MARANTZ PM6010K Service Manual

Cover page of MARANTZ PM6010K Service Manual

Service Manual for MARANTZ PM6010K, downloadable as a PDF file.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 1 pages
  • File size: 0.15 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5
background image
Service
Manual
PM6010K/N1B/T1B
/N1G/T1G
R
PM6010 KI
275W855020 ACT
3120 785 22610
First Issue:2001.04
Printed in The Netherlands
PM6010
KI
PM6010
KI
Integrated Amplifier
REMARK : This service manual explains the differences between the PM6010F/
N1B/T1G/N1G/T1G (OSE version) and the PM6010K/N1B/T1G/N1G/T1G (KI
version). Only the electrical differences are listed. The mechanical parts, which
differ, are not available as spare part.
All other information is described in the service manual of the model PM6010F/
N1B/T1G/N1G/T1G (Code number : 3120 785 22009). The dispatch of the parts
for after sales service has to be referred to this service manual, with the first
priority.
For this reason, please use this service manual with referring to the model
PM6010F service manual without fail.
PM6010KI is equal to the PM6010OSE except the following electrical
changes (mechanical changes are not listed):
Position No.
Service code
Description
L001
4822 146 10788
Transformer 230V
F902
Fuse 2.5AT
C703, C704
-
Removed
C707, C708
9965 000 08133
330pF Styrene
C713, C714
9965 000 08134
10pF Styrene
C717,C718
9965 000 08135
47uF 50V Silmic
C720
4822 124 22039
220uF 16V Cerafine
C753, C754,
9965 000 08136
120pF Styrene
C755, C756
C801x, C802x
9965 000 08137
1000uF 50V Silmic
Note: These are
added in parallel
to C801/C802
C471,C472
4822 124 80119
100uF Silmic 25V
C455, C456,
4822 124 80543
10uF 35V Silmic
C467, C468
background image
Service
Manual
PM6010K/N1B/T1B
/N1G/T1G
R
PM6010 KI
275W855020 ACT
3120 785 22610
First Issue:2001.04
Printed in The Netherlands
PM6010
KI
PM6010
KI
Integrated Amplifier
REMARK : This service manual explains the differences between the PM6010F/
N1B/T1G/N1G/T1G (OSE version) and the PM6010K/N1B/T1G/N1G/T1G (KI
version). Only the electrical differences are listed. The mechanical parts, which
differ, are not available as spare part.
All other information is described in the service manual of the model PM6010F/
N1B/T1G/N1G/T1G (Code number : 3120 785 22009). The dispatch of the parts
for after sales service has to be referred to this service manual, with the first
priority.
For this reason, please use this service manual with referring to the model
PM6010F service manual without fail.
PM6010KI is equal to the PM6010OSE except the following electrical
changes (mechanical changes are not listed):
Position No.
Service code
Description
L001
4822 146 10788
Transformer 230V
F902
Fuse 2.5AT
C703, C704
-
Removed
C707, C708
9965 000 08133
330pF Styrene
C713, C714
9965 000 08134
10pF Styrene
C717,C718
9965 000 08135
47uF 50V Silmic
C720
4822 124 22039
220uF 16V Cerafine
C753, C754,
9965 000 08136
120pF Styrene
C755, C756
C801x, C802x
9965 000 08137
1000uF 50V Silmic
Note: These are
added in parallel
to C801/C802
C471,C472
4822 124 80119
100uF Silmic 25V
C455, C456,
4822 124 80543
10uF 35V Silmic
C467, C468
