HTP-430
SPECIFICATIONS
Type :
Input sensitivity / impedance :
Maximum output power :
Frequency response :
Cabinet capacity :
Dimensions (W x H x D) :
Weight :
Driver unit :
Power supply :
North American :
Australian :
Power consumption :
North American :
Australian :
Other :
Bass-reflex with built-in
power amplifier
220 mV / 15 k ohm
150 W
30 Hz - 150 Hz
1.15 cubic feet (32.5 L)
9-1/4" x 20-3/8" x 16-3/16"
(235 x 518 x 411 mm)
28.2 lbs. (12.8 kg)
8" (20 cm) Cone (Woofer)
AC 120 V, 60 Hz
AC 230-240 V, 50 Hz
75 W
77 W
Auto Standby function
Front Speaker (SKF-330F)
Type :
Impedance :
Maximum input power :
Output sound pressure level :
Frequency response :
Crossover frequency :
Cabinet capacity :
Dimensions (W x H x D) :
Weight :
Drivers unit :
Terminal :
Key hole slot :
Threaded insert :
Grille :
Other :
2 Way Bass-reflex
8 ohm
100 W
83 dB/W/m
80 Hz - 22 kHz
10 kHz
0.042 cubic feet (1.2 L)
5-13/16" x 7-15/16" x 4"
(148 x 202 x 101 mm)
2.0 lbs. (0.9 kg)
3-1/8" (8 cm) Cone (Woofer)
3/4" (2 cm) Ceramic (Tweeter)
Spring type color coded
1
North American model :
1/4" screw, Depth 5/16"
Other models :
5 mm screw, Depth 8 mm
Fixed
Magnetic shielding
Type :
Impedance :
Maximum input power :
Output sound pressure level :
Frequency response :
Crossover frequency :
Cabinet capacity :
Dimensions (W x H x D) :
Weight :
Drivers unit :
Terminal :
Key hole slot :
Threaded insert :
Grille :
Other :
2 Way Bass-reflex
8 ohm
100 W
86 dB/W/m
80 Hz - 22 kHz
10 kHz
0.081 cubic feet (2.3 L)
14-3/16" x 5" x 5-3/16"
(360 x 127 x 131 mm)
3.5 lbs. (1.6 kg)
3-1/8" (8 cm) Cone (Woofer) x 2
3/4" (2 cm) Ceramic (Tweeter)
Spring type color coded
2
North American model :
1/4" screw, Depth 5/16"
Other models :
5 mm screw, Depth 8 mm
Fixed
Magnetic shielding
Surround Speaker (SKM-330S / SKB-330)
Type :
Impedance :
Maximum input power :
Output sound pressure level :
Frequency response :
Crossover frequency :
Cabinet capacity :
Dimensions (W x H x D) :
Weight :
Drivers unit :
Terminal :
Key hole slot :
Threaded insert :
Grille :
2 Way Bass-reflex
8 ohm
100 W
82 dB/W/m
80 Hz - 22 kHz
10 kHz
0.042 cubic feet (1.2 L)
5-13/16" x 7-15/16" x 4"
(148 x 202 x 101 mm)
1.5 lbs. (0.7 kg)
3-1/8" (8 cm) Cone (Woofer)
3/4" (2 cm) Ceramic (Tweeter)
Spring type color coded
1
North American model :
1/4" screw, Depth 5/16"
Other models :
5 mm screw, Depth 8 mm
Fixed
Specifications and appearance are subject to change
without prior notice.
Powered Subwoofer (SKW-420)
Center Speaker (SKC-330C)
