PLAY
MP3 files recorded on CD-ROM can be played with DJ func-
tions.
CUE
¶ BACK CUE
After storing the cue point in memory, press the CUE button
while playing the unit to go back to the cue point and start over.
¶ AUTO CUE
Auto cue automatically locates the song's start point even if it
differs from the track's frame, allowing the player to start in-
stantly at a press of the PLAY button.
¶ CUE POINT SAMPLER
The sound from the memorized cue point can be reproduced by
one touch, which can be used as the start point check and the
sampler.
REAL TIME SEAMLESS LOOP
This function simplifies setting and releasing loops. This func-
tion lets you set a loop while you are playing a track. A loop can
also be set at the end of the track so that the track does not
stop. In addition, an ADJUST mode has been added to enable
one-touch adjustments to Loop-out points and facilitate loop
operation.
AUTO BEAT LOOP
This function uses the track's BPM to automatically set a loop
out point and perform loop play.
RELOOP
Allows you to replay a loop any number of times.
Press the RELOOP button after releasing loop play to return to
the loop start point. Clever use of on and off in combination with
the rhythm make it possible to create new sound effects.
PLAYING ADDRESS
This bar graph provides a visual representation of track playback
progress that enables you to see current playback position just
like you can on an analog record by checking needle position.
The length of the bar shows current position and a flashing bar
provides advance notice of track end.
SLOT IN
Discs are loaded directly without opening doors or trays, making
track selection that much faster.
FADER START
When a Pioneer DJ mixer (sold separately) is connected, the
mixer's fader operation can be used to perform quick start and
back cue.
MULTI READ
Allows playback of CD-R, CD-RW discs (recorded in music CD or
MP3 format). (Note that some discs may not play properly due
to characteristics of the individual disc, recorder, or disc soiling
and scratches.)
background image
5
Handling Precautions
Installation location
¶ Placing and using the player for long periods on heat-generat-
ing sources such as amplifiers or near spotlights, etc. will af-
fect product performance. Avoid placing the player on heat-
generating sources.
¶ Install this player as far as possible away from tuners and TV
sets. The player installed in close proximity to such equip-
ment may cause noise or degradation of the picture.
Noise may be noticeable when an indoor antenna is used. In
such cases, make use of an outdoor antenna or turn off power
to the player.
¶ When the unit is used in a loud-sound environment, e.g., near
a speaker, sound skip may occur. Install the unit away from
the speaker or reduce the listening volume.
¶ Place this unit on a level surface and a stable platform.
Take adequate note of the following precautions when pre-
paring a place for installation:
Be sure the player, including its video, audio and power supply
cords, does not touch vibrating materials. Any vibration other
than that transmitted through the insulators may cause the disc
to skip. Take special care when using the player while it is in-
stalled in a carrying case.
Moving the unit
I Never move the unit during playback!
During playback, a disc rotates at very high speed; moving the
player during playback may result in scratches or other damage
to the disc.
I When moving the unit is necessary
Before moving the unit, remove any disc and disconnect the
power. Malfunctions or damage may result if the unit is moved
with a disc loaded.
About the carrying case
The upper surface of the jog dial is equipped with a touch-sensi-
tive switch. When placing the player in its carrying case, avoid
placing any pressure on the jog dial.
Condensation
When this unit is brought into a warm room from previously cold
surroundings or when the room temperature rises sharply, con-
densation may form inside the unit and impair its performance.
In such cases, allow the unit to stand for about an hour or raise
the room temperature gradually.
Cleaning the player
To clean the player wipe with a polishing or a soft, dry cloth. For
stubborn dirt, moisten a soft cloth with a weak solution of neu-
tral detergent (diluted in five to six parts water), wring the cloth
well, and wipe away the dirt. Use a dry cloth to wipe the surface
dry. Do not use volatile liquids such as benzene or thinner which
will damage the unit.
About the lens cleaner
The player's pickup lens should not become dirty in normal use.
If for some reason, the lens becomes soiled and malfunctions,
contact your nearest PIONEER authorized service center. Lens
cleaners for CD players are commercially available, but special
care should be exercised in their use as some may cause dam-
age to the lens.
Handling Precautions
Do not place on or
against vibrating
materials!
Leave space to
allow for heat
dissipation.
Leave space to
allow for heat
dissipation.
Leave space to allow for heat
dissipation.

Reviews

There are no reviews of this manual yet.
