HT-S8230
SERVICE MANUAL
SERVICE MANUAL
5.1-CH HOME THEATER SYSTEM
Silver model
MODEL
HT-S8230(S)
120 V AC, 60 Hz
SMDD
Ref. No. 3816
082004
- - - - - HT-R8230 (AV Receiver) - - - - -
- - - - - - - - - - - - HTP-8230 (5.1-channel speaker package) - - - - - - - - - - - -
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK
ON THE
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
background image
HT-S8230
SERVICE MANUAL
SERVICE MANUAL
5.1-CH HOME THEATER SYSTEM
Silver model
MODEL
HT-S8230(S)
120 V AC, 60 Hz
SMDD
Ref. No. 3816
082004
- - - - - HT-R8230 (AV Receiver) - - - - -
- - - - - - - - - - - - HTP-8230 (5.1-channel speaker package) - - - - - - - - - - - -
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK
ON THE
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
background image
HT-S8230
PACKING PROCEDURES-1
RECEIVER SECTION
A631
A610
A601
(L & R)
<R>
Front side
Right side
marking
Front side
marking
Left side
marking
Front side
marking
A631
A656
A656
<L>
A631
A631
A611
A625
A631
A813
A801
A650
A811
A820
A821
A845
background image
HT-S8230
PACKING PROCEDURES-2
SPEAKERS SECTION
SP08
SP07
SP03
SP01
SP02
SP08
SP05
SP08
SP06
SP08
SP05
SP08
SP04
Upper side
marking
Upper side
marking
Upper side
marking
Front side
background image
HT-S8230
PACKING PROCEDURES-3
Home
Theater
S
ystem
Home
Theater
S
ystem
Sistema
De
Cine
En
Case
HT-S8230
HT-S8230
HT-S8230
Home
Theater
System
HT-S8230
L = 15 ft.
(22# 4.5 m)
(White / Black)
L = 15 ft.
(22# 4.5 m)
(Red / Black)
L = 30 ft.
(22# 9 m)
(Blue / Black)
L = 10 ft.
(22# 3 m)
(Green / Black)
SP15
SP12
SP12
SP11
L = 10 ft.
(3 m)
(Black / RCA)
Front side
Refer to "PACKING PROCEDURES-1"
Refer to "PACKING PROCEDURES-2"
L = 30 ft.
(22# 9 m)
(Gray / Black)
SP16
Front side
SP13
background image
HT-S8230
PACKING PROCEDURES PARTS LIST
RECEIVER SECTION (HT-R8230)
REF. NO.
PART NAME
DESCRIPTION
Q'TY PART NO. (SN)
MARK
PACKING
A601
PAD
(L & R)
1
29092222
PACKING
A610
POLY BAG
POLY BAG (850 x 650)
1
29100034-1A
PACKING
A611
SHEET
---
1
29095906
PACKING
A631
TAPE
NITTO NO.29 (Yellow)
(1)
29110149
PACKING
A625
POLY BAG
350 x 250
1
29100097-1A
PACKING
A650
SHEET
(SETUP)
1
29095976
PACKING
A656
LABEL
(DES), 2 sheets
1
29363933
PACKING
A801
INS MANUAL
En (HT-R8230)
1
29343866A
PACKING
A811
REMO CON
RC-479S
1
24140479
PACKING
A813
BATTERY
R6/AA (UM-3)
2
3010054
PACKING
A820
ANT COIL
NMA-3057
1
232140
PACKING
A821
FM ANT AS
D
1
292142
PACKING
A845
WRNTY CARD
(RS)
1
29365100
HT-S8230
<Note>
Parts marked by "NSP" are generally unavailable because
they are not in our Master Spare Parts List.
SPEAKERS SECTION (HTP-8230)
REF. NO.
PART NAME
DESCRIPTION
Q'TY PART NO. (SN)
MARK
PACKING
SP01
TOP POLYFOAM
W509 x H522 x T75
1
ITF830340-0001
PACKING
SP02
MIDDLE POLYFOAM
W509 x H522 x T90
1
ITF830340-0002
PACKING
SP03
BOTTOM POLYFOAM
W509 x H522 x T75
1
ITF830340-0003
PACKING
SP04
POLY BAG (SOFT BAG)
(FOR AC CORD)
1
---
NSP
PACKING
SP05
PO BAG (HM BAG)
L320 x W240 x T0.015 (FOR SKF / SKM)
4
IVA803102-0010
PACKING
SP06
PO BAG (HM BAG)
L400 x W240 x T0.015 (FOR SKC)
1
IVA803102-0011
PACKING
SP07
PO BAG (HM BAG)
L860 x W650 x T0.015 (FOR SKW)
1
IVA803101-0022
PACKING
SP08
TAPE
(SEROHAN) NITTO NO.29 (Yellow)
(1)
29110149
PACKING
SP11
CARTON BOX
HT-S8230 (S) / (HTP-8230)
1
ICC8S404S-BM10
PACKING
SP12
PP TAPE
W50
(1)
29110071 or
PACKING
SP12
PP TAPE
NITTO 3703 SUPER W50L100
(1)
29110176
PACKING
SP13
MIRAMAT SHEET
L509 x W439 x T0.5
1
IVH802004-0023
PACKING
SP15
INSTRUCTION MANUAL En ENGLISH 8 PAGE
1
YOM800001-0232
PACKING
SP16
CABLE SET
SP CABLE / RCA CABLE / POLY BAG
1
WMA8020010009
