AV Receiver

TX-DS484

Instruction Manual

Thank you for purchasing the Onkyo AV Receiver.

Please read this manual thoroughly before making

connections and turning on the power.

Following the instructions in this manual will enable

you to obtain optimum performance and listening

enjoyment from your new AV Receiver.

Please retain this manual for future reference.

Contents

Before using

Important Safeguards........................ 2

Precautions ....................................... 3

Features............................................. 4

Supplied accessories......................... 4

Before operating this unit ................. 5

Preparation

Audio equipment connections .......... 6

Video equipment connections .......... 7

Connecting other devices ................. 8

Connecting speakers....................... 10

Positioning speakers ....................... 11

Connecting the power..................... 11

Making antenna connections .......... 12

Operation

Speaker setup.................................. 14

Selecting a sound source ................ 17

To enjoy Surround mode or Stereo

mode ............................................ 20

Tuning in a radio station................. 23

Using preset radio stations.............. 24

Recording a source ......................... 25

Appendix

Troubleshooting guide.................... 27

Specifications ................................. 28

Control guide

Control positions and names .......... 29

Remote controller RC-427S ........... 30

Using the remote controller ............ 31

PORTABLE CART WARNING

S3125A

Important Safeguards

1. Read Instructions All the safety and operating instructions

should be read before the appliance is operated.

2. Retain Instructions The safety and operating instructions

should be retained for future reference.

3. Heed Warnings All warnings on the appliance and in the

operating instructions should be adhered to.

4. Follow Instructions All operating and use instructions

should be followed.

5. Cleaning Unplug the appliance from the wall outlet before

cleaning. The appliance should be cleaned only as recom-

mended by the manufacturer.

6. Attachments Do not use attachments not recommended by

the appliance manufacturer as they may cause hazards.

7. Water and Moisture Do not use the appliance near water for

example, near a bath tub, wash bowl, kitchen sink, or laundry

tub; in a wet basement; or near a swimming pool; and the like.

8. Accessories Do not place the appliance on an unstable cart,

stand, tripod, bracket, or table. The appliance may fall, causing

serious injury to a child or adult, and serious damage to the

appliance. Use only with a cart, stand, tripod, bracket, or table

recommended by the manufacturer, or sold with the appliance.

Any mounting of the appliance

should

the

manufac-

turer's instructions, and should

use a mounting accessory rec-

ommended by the manufacturer.

9. An appliance and cart combina-

tion should be moved with care.

Quick stops, excessive force,

and uneven surfaces may cause

the appliance and cart combina-

tion to overturn.

10. Ventilation Slots and openings in the cabinet are provided

for ventilation and to ensure reliable operation of the appliance

and to protect it from overheating, and these openings must not

be blocked or covered. The openings should never be blocked

by placing the appliance on a bed, sofa, rug, or other similar

surface. The appliance should not be placed in a built-in instal-

lation such as a bookcase or rack unless proper ventilation is

provided. There should be free space of at least 20 cm (8 in.)

and an opening behind the appliance.

11. Power Sources The appliance should be operated only from

the type of power source indicated on the marking label. If you

are not sure of the type of power supply to your home, consult

your appliance dealer or local power company.

12. Grounding or Polarization The appliance may be equipped

with a polarized alternating current line plug (a plug having

one blade wider than the other). This plug will fit into the

power outlet only one way. This is a safety feature. If you are

unable to insert the plug fully into the outlet, try reversing the

plug. If the plug should still fail to fit, contact your electrician

to replace your obsolete outlet. Do not defeat the safety pur-

pose of the polarized plug.

13. Power-Cord Protection Power-supply cords should be

routed so that they are not likely to be walked on or pinched by

items placed upon or against them, paying particular attention

to cords at plugs, convenience receptacles, and the point where

they exit from the appliance.

14. Outdoor Antenna Grounding If an outside antenna or cable

system is connected to the appliance, be sure the antenna or

cable system is grounded so as to provide some protection

against voltage surges and built-up static charges. Article 810

of the National Electrical Code, ANSI/NFPA 70, provides

information with regard to proper grounding of the mast and

supporting structure, grounding of the lead-in wire to an

antenna-discharge unit, size of grounding conductors, location

of antenna-discharge unit, connection to grounding electrodes,

and requirements for the grounding electrode. See Figure 1.

15. Lightning For added protection for the appliance during a

lightning storm, or when it is left unattended and unused for

long periods of time, unplug it from the wall outlet and discon-

nect the antenna or cable system. This will prevent damage to

the appliance due to lightning and power-line surges.

16. Power Lines An outside antenna system should not be

located in the vicinity of overhead power lines or other electric

light or power circuits, or where it can fall into such power

lines or circuits. When installing an outside antenna system,

extreme care should be taken to keep from touching such

power lines or circuits as contact with them might be fatal.

17. Overloading Do not overload wall outlets, extension cords,

or integral convenience receptacles as this can result in a risk of

fire or electric shock.

18. Object and Liquid Entry Never push objects of any kind

into the appliance through openings as they may touch danger-

ous voltage points or short-out parts that could result in a fire or

electric shock. Never spill liquid of any kind on the appliance.

19. Servicing Do not attempt to service the appliance yourself as

opening or removing covers may expose you to dangerous

voltage or other hazards. Refer all servicing to qualified service

personnel.

20. Damage Requiring Service Unplug the appliance form the

wall outlet and refer servicing to qualified service personnel

under the following conditions:

A. When the power-supply cord or plug is damaged,

B. If liquid has been spilled, or objects have fallen into the

appliance,

C. If the appliance has been exposed to rain or water,

D. If the appliance does not operate normally by following the

operating instructions. Adjust only those controls that are

covered by the operating instructions as an improper

adjustment of other controls may result in damage and will

often require extensive work by a qualified technician to

restore the appliance to its normal operation,

E. If the appliance has been dropped or damaged in any way,

and

F. When the appliance exhibits a distinct change in perfor-

mance this indicates a need for service.

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,

DO NOT EXPOSE THIS APPLIANCE TO RAIN OR

MOISTURE.

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE

PARTS INSIDE. REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral

triangle, is intended to alert the user to the presence of uninsulated

"dangerous voltage" within the product's enclosure that may be of

sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to

alert the user to the presence of important operating and maintenance

(servicing) instructions in the literature accompanying the appliance.

WARNING

RISK OF ELECTRIC SHOCK

DO NOT OPEN

RISQUE DE CHOC ELECTRIQUE

NE PAS OUVRIR

AVIS

ANTENNA

DISCHARGE UNIT

(NEC SECTION 810-20)

GROUNDING CONDUCTORS

(NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING

ELECTRODE SYSTEM

(NEC ART 250, PART H)

NEC NATIONAL ELECTRICAL CODE

ELECTRIC

SERVICE

EQUIPMENT

GROUND

CLAMP

ANTENNA

LEAD IN

WIRE

S2898A

21. Replacement Parts When replacement parts are required, be

sure the service technician has used replacement parts specified

by the manufacturer or have the same characteristics as the

original part. Unauthorized substitutions may result in fire,

electric shock, or other hazards.

22. Safety Check Upon completion of any service or repairs to the

appliance, ask the service technician to perform safety checks to

determine that the appliance is in proper operation condition.

23. Wall or Ceiling Mounting The appliance should be mounted

to a wall or ceiling only as recommended by the manufacturer.

24. Heat The appliance should be situated away from heat

sources such as radiators, heat registers, stoves, or other appli-

ances (including amplifiers) that produce heat.

FIGURE 1:

EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL

ELECTRICAL CODE, ANSI/NFPA 70

Precautions

1. Warranty Claim

You can find the serial number on the rear panel of this unit. In case

of warranty claim, please report this number.

2. Recording Copyright

Recording of copyrighted material for other than personal use is

illegal without permission of the copyright holder.

3. AC Fuse

The fuse is located inside the chassis and is not user-serviceable. If

power does not come on, contact your Onkyo authorized service station.

4. Care

From time to time you should wipe the front and rear panels and the

cabinet with a soft cloth. For heavier dirt, dampen a soft cloth in a

weak solution of mild detergent and water, wring it out dry, and

wipe off the dirt. Following this, dry immediately with a clean cloth.

Do not use rough material, thinners, alcohol or other chemical sol-

vents or cloths since these could damage the finish or remove the

panel lettering.

5. Power

WARNING

BEFORE PLUGGING IN THE UNIT FOR THE FIRST TIME,

READ THE FOLLOWING SECTION CAREFULLY.

The voltage of the available power supply differs according to

country or region. Be sure that the power supply voltage of the area

where this unit will be used meets the required voltage (e.g., AC

230 V, 50 Hz or AC 120 V, 60 Hz) written on the rear panel.

Worldwide models are equipped with a voltage selector to conform

to local power supplies. Be sure to set this switch to match the volt-

age of the power supply in your area before plugging in the unit.

For British model

Replacement and mounting of an AC plug on the power supply cord

of this unit should be performed only by qualified service personnel.

IMPORTANT

The wires in the mains lead are coloured in accordance with the

following code:

Blue

: Neutral

Brown : Live

As the colours of the wires in the mains lead of this apparatus may

not correspond with the coloured markings identifying the termi-

nals in your plug, proceed as follows:

The wire which is coloured blue must be connected to the terminal

which is marked with the letter N or coloured black.

The wire which is coloured brown must be connected to the termi-

nal which is marked with the letter L or coloured red.

IMPORTANT

A 5 amp fuse is fitted in this plug. Should the fuse need to be

replaced, please ensure that the replacement fuse has a rating of 5

amps and that it is approved by ASTA or BSI to BS1362. Check for

the ASTA mark or the BSI mark on the body of the fuse.

IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE

SOCKET OUTLET IN YOUR HOME THEN THE FUSE

SHOULD BE REMOVED AND THE PLUG CUT OFF AND

DISPOSED OF SAFELY. THERE IS A DANGER OF SEVERE

ELECTRICAL SHOCK IF THE CUT OFF PLUG IS INSERTED

INTO ANY 13 AMP SOCKET.

If in any doubt, please consult a qualified electrician.

For U.S. model

Note to CATV system installer:

This reminder is provided to call the CATV system installer's

attention to Article 820-40 of the NEC, ANSI/NFPA 70, which pro-

vides guidelines for proper grounding and, in particular, specifies

that the cable ground shall be connected to the grounding system of

the building, as close to the point of cable entry as practical.

FCC Information for User

CAUTION:

The user changes or modifications not expressly approved by the

party responsible for compliance could void the user's authority to

operate the equipment.

NOTE:

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or televi-

sion reception, which can be determined by turning the equipment

off and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

· Reorient or relocate the receiving antenna.

· Increase the separation between the equipment and receiver.

· Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

· Consult the dealer or an experienced radio/TV technician for help.

For Canadian model

CAUTION: THIS DIGITAL APPARATUS DOES NOT

EXCEED THE CLASS B LIMITS FOR RADIO NOISE EMIS-

SION FROM DIGITAL APPARATUS SET OUT IN THE RADIO

INTERFERENCE

REGULATIONS

THE

CANADIAN

DEPARTMENT OF COMMUNICATIONS.

For models having a power cord with a polarized plug:

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH

WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

Modele pour les Canadien

ATTENTION: L'INTERFÉRENCE RADIO ÉLECTRIQUE

GÉNÉRÉE PAR CET APPAREIL NUMÉRIQUE DE TYPE B NE

DÉPASSE PAS LES LIMITES ÉNONCÉES DANS LE RÈGLE-

MENT SUR LES PERTURBATIONS RADIO ÉLECTRIQUES,

SECTION APPAREIL NUMÉRIQUE, DU MINISTÈRE DES

COMMUNICATIONS.

Sur les modèles dont la fiche est polarisée:

ATTENTION: POUR ÉVITER LES CHOCS ÉLEC-

TRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA

FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE

ET POUSSER JUSQU'AU FOND.

Features

55 W/CH TO EACH OF THE FIVE CHANNELS

INTO 8 OHMS, 20 Hz--20 kHz, 0.08% THD (North

American models, FTC rating)

75 W/CH TO EACH OF THE FIVE CHANNELS

INTO 6 OHMS, 1 kHz, DIN (European models, DIN)

100 W/CH TO EACH OF THE FIVE CHANNELS

INTO 6 OHMS, 1 kHz, EIAJ (Asian models,EIAJ)

WIDE

RANGE

AMPLIFIER

TECHNOLOGY

(WRAT)

6-OHM,

HIGH

CURRENT,

LOW-IMPEDANCE

DRIVE FOR ALL 5 CHANNELS

DISCRETE OUTPUT STAGE AMPS FOR ALL 5

CHANNELS

2 HIGH QUALITY EXTRUDED HEAT SINKS

OVERSIZED POWER TRANSFORMER

LARGE, HIGH-QUALITY CAPACITORS

A/B SPEAKER SELECTION

DTS*

AND

DOLBY**

DIGITAL

DECODER

ONBOARD

DUAL

BANANA-PLUG

COMPATIBLE

TERMI-

NALS FOR ALL CHANNELS

96-kHz/24-BIT DAC

5.1 MULTICHANNEL INPUTS

6 DSP SOUNDFIELDS

3 ASSIGNABLE DIGITAL INPUTS (2 COAXIAL & 1

OPTICAL)

LATE NIGHT MODE

PRECISION SPEED-SENSITIVE DIGITAL VOL-

UME CONTROL

ABSOLUTE VOLUME DISPLAY

30 FM/AM RANDOM PRESETS

ALUMINUM FRONT PANEL

FULL-FUNCTION REMOTE

*Manufactured under license from Digital Theater Systems, Inc. US Pat.

No.5,451,942 and other worldwide patents issues and pending. "DTS" and

"DTS Digital Surround" are trademarks of Digital Theater Systems, Inc.©

**Manufactured under license from Dolby Laboratories.

"Dolby", "Pro Logic" and the double-D symbol

are trademarks of

Supplied accessories

Check that the following accessories are supplied with this unit.

Memory Preservation

This unit does not require memory preservation batteries. A

built-in memory power back-up system preserves the contents

of the memory during power failures and even when the unit is

unplugged. The unit must be plugged in order to charge the

back-up system.

The memory preservation period after the unit has been

unplugged varies depending on climate and placement of the

unit. On the average, memory contents are protected over a

period of a few weeks after the last time the unit has been

unplugged. This period is shorter when the unit is exposed to a

highly humid climate.

The following accessories are only available for worldwide

models.

75/300 ohm antenna

adapter

× 1

Conversion plug (Shape may

vary depending on the area

which it was purchased.)

× 1

FM indoor antenna

× 1

AM loop antenna

× 1

Remote controller (RC-427S)

× 1

Batteries (size AA or UM-3)

× 2

Declaration of Conformity

We, ONKYO EUROPE

ELECTRONICS GmbH

INDUSTRIESTRASSE 20

82110 GERMERING,

GERMANY

declare in own responsibility, that the ONKYO product described

in this instruction manual is in compliance with the corresponding

technical standards such as EN60065, EN55013, EN55020 and

EN61000-3-2, -3-3 (or EN60555-2, -3).

GERMERING, GERMANY

ONKYO EUROPE ELECTRONICS GmbH

K.OTSU

Before operating this unit

Worldwide models are equipped with a switch that controls the AM

band tuning steps. Please set this switch to match the AM band tun-

ing step frequency in your area.

U.S.A. and Canada : 10 kHz

Other areas

: 9 kHz

Worldwide models are equipped with a voltage selector to conform with

local power supplies. Be sure to set this switch to match the voltage of

the power supply in your area before plugging in the unit.

1. Determine the proper voltage for your area: 220-230 V or

120 V.

2. If the preset voltage is not correct for your area, insert a screw-

driver into the groove in the switch. Slide the switch all the way

to the right (120 V) or to the left (220-230 V), whichever is

appropriate.

1. Remove the battery compartment cover by pressing the tab and

lifting up the cover.

2. Insert two AA (R6- or UM-3)-size batteries into the battery compart-

ment. Carefully follow the polarity diagram (positive (+) and nega-

tive () symbols) inside the battery compartment.

3. After batteries are installed and seated correctly, replace the com-

partment cover.

Notes

· Do not mix new batteries with old batteries or different kinds of

batteries.

· To avoid corrosion, remove the batteries if the remote controller

is not to be used for a long time.

· Remove dead batteries immediately to avoid damage from cor-

rosion. If the remote controller doesn't operate smoothly,

replace both the batteries at the same time.

· The life of the batteries supplied is about six months but this

will vary depending on usage.

Point the remote controller toward the remote control sensor.

The STANDBY indicator lights up when the unit receives a signal

from the remote controller.

Notes

· Place the unit away from strong light such as direct sunlight or

inverted fluorescent light which can prevent proper operation of the

remote controller.

· Using another remote controller of the same type in the same

room or using the unit near equipment which uses infrared rays

may cause operational interference.

· Do not put any object such as a book on the remote controller.

The buttons of the remote controller may be pressed by mistake

and drain the batteries.

· Make sure the audio rack doors do not have colored glass. Plac-

ing the unit behind such doors may prevent proper remote con-

troller operation.

· If there is any obstacle between the remote controller and the

remote control sensor, the remote controller will not operate.

Setting the AM tuning step frequency

(Worldwide models only)

Setting the Voltage selector (Worldwide models

only)

Installing the remote controller batteries

Using the remote controller

REMOTE CONTROL

ANTENNA

GND

PHONO

(PLAY)

(REC)

OUT

MONI-

TOR

OUT

SUB

WOOFER

PRE OUT

SURROUND

FRONT

TAPE

VIDEO 1

CENTER

SUB

WOOFER

VIDEO 2

DVD

CENTER

DIGITAL INPUT

FRONT SPEAKERS

SPEAKER

CENTER

SPEAKERS

SURROUND

COAXIAL

OPTICAL

MULTI CH INPUT

OUT

TX-DS484

AC OUTLETS

SWITCHED

TOTAL 100W MAX.

AM FREQUENCY

VOLTAGE SELECTOR

220-230V

120V

STEP

10kHz

9kHz

120V

VOLTAGE SELECTOR

220-230V

AM FREQUENCY

STEP

10kHz

9kHz

TX-DS484

STANDBY indicator

Remote control sensor

30°

approx. 5 m

(16 feet)

Reviews

There are no reviews of this manual yet.

Related Products

ONKYO T-4017 Service Manual

This manual has 22 pages, file size: 1.3 MB. It's available in languages: English.

ONKYO C-705TX Owner's Manual

This manual has 24 pages, file size: 0.41 MB. It's available in languages: English.

ONKYO SKSHT150 Service Manual

This manual has 12 pages, file size: 0.38 MB. It's available in languages: English.

ONKYO A-8017 Service Manual

This manual has 13 pages, file size: 1.27 MB. It's available in languages: English.

ONKYO A8850 Service Manual

This manual has 20 pages, file size: 4.57 MB. It's available in languages: English.

ONKYO TX-DS484 Owner's Manual

Manual details

We guarantee that...

Sample pages

Reviews

Related Products

ONKYO T-4017 Service Manual

ONKYO C-705TX Owner's Manual

ONKYO SKSHT150 Service Manual

ONKYO A-8017 Service Manual

ONKYO A8850 Service Manual

Popular Brands

General

Members Area
