Compact Disc Changer
DX-C34
Instruction Manual
Thank you for purchasing an Onkyo Compact Disc
Changer.
Please read this manual thoroughly before making
connections and turning on the power.
Following the instructions in this manual will enable
you to obtain optimum performance and listening
enjoyment from your new Compact Disc Changer.
Please retain this manual for future reference.
Getting Started
2
Connection
11
Basic Operation
14
Advanced Operation
20
Others
25
background image
En
Compact Disc Changer
DX-C34
Instruction Manual
Thank you for purchasing an Onkyo Compact Disc
Changer.
Please read this manual thoroughly before making
connections and turning on the power.
Following the instructions in this manual will enable
you to obtain optimum performance and listening
enjoyment from your new Compact Disc Changer.
Please retain this manual for future reference.
Getting Started
2
Connection
11
Basic Operation
14
Advanced Operation
20
Others
25
background image
2
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer's instructions.
8. Do not install near any heat sources such as radia-
tors, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong are pro-
vided for your safety. If the provided plug does not
fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience recepta-
cles, and the point where they exit from the appara-
tus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand,
tripod, bracket, or table spec-
ified by the manufacturer, or
sold
with
the
apparatus.
When a cart is used, use cau-
tion when moving the cart/
apparatus
combination
to
avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or
when unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
15. Damage Requiring Service
Unplug the apparatus from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:
A. When the power-supply cord or plug is damaged,
B. If liquid has been spilled, or objects have fallen
into the apparatus,
C. If the apparatus has been exposed to rain or
water,
D. If the apparatus does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions as an improper adjustment of other
controls may result in damage and will often
require extensive work by a qualified technician
to restore the apparatus to its normal operation,
E. If the apparatus has been dropped or damaged in
any way, and
F. When the apparatus exhibits a distinct change in
performance this indicates a need for service.
16. Object and Liquid Entry
Never push objects of any kind into the apparatus
through openings as they may touch dangerous volt-
age points or short-out parts that could result in a
fire or electric shock.
The apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids, such as
vases shall be placed on the apparatus.
Don't put candles or other burning objects on top of
this unit.
17. Batteries
Always consider the environmental issues and fol-
low local regulations when disposing of batteries.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPARATUS
TO RAIN OR MOISTURE.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING
TO
QUALIFIED
SERVICE
PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated "dangerous voltage" within
the product's enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC ELECTRIQUE
NE PAS
OUVRIR
AVIS
PORTABLE CART WARNING
S3125A
background image
3
Introduction
· 6-disc CD changer
· MP3 playback
· Multi-bit D/A converter
· 128-times oversampling
· VLSC (Vector Linear Shaping Circuitry)
· Direct Digital Path
· Change up to 5 discs without stopping playback
· Cue up the next track or disc with the Next
Selection function
· Repeat playbacks: All Discs, Entire Disc, Ran-
dom Tracks, Memory Tracks, Random Memory,
Single Folder, Single Track
· 40-track memory playback
· Optical and coaxial digital audio outputs
· Analog outputs
·
compatible remote control
Make sure you have the following accessories:
* In catalogs and on packaging, the letter added to the end of
the product name indicates the color of the DX-C34. Spec-
ifications and operation are the same regardless of color.
DX-C34 Features
Supplied Accessories
RCA/phono audio connecting cable
cable
Cable used for system connections to an Onkyo compo-
nent with an
jack.
(The components will not function as a system with
only
connections. Be sure to connect the audio con-
nection cables correctly as well.)
Remote controller (RC-547C) and two (AA/R6)
batteries
Power cord
Rack Mount Instruction Manual
background image
4
Precautions
1. Recording Copyright
Unless it's for personal use only, recording copy-
righted material is illegal without the permission of
the copyright holder.
2. AC Fuse
The AC fuse inside the DX-C34 is not user-service-
able. If you cannot turn on the DX-C34, contact your
Onkyo dealer.
3. Care
Occasionally you should dust the DX-C34 all over
with a soft cloth. For stubborn stains, use a soft cloth
dampened with a weak solution of mild detergent
and water. Dry the DX-C34 immediately afterwards
with a clean cloth. Don't use abrasive cloths, thin-
ners, alcohol, or other chemical solvents, because
they may damage the finish or remove the panel let-
tering.
4. Power
WARNING
BEFORE PLUGGING IN THE UNIT FOR THE
FIRST TIME, READ THE FOLLOWING SEC-
TION CAREFULLY.
AC outlet voltages vary from country to country.
Make sure that the voltage in your area meets the
voltage requirements printed on the DX-C34's rear
panel (i.e., AC 120 V, 60 Hz).
Setting the [STANDBY/ON] switch to STANDBY
does not fully shutdown the DX-C34. If you do not
intend to use the DX-C34 for an extended period,
remove the power cord from the AC outlet.
5. Never Touch This Unit with Wet Hands
Never handle this unit or its power cord while your
hands are wet or damp. If water or any other liquid
gets inside this unit, have it checked by your Onkyo
dealer.
6. Installing This Unit
· Install this unit in a well-ventilated location.
· Ensure that there's adequate ventilation all around
this unit, especially if it's installed in an audio
rack. If the ventilation is inadequate, the unit may
overheat, leading to malfunction.
· Do not expose this unit to direct sunlight or heat
sources, because its internal temperature may rise,
shortening the life of the optical pickup.
·Avoid damp and dusty places, and places subject
to vibrations from loudspeakers. Never put the
unit on top of, or directly above a loudspeaker.
· Install this unit horizontally. Never use it on its
side or on a sloping surface, because it may cause
a malfunction.
· If you install this unit near a TV, radio, or VCR,
the sound quality may be affected. If this occurs,
move this unit away from the TV, radio, or VCR.
7. Moisture Condensation
Moisture condensation may damage this unit.
Read the following carefully:
When you take a glass containing a cold drink out-
side on a summer's day, drops of water, called con-
densation, form on the outside of the glass.
Similarly, moisture may condense on the lens of the
optical pickup, one of the most important parts
inside this unit.
· Moisture condensation can occur in the following
situations:
-- The unit is moved from a cold place to a warm
place.
--A heater is turned on, or cold air from an air
conditioner is hitting the unit.
-- In the summer, when this unit is moved from
an air conditioned room to a hot and humid
place.
-- The unit is used in a humid place.
· Do not use this unit when there's the possibility of
moisture condensation occurring. Doing so may
damage your discs and certain parts inside this
unit.
If condensation does occur, remove all discs and
leave this unit turned on for two to three hours. By
this time, the unit will have warmed up and any con-
densation will have evaporated. To reduce the risk of
condensation, keep this unit connected to a wall out-
let.
For U.S. model
The laser is covered by a housing which prevents expo-
sure during operation or maintenance. However, this
product is classified as a Laser Product by CDRH (Cen-
ter for Devices and Radiological Health) which is a
department of the Food and Drug Administration.
According to their regulations 21 CFR section 1002.30,
all manufactures who sell Laser Products must maintain
records of written communications between the manu-
facturer, dealers and customers concerning radiation
safety. If you have any complaints about instructions or
explanations affecting the use of this product, please feel
free to write to the address on the back page of this man-
ual. When you write us, please include the model num-
ber and serial number of your unit.
In compliance with Federal Regulations, the certifica-
tion, identification and the period of manufacture are
indicated on the rear panel.
FCC INFORMATION FOR USER
CAUTION:
The user changes or modifications not expressly
approved by the party responsible for compliance could
void the user's authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules.
These limits are designed to provide reasonable protec-
tion against harmful interference in a residential installa-
tion. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a partic-
ular installation.
background image
5
Precautions--Continued
If this equipment does cause harmful interference to
radio or television reception, which can be determined
by turning the equipment off and on, the user is encour-
aged to try to correct the interference by one or more of
the following measures:
· Reorient or relocate the receiving antenna.
· Increase the separation between the equipment and
receiver.
· Connect the equipment into an outlet on a circuit dif-
ferent from
· that to which the receiver is connected.
· Consult the dealer or an experienced radio/TV techni-
cian for help.
For Canadian model
NOTE: This Class B digital apparatus complies with
Canadian ICES-003.
For models having a power cord with a polarized plug:
CAUTION: TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
Modèle pour les Canadien
REMARQUE: Cet appareil numérique de la classe B
est conforme à la norme NMB-003 du Canada.
Sur les modèles dont la fiche est polarisee:
ATTENTION: POUR ÉVITER LES CHOCS ÉLEC-
TRIQUES, INTRODUIRE LA LAME LA PLUS
LARGE DE LA FICHE DANS LA BORNE CORRE-
SPONDANTE DE LA PRISE ET POUSSER
JUSQU'AU FOND.
Table of Contents
Getting Started
Controls & Connectors ........................ 6
Front Panel ..........................................................6
Display ................................................................7
Rear Panel ...........................................................8
Remote Controller ...............................................9
Before Using the DX-C34 ................... 10
Installing the Remote Controller's Batteries.....10
Using the Remote Controller ............................10
Connections
Connecting the DX-C34 ..................... 11
Audio Connections............................................11
Connections ................................................12
Controlling AV Components that are Out of
Range.............................................................13
Basic Operation
Turning On the DX-C34 ...................... 14
Turning On the DX-C34 ...................................14
Basic Playback ................................... 14
Loading Discs....................................................14
Starting Playback ..............................................15
Selecting Discs ..................................................15
Loading Discs During Playback........................15
Adjusting the Display Brightness......................15
Basic Operation .................................................16
Selecting MP3s..................................................17
Selecting Tracks by Number .............................18
Selecting MP3 Folders & Tracks by Number ...18
Displaying Information .....................................19
Advanced Operation
Advanced Playback............................ 20
Cuing Up the Next Track, Folder, or Disc ........20
Playing All Discs Repeatedly............................21
Playing One Track, Folder,
or Disc Repeatedly ........................................21
Using Random Playback ...................................21
Using Memory Playback...................................22
MP3 Preferences ................................ 24
Setting the MP3 Preferences .............................24
Initializing the MP3 Preferences .......................24
Others
Troubleshooting ................................. 25
Disc Notes ........................................... 26
Specifications ..................................... 27
This unit contains a semiconductor laser system and is
classified as a "CLASS 1 LASER PRODUCT." So, to
use this model properly, read this Instruction Manual
carefully. In case of any trouble, please contact the
store where you purchased the unit. To prevent expo-
sure to the laser beam, do not try to open the enclosure.
DANGER:
VISIBLE AND INVISIBLE LASER RADIATION
WHEN OPEN AND INTERLOCK FAILED OR
DEFEATED. DO NOT STARE INTO BEAM.
CAUTION:
THIS PRODUCT UTILIZES A LASER. USE OF
CONTROLS OR ADJUSTMENTS OR PERFOR-
MANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
1. This unit is a CLASS 1 LASER PRODUCT and
employs a laser inside the cabinet.
2. To prevent the laser from being exposed, do not
remove the cover. Refer servicing to qualified per-
sonnel.

Reviews

There are no reviews of this manual yet.
