LS-5070ES
B61-1271-00 00 (E) KW 0504
ENGLISH
FRANÇAIS
DEUTSCH
NEDERLANDS
IT
ALIANO
LA DICHIARAZIONE DI CONFORMITA'
"CE" DI QUESTO
PRODOTTO E' DEPOSITATA PRESSO:
KENWOOD ELECTRONICS EUROPE B.V.
AMSTERDAMSEWEG 37
1422 AC UITHOORN
THE NETHERLANDS
ESP
AÑOL
SPEAKER SYSTEM
INSTRUCTION MANUAL
SYSTEME DE ENCEINTE
MODE D'EMPLOI
SISTEMA DE ALTAVOCES
MANUAL DE INSTRUCCIONES
LAUTSPRECHERSYSTEM
BEDIENUNGSANLEITUNG
SISTEMA DIFFUSORI
ISTRUZIONI PER L'USO
LUIDSPREKERSYSTEEM
GEBRUIKSAANWIJZING
background image
LS-5070ES
B61-1271-00 00 (E) KW 0504
ENGLISH
FRANÇAIS
DEUTSCH
NEDERLANDS
IT
ALIANO
LA DICHIARAZIONE DI CONFORMITA'
"CE" DI QUESTO
PRODOTTO E' DEPOSITATA PRESSO:
KENWOOD ELECTRONICS EUROPE B.V.
AMSTERDAMSEWEG 37
1422 AC UITHOORN
THE NETHERLANDS
ESP
AÑOL
SPEAKER SYSTEM
INSTRUCTION MANUAL
SYSTEME DE ENCEINTE
MODE D'EMPLOI
SISTEMA DE ALTAVOCES
MANUAL DE INSTRUCCIONES
LAUTSPRECHERSYSTEM
BEDIENUNGSANLEITUNG
SISTEMA DIFFUSORI
ISTRUZIONI PER L'USO
LUIDSPREKERSYSTEEM
GEBRUIKSAANWIJZING
background image
ENGLISH
2 EN
LS-5070ES 1271-00_00
background image
3 EN
ENGLISH
LS-5070ES 1271-00_00
Introduction
Thank you for selecting our speakers as part of your high-fidelity
system. We at KENWOOD are confident that your choice will bring
you years of rich listening pleasure. Please take the time to read
through this booklet carefully. It will help you to obtain the peak
performance for which the speakers were designed.
For your records
Record the serial number, found on the back of the unit, in the
spaces designated on the warranty card, and in the space pro-
vided below.
Refer to these model and serial numbers whenever you call upon
your KENWOOD dealer for information or service on this product.
LS-5070ES Serial number
Installation Locations
Important Safeguards
Caution: Read this item carefully to keep your
safety.
1.
Suffocation ­ After taking the unit out of the polyethylene
bag, be sure to dispose of the polyethylene bag out of the
reach of children. Otherwise, they may play with the bag,
which could cause hazard of suffocation.
2.
Water and moisture ­ The appliance should not be used
near water - for example, near a bathtub, washbowl, kitchen
sink, laundry tub, in a wet basement, or near a swimming
pool, etc.
3.
Heat ­ Do not install the unit near a source of heat, such
as radiators, or under direct sunlight.
4.
Modification ­ Do not attempt to open or modify the unit,
for this could cause fire hazard or malfunction.
5.
Cleaning ­ Do not use volatile solvents such as alcohol,
paint thinner, gasoline, or benzine, etc. to clean the cabi-
net. Use a clean dry cloth.
6.
Abnormal smell ­ If an abnormal smell or smoke is de-
tected, immediately turn the power OFF and unplug the
appliance from the wall outlet. Contact your dealer or near-
est service center.
Left
speaker
Center speaker
Right
speaker
Right
Left
Surround speakers
Surround back
speaker
Subwoofer
Information on Disposal of Old Electrical and Electronic
Equipment (applicable for EU countries that have
adopted separate waste collection systems)
Products with the symbol (crossed-out wheeled bin)
cannot be disposed as household waste. Old elec-
trical and electronic equipment should be recycled
at a facility capable of handling these items and their
waste byproducts. Contact your local authority for
details in locating a recycle facility nearest to you.
Proper recycling and waste disposal will help con-
serve resources whilst preventing detrimental ef-
fects on our health and the environment.
Positioning For Optimal Surround Sound
Use this speaker system as the front, surround or surround
back speaker. Other speakers are to be purchased separately.
· Place the left and right speakers at each side of your TV.
Angle the speakers towards the listening area to enhance
the stereo effect.
· Place the center speaker on the center between the front
left and right speakers. Tilt the speaker upward or down-
ward so that it is directly facing the listening area.
· The subwoofer's deep-bass reproduction characteristics are
richest when the subwoofer is installed in a corner or near a
wall.
· Place the surround speakers straight to or diagonally be-
hind the left and right of the listening position.
· Place the surround back speaker behind the listining posi-
tion, at the same height as the left and right surround speak-
ers.
About Using Speakers Near a TV
This speaker include magnetic shielding and can therefore be
installed close to a TV set. Note, however, that placing the
speaker too close to a CRT type TV may in some cases pro-
duce distortion in the color reception. In such case, turn on the
TV and check that color reproduction is normal. If color is dis-
torted, turn the TV off for 15 to 30 minutes, then turn it back on
and check again. (This allows the TV's degaussing circuitry to
correct for the magnetic field from the speakers.) If distortion
is still present, move the speakers further from the TV.
background image
ENGLISH
4 EN
LS-5070ES 1271-00_00
On the Wall
This speaker system can be hung on the wall. With this installation method, the speaker should be installed upside down on the
wall. Proceed as follows.
Precautions
Please observe the following precautions when mounting the speaker onto the wall or speaker stand.
·
Be sure that the wall you are using is strong enough to support the full weight of the speaker (approx. 2.2 kg [4.9 lb] ).
·
Wall screw must be purchased separately.
·
Be sure to use a screw that is appropriate for the wall or stand you are using, and that are long enough to provide
sufficient strength.
·
If you are uncertain about the wall's support strength, the type of screw to use, or any other points regarding this
type of installation, please consult a contractor or other qualified person before proceeding.
Be sure to follow the procedure given here when carrying out installation. Kenwood can assume no liability for injury
or damage that may occur if a speaker setup falls from the wall as a result of incorrect installation or insufficient
support strength.
1 Screw a single screw into the wall at the desired
location. Screw it only part way in, so that the screw
projects 9 to 11 mm (3/8 to 7/16 inches) outward from
the wall surface.
On Floor or Shelf
Place the speakers on the floor or on a shelf or other horizontal
stable surface. Keep in mind that speakers are not fixed into
place, so be careful to avoid knocking them over.
· Attach four cushions to the base of the
speaker, one at each corner. The cush-
ions prevent the speaker from sliding,
and dampen its vibrations.
3 Each speaker has a hole for attaching the provided wall-mount bracket on the rear panel.The bracket can be attached
to the speaker using the provided screw. When attaching the bracket, be sure to observe the front and back surfaces
and attach as shown below. After attaching, place the speaker upside down and fit the hole on the bracket around the
screw attached on the wall. Confirm that the speaker is held firmly and securely in place.
2 Remove the grille and reattach it upside down.
· Attach each couple of provided cushions to make two sets of two-cushion piles,
and attach them to the two positions shown on the rear of the speaker. These
piles will protect the speaker body from damage and prevent the vibrations of
the speaker body from being transmitted to the wall.
On the speaker stand
The speaker can be installed on the SR-8000 stand optionally available from KENWOOD. Any
commercially available speaker mount or bracket can also be used (provided that the speaker
can be fixed using an M5 screw with a pitch of 60 mm and effective thread length of 7 to 10
mm). For details, read the instruction manual for the speaker mount or bracket.
Installation Methods
Bracket
Cushion
Effective thread
length
M5 screw
Screw
(Accessory)
View of attached
bracket
Cushion
9 - 11 mm (3/8 to 7/16")
· Wall screw must be purchased separately.
background image
5 EN
ENGLISH
LS-5070ES 1271-00_00
Connections
Note on connection
1.
Be sure to turn off your amplifier before connecting or disconnecting speakers.
2.
This speaker system has a nominal impedance of 8 ohms. To ensure safe and reliable operation, be sure that your
amplifier or receiver (audio video control center) is able to work with 8-ohm speaker.
·
Never short the (+) and (­) speaker wire's conductors together.
·
Do not reverse L and R or (+) and (­) connections. Reversal of sides or polarities may result in unnatural, incorrectly positioned
sound.
RL
-
+
RL
-
+
WHITE
RED
FRONT A
BLUE
GRAY
SURROUND
Speaker terminals
(Amplifier or Audio Video control center)
Wire with
white line
Left
Right
Using as Surround speakers
Using as Front speakers
Wire with
white line
Left
Right
·
When using the speaker as the surround back speaker,
connect them to the surround back speaker output
terminals.
3 Secure
1 Loosen
2 Insert the conductor
Note on operation
The speaker system's peak input power is indicated in the
specifications. To avoid speaker damage, never run the
speakers at power levels exceeding this limit.
Protection against high input level
This speaker system has the function for preventing the speaker
damage due to excessive low frequency input level. When this
function is activated, the output level of the low frequency is
reproduced temporarily.
The speaker wire can also be connected to the speaker by
using banana plugs which are commercially available in
audio stores.
To use the banana plug connection, tighten the screws on
the speaker terminals before inserting the banana plug.
