background image
KDV-S250P
DVD PLAYER
INSTRUCTION MANUAL
LECTEUR DE DVD
MODE D'EMPLOI
DVD-Player
BEDIENUNGSANLEITUNG
DVD-SPELER
GEBRUIKSAANWIJZING
LETTORE DVD
ISTRUZIONI PER L'USO
REPRODUCTOR-DVD
MANUAL DE INSTRUCCIONES
LEITOR DE DVD
MANUAL DE INSTRUÇÕES
© B64-4405-08/00 (K/E)
Take the time to read through this instruction manual.
Familiarity with installation and operation procedures will help
you obtain the best performance from your new DVD player.
For your records
Record the serial number, found on the back of the unit, in the spaces
designated on the warranty card, and in the space provided below.
Refer to the model and serial numbers whenever you call upon your
Kenwood dealer for information or service on the product.
Model KDV-S250P Serial number
background image
KDV-S250P
DVD PLAYER
INSTRUCTION MANUAL
LECTEUR DE DVD
MODE D'EMPLOI
DVD-Player
BEDIENUNGSANLEITUNG
DVD-SPELER
GEBRUIKSAANWIJZING
LETTORE DVD
ISTRUZIONI PER L'USO
REPRODUCTOR-DVD
MANUAL DE INSTRUCCIONES
LEITOR DE DVD
MANUAL DE INSTRUÇÕES
© B64-4405-08/00 (K/E)
Take the time to read through this instruction manual.
Familiarity with installation and operation procedures will help
you obtain the best performance from your new DVD player.
For your records
Record the serial number, found on the back of the unit, in the spaces
designated on the warranty card, and in the space provided below.
Refer to the model and serial numbers whenever you call upon your
Kenwood dealer for information or service on the product.
Model KDV-S250P Serial number
background image
2 | KDV-S250P
Contents
Safety precautions
3
Notes
4
Common features
8
Power
Play
Mute
Skip
Fast Forward and Reverse
Repeat Play
A-B Repeat Play
Random Play
Program Play
Switching Display
DVD Video/Video CD/Video file/Picture
file features
12
Search Play
DVD menu/Top (title) menu
Audio Language select
Subtitle Language select
Picture Angle select
Zoom
PBC
Slow Motion play
Frame-by-frame playback
Slide show
Picture Rotation
CD/Audio file features
15
Direct Skip Play
Play Time Search
Search Play
Setup menu
16
Setup menu
DISC menu
VIDEO menu
AUDIO menu
DISPLAY
OTHER
Accessories
19
Installation
20
Connecting Wires to Terminals
21
Troubleshooting Guide
22
Specifications
23
US Residence Only
Register Online
Register your Kenwood product at www.Kenwoodusa.com
background image
English
|
3
Safety precautions
Lens Fogging
Right after you turn on the car heater in cold weather,
dew or condensation may form on the lens in the CD
player of the unit. Called lens fogging, CDs may be
impossible to play. In such a situation, remove the disc
and wait for the condensation to evaporate. If the unit
still does not operate normally after a while, consult
your Kenwood dealer.
Cleaning the Unit
If the faceplate of this unit is stained, wipe it with a
dry soft cloth such as a silicon cloth.
If the faceplate is stained badly, wipe the stain off with
a cloth moistened with neutral cleaner, then wipe
neutral detergent off.
¤
· Applying spray cleaner directly to the unit may affect its
mechanical parts. Wiping the faceplate with a hard cloth or
using a volatile liquid such as thinner or alcohol may scratch
the surface or erases characters.
2WARNING
To prevent injury or fire, take the following
precautions:
· The unit is a model that can be only installed in a
vehicle. Do not use it in your home.
· Be sure to use the supplied power cable to get
a power supply. Use of a cable other than the
provided cable will cause a fire.
· To prevent a short circuit, never put or leave any
metallic objects (such as coins or metal tools) inside
the unit.
· Do not watch or fix your eyes on the unit's display
when you are driving for any extended period.
· Mounting and wiring this product requires skills and
experience. For safety's sake, leave the mounting
and wiring work to professionals.
· Do not connect the unit to the front monitor. This
unit is for rear seat entertainment.
2CAUTION
To prevent damage to the machine, take
the following precautions:
· Make sure to ground the unit to a negative 12V DC
power supply.
· Do not install the unit in a spot exposed to direct
sunlight or excessive heat or humidity. Also avoid
places with too much dust or the possibility of
water splashing.
· When replacing a fuse, only use a new fuse with
the prescribed rating. Using a fuse with the wrong
rating may cause your unit to malfunction.
· Use only the screws provided or specified for
installation. If you use wrong screws, you could
damage the unit.
NOTE
· If you experience problems during installation,
consult your Kenwood dealer.
· The illustrations of the display and the panel
appearing in this manual are examples used to
explain more clearly how the controls are used.
Therefore, what appears on the display in the
illustrations may differ from what appears on the
display on the actual equipment, and some of the
illustrations on the display may be inapplicable.
background image
4 | KDV-S250P
Region codes in the world
DVD disc marks
Symbol
Description
ALL
Indicates a region number. The discs with this mark can
be played with any DVD player.
8
Indicates the number of audio languages recorded. Up
to 8 languages can be recorded in a movie. You can
select a favorite language.
32
Indicates the number of subtitled languages recorded.
Up to 32 languages can be recorded.
9
If a DVD disc has scenes shot from multiple angles, you
can select a favorite angle.
16:9 LB
Indicates the type of screen for the image. The left mark
indicates that a wide image picture (16:9) is displayed
on a standard TV set screen (4:3) with a black band at
both the top and bottom of the screen (letter box).
Notes
1
2
4
1
5
4
5
2
1
2
6
3
Restrictions due to difference between
discs
Inhibition
icon
Some DVD and VCD discs can be played
only in certain playback modes according
to the intentions of the software
producers. As this player plays discs
according to their intentions, some
functions may not work as intended by
you. Please be sure to read the instructions provided
with each disc. When an inhibition icon is displayed
on the monitor, it indicates that the disc being played
is under the restriction as described above.
Use of "DualDisc"
When playing a "DualDisc" on this unit, the surface of
the disc that is not played may be scratched while the
disc is inserted or ejected. Since the music CD surface
does not conform to the CD standard, playback may
be impossible.
(A "DualDisc" is a disc with one surface containing
DVD standard signals and the other surface
containing music CD signals.)
About the usable temperatures
The protective circuit in the unit activates when the
temperature inside the DVD player exceeds 60°C
(140°F). Refer to <Troubleshooting Guide> (page 22).
background image
English
|
5
List of playable discs
Disc
types
Standard
Support
Remark
DVD
DVD Video
DVD Audio
×
DVD-R
MP3/WMA/AAC/JPEG/DivX
Playback
Multi-border/Multisession
(Playback depends on
authoring conditions)
Video mode supported
VR mode supported (Only
DVD-R/RW/R DL)
DVD-RW
DVD+R
DVD+RW
DVD-R DL (Dual layer)
DVD+R DL (Double layer)
DVD-RAM
×
CD
Music CD
CD-TEXT/8-cm (3 inch)
discs supported.
CD-ROM
MP3/WMA/AAC/JPEG/DivX
playback
Multisession supported
Packet write not supported.
CD-R
CD-RW
DTS-CD
Video CD (VCD)
Super video CD
×
Picture CD
CD-EXTRA
%
Only music CD session can
be played.
HDCD
%
Sound quality of normal
CD music
CCCD
×
Others
Dualdisc
×
Super audio CD
%
Only CD layer can be played.
: Playback is possible.
% : Playback is partly possible.
× : Playback is impossible.
/
· When buying DRM enabled contents, check the
Registration Code in the <REGISTRATION> (page 18).
Registration Code changes each time a file with the
displayed Registration Code is played to protect against
copying.
About the functions by playback source
In this manual, functions that can be used with
various playback sources are indicated as follows:
[DVD]:
Function of during DVD playback only.
[VCD]:
Function of during Video CD playback only.
[CD]:
Function of during CD playback only.
[AUDIO]: Function of during Audio file playback only.
[DivX]:
Function of during Video file playback only.
[PIC]:
Function of during JPEG/Picture CD
playback only.
Handling discs
· Do not touch the recording surface of the disc.
· Do not stick tape etc. on the disc, or use a disc with
tape stuck on it.
· Do not use disc type accessories.
· Clean from the center of the disc and move
outward.
· When removing discs from this unit, pull them out
horizontally.
· If the disc center hole or outside rim has burrs,
use the disc only after removing the burrs with a
ballpoint pen etc.
Discs that cannot be used
· Discs that are not round cannot be used.
· Discs with coloring on the recording surface or discs
that are dirty cannot be used.
· This unit can only play the CDs with
.
This unit may not correctly play discs which do not
have the mark.
· You cannot play a disc that has not been finalized.
(For the finalization process refer to your disc writing
software, and your disc recorder instruction manual.)
