1 SPECIFICATIONS
2
Media type ............CD-RW and CD-R for Digital audio (record and
playback), CD (playback only)
Frequency converter input sampling frequency ........32kHz~48kHz
Recording sampling frequency ..........................................44.1kHz
Frequency response ....................................................20Hz~20kHz
(playback:±1.5dB, recording:±1.5dB)
Signal to noise ratio ............................More than 92dB (playback)
More than 86dB (recording)
Dynamic range ....................................More than 92dB (playback)
More than 86dB (recording)
Total Harmonic Distortion ..................Less than 0.01% (playback)
Less than 0.02% (recording)
Wow & flutter ..........................................................Unmeasurable
Audio Input Sensitivity/Impedance ........LINE : -6dBV (0.5V)/20k
Output Level/Impedance ..........................LINE : -6dBV (0.5V)/1k
Maximum output level ....................................LINE :+6dBV (2.0V)
Power supply........120/230 V AC, 50/60Hz (General export model)
230 V AC, 50Hz (Europe model)
Power consumption ..............................................................20 W
Dimensions (W x H x D) ................................435 x 102 x 320 mm
(17-1/8" x 4" x 12-4/8")
Weight (Net) ......................................................5.1kg (11-3/16 lb)
Standard Accessories..................Audio signal connection cord x 1
Remote control unit x 1
Improvements may result in specification or feature changes
without notice.
SAFETY INFORMATION
This product has been designed and manufactured according to FDA regulations
"title 21, CFR, chapter 1, subchapter J, based on the Radiation Control for Health
and Safety Act of 1968", and is classified as a class 1 laser product. There is no
hazardous invisible laser radiation during operation because invisible laser radiation
emitted inside of this product is completely confined in the protective housings.
The label required in this regulation is shown 1.
OCAUTION
USE OF CONTROLS OR ADJUSTMENT OR PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
Optical pickup:
Material
: Ga-Al-As
Wavelength
: 765 - 815nm (25
) (Play)
780 - 786nm (25
) (Record)
Laser output : Continuous wave max. 5mW (Play)
Continuous wave max. 40mW (Record)
1 For U.S.A.
