ONKYO DXC370 Owner's Manual

Cover page of ONKYO DXC370 Owner's Manual

Owner's Manual for ONKYO DXC370, downloadable as a PDF file.

We also have service manual to this model.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 16 pages
  • File size: 0.44 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
6 DISC
FIVE CD EXCHANGE CONTINUOUS PLAY
OPEN/CLOSE
PLAY
POWER
OFF
STOP
PAUSE
REPEAT
RANDOM
DISC 1
DISC 2
DISC 3
DISC 4
DISC 5
DISC 6
NEXT SELECTION
DISPLAY
COMPACT DISC CHANGER
DX-C370
ON
MEMORY CLEAR
DISC SKIP
/
/
DISC 1
DISC 2
DISC 3
123
REPEAT
CLEAR
+10
0
DISC 4
DISC 5
DISC 6
456
789
MEMORY
NEXT SELECTION
RANDOM
DISC
INTRO SCAN
REMOTE CONTROLLER RC-331C
Compact Disc Changer
DX-C370
Instruction Manual
CONTENTS
Important Safeguards ................................... 2
Precautions .................................................. 3
Features ........................................................ 4
Supplied accessories .................................... 4
Before using this unit ................................... 5
Control positions and names ....................... 5
System Connections .................................... 7
Playing CDs ................................................. 8
Using memory functions ........................... 14
Troubleshooting Guide .............................. 16
Specifications ............................................. 16
Thank you for purchasing the Onkyo Compact Disc Changer.
Please read this manual thoroughly before making connections
and plugging in the unit.
Following the instructions in this manual will enable you to
obtain optimum performance and listening enjoyment from
your new Compact Disc Changer.
Please retain this manual for future reference.
background image
6 DISC
FIVE CD EXCHANGE CONTINUOUS PLAY
OPEN/CLOSE
PLAY
POWER
OFF
STOP
PAUSE
REPEAT
RANDOM
DISC 1
DISC 2
DISC 3
DISC 4
DISC 5
DISC 6
NEXT SELECTION
DISPLAY
COMPACT DISC CHANGER
DX-C370
ON
MEMORY CLEAR
DISC SKIP
/
/
DISC 1
DISC 2
DISC 3
123
REPEAT
CLEAR
+10
0
DISC 4
DISC 5
DISC 6
456
789
MEMORY
NEXT SELECTION
RANDOM
DISC
INTRO SCAN
REMOTE CONTROLLER RC-331C
Compact Disc Changer
DX-C370
Instruction Manual
CONTENTS
Important Safeguards ................................... 2
Precautions .................................................. 3
Features ........................................................ 4
Supplied accessories .................................... 4
Before using this unit ................................... 5
Control positions and names ....................... 5
System Connections .................................... 7
Playing CDs ................................................. 8
Using memory functions ........................... 14
Troubleshooting Guide .............................. 16
Specifications ............................................. 16
Thank you for purchasing the Onkyo Compact Disc Changer.
Please read this manual thoroughly before making connections
and plugging in the unit.
Following the instructions in this manual will enable you to
obtain optimum performance and listening enjoyment from
your new Compact Disc Changer.
Please retain this manual for future reference.
background image
2
Important Safeguards
1. Read Instructions ­ All the safety and operating instructions
should be read before the appliance is operated.
2. Retain Instructions ­ The safety and operating instructions
should be retained for future reference.
3. Heed Warnings ­ All warnings on the appliance and in the
operating instructions should be adhered to.
4. Follow Instructions ­ All operating and use instructions
should be followed.
5. Water and Moisture ­ The appliance should not be used near
water ­ for example, near a bathtub, washbowl, kitchen sink,
laundry tub, in a wet basement, or near a swimming pool, and
the like.
6. Carts and Stands ­ The appliance should be used only with a
cart or stand that is recom-
mended by the manufacturer.
6A. An appliance and cart combi-
nation should be moved with
care. Quick stops, excessive
force, and uneven surfaces may
cause the appliance and cart
combination to overturn.
7. Wall or Ceiling Mounting ­ The appliance should be mounted
to a wall or ceiling only as recommended by the manufacturer.
8. Ventilation ­ The appliance should be situated so that its loca-
tion or position does not interfere with its proper ventilation.
For example, the appliance should not be situated on a bed,
sofa, rug, or similar surface that may block the ventilation
openings; or if placed in a built-in installation, such as a book-
case or cabinet that may impede the flow of air through the
ventilation openings, there should be free space of at least 5 cm
(2 in.) and an opening behind the appliance.
9. Heat ­ The appliance should be situated away from heat
sources such as radiators, heat registers, stoves, or other appli-
ances (including amplifiers) that produce heat.
10. Power Sources ­ The appliance should be connected to a
power supply only of the type described in the operating
instructions or as marked on the appliance.
11. Polarization ­ If the appliance is provided with a polarized plug
having one blade wider than the other, please read the following
information:
The polarization of the plug is a safety feature. The polarized plug
will only fit the outlet one way. If the plug does not fit fully into the
outlet, try reversing it. If there is still trouble, the user should seek
the services of a qualified electrician. Under no circumstances
should the user attempt to defeat the polarization of the plug.
12. Power-Cord Protection ­ Power-supply cords should be
routed so that they are not likely to be walked on or pinched by
items placed upon or against them, especially near plugs, con-
venience receptacles, and the point where they exit from the
appliance.
13. Cleaning ­ The appliance should be cleaned only as recom-
mended by the manufacturer.
14. Nonuse Periods ­ The power cord of the appliance should be
unplugged from the outlet when left unused for a long period
of time.
15. Object and Liquid Entry ­ Care should be taken so that
objects do not fall and liquids are not spilled into the enclosure
through openings.
16. Damage Requiring Service ­ The appliance should be ser-
viced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged; or
B. Objects have fallen, or liquid has been spilled into the
appliance; or
C. The appliance has been exposed to rain; or
D. The appliance does not appear to operate normally or
exhibits a marked change in performance; or
E. The appliance has been dropped, or the enclosure damaged.
17. Servicing ­ The user should not attempt to service the appliance
beyond that described in the operating instructions. All other ser-
vicing should be referred to qualified service personnel.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulated
"dangerous voltage" within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC ELECTRIQUE
NE PAS OUVRIR
AVIS
PORTABLE CART WARNING
S3125A
This label on the rear panel states that:
1. This unit is a CLASS 1 LASER PRODUCT and employs a
laser inside the cabinet.
2. To prevent the laser from being exposed, do not remove the
cover. Refer servicing to qualified personnel.
"CLASS 1 LASER
PRODUCT "
This unit contains a semiconductor laser system and is classified
as a "CLASS 1 LASER PRODUCT". So, to use this model prop-
erly, read this Instruction Manual carefully. In case of any trou-
ble, please contact the store where you purchased the unit. To
prevent being exposed to the laser beam, do not try to open the
enclosure.
DANGER:
INVISIBLE LASER RADIATION WHEN OPEN AND INTER-
LOCK FAILED OR DEFEATED. AVOID DIRECT EXPOSURE
TO BEAM.
CAUTION:
THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS
OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT
IN HAZARDOUS RADIATION EXPOSURE.
background image
3
Precautions
For U.S. model
The laser is covered by a housing which prevents exposure during
operation or maintenance. However, this product is classified as a
Laser Product by CDRH (Center for Devices and Radiological
Health) which is a department of the Food and Drug Administra-
tion. According to their regulations 21 CFR section 1002.30, all
manufactures who sell Laser Products must maintain records of
written communications between the manufacturer, dealers and
customers concerning radiation safety. If you have any complaints
about instructions or explanations affecting the use of this product,
please feel free to write to the address on the back page of this
manual. When you write us, please include the model number and
serial number of your unit.
In compliance with Federal Regulations, the certification, identifi-
cation and the period of manufacture are indicated on the rear
panel.
FCC INFORMATION FOR USER
CAUTION:
The user changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to
operate the equipment.
NOTE:
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or televi-
sion reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
· Reorient or relocate the receiving antenna.
· Increase the separation between the equipment and receiver.
· Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
· Consult the dealer or an experienced radio/TV technician for help.
For Canadian model
CAUTION: THIS DIGITAL APPARATUS DOES NOT
EXCEED THE CLASS B LIMITS FOR RADIO NOISE EMIS-
SION FROM DIGITAL APPARATUS SET OUT IN THE RADIO
INTERFERENCE
REGULATIONS
OF
THE
CANADIAN
DEPARTMENT OF COMMUNICATIONS.
For models having a power cord with a polarized plug:
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH
WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
Modele pour les Canadien
ATTENTION: L'INTERFÉRENCE RADIO ÉLECTRIQUE
GÉNÉRÉE PAR CET APPAREIL NUMÉRIQUE DE TYPE B NE
DÉPASSE PAS LES LIMITES ÉNONCÉES DANS LE RÈGLE-
MENT SUR LES PERTURBATIONS RADIO ÉLECTRIQUES,
SECTION APPAREIL NUMÉRIQUE, DU MINISTÈRE DES
COMMUNICATIONS.
Sur les modèles dont la fiche est polarisée:
ATTENTION: POUR ÉVITER LES CHOCS ÉLECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE
DANS LA BORNE CORRESPONDANTE DE LA PRISE ET
POUSSER JUSQU'AU FOND.
For British model
Replacement and mounting of an AC plug on the power supply cord
of this unit should be performed only by qualified service personnel.
IMPORTANT
The wires in the mains lead are coloured in accordance with the
following code:
Blue
: Neutral
Brown : Live
As the colours of the wires in the mains lead of this apparatus may
not correspond with the coloured markings identifying the termi-
nals in your plug, proceed as follows:
The wire which is coloured blue must be connected to the terminal
which is marked with the letter N or coloured black.
The wire which is coloured brown must be connected to the termi-
nal which is marked with the letter L or coloured red.
IMPORTANT
A 5 amp fuse is fitted in this plug. Should the fuse need to be
replaced, please ensure that the replacement fuse has a rating of 5
amps and that it is approved by ASTA or BSI to BS1362. Check for
the ASTA mark or the BSI mark on the body of the fuse.
IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE
SOCKET OUTLET IN YOUR HOME, THEN THE FUSE
SHOULD BE REMOVED AND THE PLUG CUT OFF AND
DISPOSED OF SAFELY. THERE IS A DANGER OF SEVERE
ELECTRICAL SHOCK IF THE CUT OFF PLUG IS INSERTED
INTO ANY 13 AMP SOCKET.
If in any doubt, please consult a qualified electrician.
Declaration of Conformity
We, ONKYO EUROPE
ELECTRONICS GmbH
INDUSTRIESTRASSE 20
82110 GERMERING,
GERMANY
GERMERING, GERMANY
ONKYO EUROPE ELECTRONICS GmbH
K.OTSU
declare in own responsibility, that the ONKYO product described
in this instruction manual is in compliance with the corresponding
technical standards such as EN60065, EN55013, EN55020 and
EN61000-3-2, -3-3 (or EN60555-2, -3)
background image
4
Precautions
1. Warranty Claim
You can find the serial number on the rear panel of this unit. In case
of warranty claim, please report this number.
2. Power
WARNING
BEFORE PLUGGING IN THE UNIT FOR THE FIRST TIME,
READ THE FOLLOWING SECTION CAREFULLY.
The voltage of the available power supply differs according to
country or region. Be sure that the power supply voltage of the area
where this unit will be used meets the required voltage (e.g., AC
230 V, 50 Hz or AC 120 V, 60 Hz) written on the rear panel.
Worldwide models are equipped with a voltage selector to conform
to local power supplies. Be sure to set this switch to match the volt-
age of the power supply in your area before plugging in the unit.
3. Do not touch this unit with wet hands
Do not handle this unit or power cord when your hands are wet or
damp. If water or any other liquid enters the case, take this unit to
an authorized service center for inspection.
4. Location of this unit
Place this unit in a well-ventilated location.
Take special care to provide plenty of ventilation on all sides of this
unit especially when it is placed in an audio rack. If ventilation is
blocked, this unit may overheat and malfunction.
Do not expose this unit to direct sunlight or heating units as this
unit's internal temperature may rise and shorten the life of the
pickup.
Avoid damp and dusty places and places directly affected by vibra-
tions from the speakers. In particular, avoid placing the unit on or
above one of the speakers.
Be sure this unit is placed in a horizontal position. Never place it
on its side or on a slanted surface as it may malfunction.
Do not place near tuners or TV sets.
If placed next to a TV or tuner, it may cause reception interference
resulting in some noise in the TV or tuner output.
5. Care
From time to time you should wipe the front and rear panels and the
cabinet with a soft cloth. For heavier dirt, dampen a soft cloth in a
weak solution of mild detergent and water, wring it out dry, and
wipe off the dirt. Following this, dry immediately with a clean cloth.
Do not use rough material, thinners, alcohol or other chemical sol-
vents or cloths since these could damage the finish or remove the
panel lettering.
6. Points to remember
If this unit is brought from a cold environment to a warm one or is
in a cold room that is quickly heated, condensation may form on
the pickup, preventing proper operation. In this case, remove the
disc and leave the power ON for about one hour to remove the con-
densation.
When transporting this unit, be careful not to bump it.
Always close the disc tray when not loading or unloading discs to
protect delicate internal parts from dust.
Features
s
6-Disc Carousel Changer ­ only from Onkyo ­ offers
more music and convenience for the money
s
Unique design allows users to change up to 5 discs
without interrupting disc in play
s
Next Selection ­ another Onkyo exclusive ­ lets users
choose the next track/disc without interrupting the
current song playing
s
Single-Bit PWM (Pulse Width Modulation) D/A Con-
verter to minimize lowlevel linearity problems that
plague many multi-bit players ­ so there's no loss of
musical detail during quieter passages
s
ProprietaryAccuPulse Quartz System with Polysorb
virtually eliminates the possibility of timing errors in
the clock oscillator
s
8-Times Oversampling
s
Fixed Analog Output
s
Visible Display when tray is out
s
Oversized power transformer
s
6-Mode Repeat: entire disc, all discs, random tracks,
programmed tracks, random memory, single track
s
3-Mode Time Display: Single, Elapse/Remain, Total
Remain
s
Compatible Remote Control
s
Disc Intro Scan plays the first 8 seconds of each disc
s
Direct Track/Disc Access via remote
s
Optical Digital Output for direct digital connection to
DAT/Minidisc player or DSP receiver.
Playable Discs
This CD player can play back the following discs.
You cannot play back discs other than those listed above.
Avoid using heart-shaped or octagonal discs. Playing irregularly
shaped discs may damage the internal mechanism of the CD player.
Do not use discs on which adhesive from adhesive tape or a disc
label (if it is a rental disc) remains. Otherwise, you may not be able
to eject the discs or the CD player may become inoperative.
Supplied accessories
Check that the following accessories are supplied with this unit.
Memory Preservation
This unit does not require memory preservation batteries. A
built-in memory power back-up system preserves the contents
of the memory during power failures and even when the unit is
unplugged. The unit must be plugged-in in order to charge the
back-up system.
The memory preservation period after the unit has been
unplugged varies depending on climate and placement of the
unit. On the average, memory contents are protected over a
period of a few weeks after the last time the unit was
unplugged. This period is shorter when the unit is exposed to a
highly humid climate.
Disc mark
Contents
Disc size
Maximum
playback time
Audio
CDs
Audio
12 cm
74 minutes
8 cm
(CD single)
20 minutes
Remote controller RC-331C
× 1
Batteries (size AA, R6 or UM-3)
× 2
Audio connection cable
× 1
cable
× 1
background image
5
13
14
6 DISC
FIVE CD EXCHANGE CONTINUOUS PLAY
OPEN/CLOSE
PLAY
POWER
OFF
STOP
PAUSE
REPEAT
RANDOM
DISC 1
DISC 2
DISC 3
DISC 4
DISC 5
DISC 6
NEXT SELECTION
DISPLAY
COMPACT DISC CHANGER
DX-C140
ON
MEMORY CLEAR
DISC SKIP
/
/
18
17
1
23
5
7
9
4
6
10 11
8
15 16
12
19
DIGITAL
OUTPUT
OPTICAL
ANALOG
OUTPUT
COMPACT DISC PLAYER
MODEL NO.
DX - C370
2-1, NISSHIN-CHO, NEYAGAWA-SHI, OSAKA,
JAPAN
MANUFACTURED IN MALAYSIA
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING
RISQUE DE CHOC ELECTRIQUE
NE PAS OUVRIR
AVIS
®
REMOTE
CONTROL
"CLASS 1 LASER
PRODUCT"
L
R
RATING
AC120V/220-230V
50/60Hz
10W
VOLTAGE SELECTOR
120V
220-230V
220-230V
VOLTAGE SELECTOR
120V
Front panel
Display
Control positions and names
Note:
· If there is a protective film on the surface of the display that makes it difficult to read the display, remove it.
· For more information about the buttons and knobs, refer to the pages listed in the brackets ( [ ] ) below.
12. Loading drawer
13. Carousel
14. Disc trays
15. DISC SKIP buttons [8]
16. Direct play buttons
(DISC 1-DISC 6) [10, 12, 14]
17. RANDOM button [13]
18. REPEAT button [13]
19. Search/Skip buttons
(
/
,
/
) [9~12, 14, 15]
Before using this unit
Setting the voltage selector (Worldwide models only)
Worldwide models are equipped with a voltage selector to conform
with local power supplies. Be sure to set this switch to match the
voltage of the power supply in your area before plugging in the unit.
1. Determine the proper voltage for your area: 220-230 V or 120 V.
2. If the preset voltage is not correct for your area, insert a screwdriver
into the groove in the switch. Slide the switch all the way to the
right (120 V) or to the left (220-230 V), whichever is appropriate.
Display
a. PAUSE indicator
b. REPEAT indicator
c. RANDOM indicator
d. MEMORY indicator
e. Disc number indicator
f. Track number indicator
g. ELAPSED/REMAIN indicators
h. Time display
Front panel
1. POWER button [7]
2. NEXT SELECTION button [12]
3. DISPLAY button [9]
4. Remote control sensor [6]
5. Display
6. OPEN/CLOSE button [8]
7. PAUSE button [9]
8. STOP button [9, 11]
9. PLAY button [8~10, 13, 14]
10. MEMORY button [14, 15]
11. CLEAR button [15]
12
3
45
6
PAUSE REPEAT RANDOM MEMORY
NEXT
DISC No.
TRACK
SINGLE
ELAPSED
TOTAL
REMAIN
a
bcd
e
h
g
f

Reviews

There are no reviews of this manual yet.
