KS-3200EX
KENWOOD CORPORATION
ENGLISH
FRANÇAIS
DEUTSCH
NEDERLANDS
IT
ALIANO
ESP
AÑOL
SPEAKER SYSTEM
INSTRUCTION MANUAL
SYSTEME DE ENCEINTE
MODE D'EMPLOI
SISTEMA DE ALTAVOCES
MANUAL DE INSTRUCCIONES
LAUTSPRECHERSYSTEM
BEDIENUNGSANLEITUNG
SISTEMA DIFFUSORI
ISTRUZIONI PER L'USO
LUIDSPREKERSYSTEEM
GEBRUIKSAANWIJZING
B61-1247-00 00 (E) KW 0410
LA DICHIARAZIONE DI CONFORMITA' "CE" DI
QUESTO
PRODOTTO E' DEPOSITATA PRESSO:
KENWOOD ELECTRONICS EUROPE B.V.
AMSTERDAMSEWEG 37
1422 AC UITHOORN
THE NETHERLANDS
background image
KS-3200EX
KENWOOD CORPORATION
ENGLISH
FRANÇAIS
DEUTSCH
NEDERLANDS
IT
ALIANO
ESP
AÑOL
SPEAKER SYSTEM
INSTRUCTION MANUAL
SYSTEME DE ENCEINTE
MODE D'EMPLOI
SISTEMA DE ALTAVOCES
MANUAL DE INSTRUCCIONES
LAUTSPRECHERSYSTEM
BEDIENUNGSANLEITUNG
SISTEMA DIFFUSORI
ISTRUZIONI PER L'USO
LUIDSPREKERSYSTEEM
GEBRUIKSAANWIJZING
B61-1247-00 00 (E) KW 0410
LA DICHIARAZIONE DI CONFORMITA' "CE" DI
QUESTO
PRODOTTO E' DEPOSITATA PRESSO:
KENWOOD ELECTRONICS EUROPE B.V.
AMSTERDAMSEWEG 37
1422 AC UITHOORN
THE NETHERLANDS
background image
ENGLISH
2 EN
background image
3 EN
ENGLISH
Introduction
Thank you for selecting our speakers as part of your high-fidelity system. We at KENWOOD are confident that your choice will bring you
years of rich listening pleasure. Please take the time to read through this booklet carefully. It will help you to obtain the peak performance
for which the speakers were designed.
For your records
Record the serial number, found on the back of the unit, in the spaces designated on the warranty card, and in the space provided below.
Refer to these model and serial numbers whenever you call upon your KENWOOD dealer for information or service on this product.
KS-3200EX Serial number
Important Safeguards
Caution: Read this item carefully to keep your safety.
4.
Modification ­ Do not attempt to open or modify the unit,
for this could cause fire hazard or malfunction.
5.
Cleaning ­ Do not use volatile solvents such as alcohol,
paint thinner, gasoline, or benzine, etc. to clean the cabi-
net. Use a clean dry cloth.
6.
Abnormal smell ­ If an abnormal smell or smoke is de-
tected, immediately turn the power OFF and unplug the
appliance from the wall outlet. Contact your dealer or near-
est service center.
1.
Suffocation ­ After taking the unit out of the polyethylene
bag, be sure to dispose of the polyethylene bag out of the
reach of children. Otherwise, they may play with the bag,
which could cause hazard of suffocation.
2.
Water and moisture ­ The appliance should not be used
near water - for example, near a bathtub, washbowl, kitchen
sink, laundry tub, in a wet basement, or near a swimming
pool, etc.
3.
Heat ­ Do not install the unit near a source of heat, such
as radiators, or under direct sunlight.
Installation
Positioning For Optimal Surround Sound
Place this speaker system as Surround back speaker, it can
provide full Surround sound. To enjoy the full effect of the Sur-
round sound field, please position the speakers as described
below.
· Place the left and right speakers at each side of your TV.
Angle the speakers towards the listening area to enhance
the stereo effect.
· Place the center speaker on the center between the front
left and right speakers. Tilt the speaker upward or down-
ward so that it is directly facing the listening area.
· Place the surround speakers as high as possible, either
directly to the sides of the listening area or else slightly
behind the listening area. Adjust the angles so that these
speakers are facing directly towards the listeners.
· Place the surround back speaker behind the listining posi-
tion, at the same height as the left and right surround speak-
ers.
Left
speaker
Center
speaker
Right
speaker
Surround speakers
Right
Left
Surround back speaker
background image
ENGLISH
4 EN
Installation Methods
On the Desktop or Shelf
Place the speaker on the desktop, shelf or a similar level surface.
On the Wall
The speaker include mount holes for wall mounting.
1.
Screw a single screw into the wall at the desired loca-
tion. Screw it only part way in, so that the screw
projects 8 to 10 mm (5/16 to 3/8 inches) outward from
the wall surface.
2.
Hang the speaker by fitting the top mount hole (at the
upper rear of the speaker) over the extending part of
the screw. Confirm that the speaker is held firmly and
securely in place.
On the speaker stand
The speaker can be installed on the SR-8000 stand optionally available from KENWOOD.
Attaching the cushions
Attach cushions to the base of the speaker as shown be-
low. The cushions prevent the speaker from sliding, and
dampen its vibrations.
Precautions
Please observe the following precautions when mounting speaker onto the wall.
· Be sure that the wall you are using is strong enough to support the full weight of the speaker (approx. 0.6 kg [1.3 lb]).
· Wall screws must be purchased separately. Be sure to use screws that are appropriate for the wall you are using, and that
are long enough to provide sufficient strength.
· If you are uncertain about the wall's support strength, the type of screw to use, or any other points regarding this type of
installation, please consult a contractor or other qualified person before proceeding.
Be sure to follow the procedure given here when carrying out installation. Kenwood can assume no liability for injury
or damage that may occur if a speaker setup falls from the wall as a result of incorrect installation or insufficient
support strength.
8 - 10 mm
(5/16 - 3/8")
background image
5 EN
ENGLISH
SUB
SUB
WOOFER
WOOFER
SURR
SURR
CENTER
CENTER SURR BACK
SURR BACK
/SW
/SW
SPEAKERS
SPEAKERS
FRONT
FRONT
(­)
(+)
Red
Center speaker
(+)
Gray
(+)
Blue
Speaker terminals
(Amplifier or receiver)
(+)
Green
(+)
White
Connections
The speaker wires and labels of speakers' back panel are color-coded to facilitate connection. Connect each wire to the matching-
colored terminal, as shown in the figure.
Be sure to turn off your amplifier before connecting or disconnecting speakers.
1. The speaker system's peak input power is indicated in the specifications. To avoid speaker damage, never run the
speakers at power levels exceeding this limit.
2. This speaker system has a nominal impedance of 8 ohms. To ensure safe and reliable operation, be sure that your
amplifier or receiver is able to work with 8-ohm speakers.
·
Never short the (+) and (­) speaker wires together.
·
Do not reverse L and R or (+) and (­) connections. Reversal of sides or polarities may result in unnatural, incorrectly positioned
sound.
Subwoofer (option)
(­)
(­)
(­)
(­)
1. Twist wire's
conductor
4. Release
3. Insert the
conductor
2. Push
Surround back
speaker
Front speakers
Left
Right
Left
Right
(+)
Brown
(­)
Surround speakers
