background image
Remote
Control
Remote Control Instruction Manual
Quick start guide ................................................ 1
Getting the most from your remote control ................. 3
Setup code chart ................................................ 4
In case of difficulty ............................................. 5
Remote operation of other components ..................... 6
Remote Control Instruction Manual
Preset Remote Control Quick Start Guide
This quick start guide explains how to setup the remote
control to operate audio and video components other
than the receiver.
In order to make full use of the functions of the remote
control, be sure to read the section of this manual
entitled "Getting the most from your remote control".
It contains a detailed explanation of how to operate the
remote control and make the necessary settings.
The quick start guide describes the operation of the
following keys:
1 POWER key
During pressing this key, you can enter the code numbers
that let you control your components.
2 Numeric keys
During pressing the
POWER key, use these keys to enter
the code numbers that let you control your components.
3 Source POWER (TV, VCR/CDR, DVD) keys
Once you have entered the setup code for another
component, you can press these keys to turn power to
that component on or off. This lets you confirm that you
entered the code properly.
This instruction manual is for some models.
Model availability and features (functions) may differ depending on the
country and sales area.
B60-4624-00 (EN)
1
B.BOOST
DISC SKIP
DVD
PHONO
CD/DVD
TUNER
MD/TAPE
VIDEO1
VIDEO2
VIDEO3
AV AUX
23
POWER
POWER
VCR/CDR
TV
DVD
DISPLAY
PTY
RETURN
OSD
MENU
P.CALL
TUNING
MUTE
VOLUME
A/B+100
TITLE
RECEIVER
AUTO
INPUT SEL.
TV SEL.
CHANNEL
ENTER
BAND
P.CALL
MULTI CONTROL
45
6
78
9
0
+10
LSTN.M
SET UP
SOUND
CDR
CD
RC-R0610
background image
Remote
Control
Remote Control Instruction Manual
Quick start guide ................................................ 1
Getting the most from your remote control ................. 3
Setup code chart ................................................ 4
In case of difficulty ............................................. 5
Remote operation of other components ..................... 6
Remote Control Instruction Manual
Preset Remote Control Quick Start Guide
This quick start guide explains how to setup the remote
control to operate audio and video components other
than the receiver.
In order to make full use of the functions of the remote
control, be sure to read the section of this manual
entitled "Getting the most from your remote control".
It contains a detailed explanation of how to operate the
remote control and make the necessary settings.
The quick start guide describes the operation of the
following keys:
1 POWER key
During pressing this key, you can enter the code numbers
that let you control your components.
2 Numeric keys
During pressing the
POWER key, use these keys to enter
the code numbers that let you control your components.
3 Source POWER (TV, VCR/CDR, DVD) keys
Once you have entered the setup code for another
component, you can press these keys to turn power to
that component on or off. This lets you confirm that you
entered the code properly.
This instruction manual is for some models.
Model availability and features (functions) may differ depending on the
country and sales area.
B60-4624-00 (EN)
1
B.BOOST
DISC SKIP
DVD
PHONO
CD/DVD
TUNER
MD/TAPE
VIDEO1
VIDEO2
VIDEO3
AV AUX
23
POWER
POWER
VCR/CDR
TV
DVD
DISPLAY
PTY
RETURN
OSD
MENU
P.CALL
TUNING
MUTE
VOLUME
A/B+100
TITLE
RECEIVER
AUTO
INPUT SEL.
TV SEL.
CHANNEL
ENTER
BAND
P.CALL
MULTI CONTROL
45
6
78
9
0
+10
LSTN.M
SET UP
SOUND
CDR
CD
RC-R0610
background image
2
Remote
Control
Register the setup codes for your audio and video components
Step 1
Look up the setup code for the component you want
to control.
RC4
Write down
all the applicable setup codes.
(This step is very important.)
Step 2
Hold down
POWER key and press
the numeric keys to enter the 3-digit
setup code for the component.
Proceed to the next step within 15
seconds.
If the component does not respond when you try to
control it, return to step 2 and enter the next setup
code on the list. Repeat this procedure until you find
the code that matches the component.
Repeat steps
2 and 3 to enter the codes for each compo-
nent you want to control.
If you accidentally exit the registration mode by pressing the
wrong key, you will not lose any setup codes you have
already saved.
Quick Start Guide
12
3
45
6
78
9
0
+10
POWER
Step 3
Press the
source POWER (TV,
VCR/CDR, DVD) key for more than
2 seconds to select the input you
registered.
Make sure if you can turn the com-
ponent on and off. (If the compo-
nent you want to control has a me-
chanical power key that cannot be
operated by remote control, press
the
6 key or the TUNING 1/
¡ key to test it.)
POWER
VCR/CDR
TV
DVD
background image
3
Remote
Control
Input
Component
Maker
Code
Key
(DVD)
DVD player
KENWOOD 804,805,808
DVD
The remote control supplied with this receiver is also
capable of controlling components from a variety of manu-
facturers once you register the appropriate setup codes
into the remote control unit.
Refer to "Remote operation of other components" for de-
tails about the operations available for each component.
1
Registering setup codes for other components
Find the setup code of the component to be registered.
Getting the most from your remote control
· Refer to the setup code lists to find the setup code for the component
to be registered.
RC4
Example: To register a DVD made by KENWOOD, you would enter
"805".
2 Hold down the POWER key and press the numeric keys to
enter the setup code.
Low battery warning
Replace all four batteries with new ones when you notice a shortening
of the distance from which the remote control will operate. The remote
control is designed to retain setup codes in memory while you change
batteries.
Press the source POWER (TV, VCR/CDR, DVD) key for
more than 2 seconds, and check to see that the compo-
nent you want to control turns on.
· Example: Press "805" to register a DVD player made by KENWOOD.
· If you push an invalid key, the remote will exit the setup mode.
If the component does not react, and there is more than one
setup code, enter another setup code and try again.
·
6, TUNING 1/¡, or MULTI CONTROL key(s) can also be used
instead of the
POWER key.
· If the component is already on, pressing the
source POWER keys will
turn it off.
3
Repeat steps
2 to 3 to register additional components
until all components have been registered.
4
Note
Although each setup code is designed to work with a number of different
models, certain codes may not work with some models. (Also, certain
codes may only operate some of the functions available on a given
model.)
This operation lets you operate the registered components.
KENWOOD audio components with system control turn on and off
automatically with the receiver via the system control connections.
Operating other components
Use the input selector keys to select the component you
desire.
Note
Be sure to point the remote control at the remote sensor on the receiver
when you want to operate KENWOOD components connected by
system control cords. Otherwise, point the remote control at the compo-
nent you want to operate.
· See "Remote operation of other components" for a list of keys
available with each component.
RC6
The remote control mode returns to the receiver operation mode
when you do not operate for more than 15 seconds.
1
2
3 Press the operation keys you desire.
· Pressing the input selector keys also changes the input selector on
the receiver.
·
When you operate your registered TV, VCR, CDR, or DVD
player, go to step
2.
·
When you operate the CD player, Cassette deck, MD player, or
Tuner with system control connection, go to step
3.
· To return to the receiver operation mode, press the
RECEIVER key.
Press the source POWER key.
POWER
Source
POWER
keys
Numeric keys
POWER
RECEIVER
Source
POWER
keys
background image
4
Remote
Control
Maker
Setup codes
BLAUPANKT
401
GRUNDIG
402
MIVER
401
NOKIA
403
NORDMENDE
404, 405
PHILIPS
406
SABA
404, 407
SCHNEIDER
408
TELEFUNKEN
407, 409, 410
THOMSON
411
AKAI
408
FENNER
412
FISHER
413
HITACHI
414, 415
INNO-HIT
416
IRRADIO
408
JVC
417
MAGNAVOX
406
OKANO
416
ORION
418
PANASONIC
419, 420
SAMSUNG
421
SANYO
413
SHARP
422
SONY
423, 424, 425,
426, 427
TOSHIBA
428
Setup code chart
TV Setup codes
Maker
Setup codes
BLAUPANKT
501
GRUNDIG
502
LOEWE
503, 504
NOKIA
505
NORDMENDE
506, 507, 508
PHILIPS
509
SABA
510
SIEMENS
502
TELEFUNKEN
511, 512
AIWA
513
BELL+HOWELL
514
CGM
514, 515
DIGTAL
515
FISHER
514
G.E.
516
HITACHI
517, 518
JVC
519
MAGNAVOX
501, 515
MITUBISHI
520, 521, 522,
523
PANASONIC
524
PHONOLA
515
SAMSUNG
525, 526
SANYO
514
SHARP
527, 528
SONY
529, 530, 531
TOSHIBA
532
VCR Setup codes
Maker
Setup codes
JVC
801
SONY
802
PIONEER
803
PANASONIC
804
KENWOOD
804, 805, 808
TOSHIBA
806
PHILIPS
807
DVD Setup codes
Maker
Setup codes
KENWOOD
533
PHILIPS
533
PIONEER
534
CDR Setup codes
background image
5
Remote
Control
Remote control unit
Cause
· No setup codes registered at for the respective
input(s).
· The remote control is set to a different operation
mode.
· Batteries are exhausted.
· The remote control unit is too far away from the
main system, controlling angle is too large, or
there is an obstacle between the receiver and
the remote.
· The audio cords and system control cords are
not connected properly.
· No software is loaded in the source component.
· An attempt is made to play a tape which is being
recorded in the cassette deck.
· The remote control has not been set to the
operation mode for the component you wish to
control.
· The microprocessor of the remote control mal-
functions.
Remedy
· Register a setup code at the respective input(s).
RC3
· Press the source select keys or source
POWER
keys to select the appropriate operation mode.
· Replace with new batteries.
· Operate the remote control unit within the con-
trollable range.
· Connect properly referring to "Setting up the
system".
· Place software in the source component you
want to play.
· Wait until recording has completed.
· Press the source select keys or source
POWER
keys to activate the operation mode for the
component you want to control before opera-
tion.
RC3
· Reset the microprocessor.
Symptom
Certain inputs cannot be selected using the
remote control.
Remote control operation is not possible.
In case of difficulty

Reviews

There are no reviews of this manual yet.
