KENWOOD KDC-7024 Owner's Manual

Cover page of KENWOOD KDC-7024 Owner's Manual

Owner's Manual for KENWOOD KDC-7024, downloadable as a PDF file.

We also have service manual to this model.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 52 pages
  • File size: 1.04 MB
  • Available language versions: Croatian, Czech, Italian, Hungarian, Portuguese, Polish, Swedish, French, English, Russian, Spanish, Dutch, German, Finnish
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
KDC-M7024
KDC-7024
© B64-2468-00/01 (EV/E2V)
CD-RECEIVER
INSTRUCTION MANUAL
COMPACT
DIGITAL AUDIO
KDC-M7024(EV) Cover_r2
03.1.8
3:42 PM
Page 1
background image
KDC-M7024
KDC-7024
© B64-2468-00/01 (EV/E2V)
CD-RECEIVER
INSTRUCTION MANUAL
COMPACT
DIGITAL AUDIO
KDC-M7024(EV) Cover_r2
03.1.8
3:42 PM
Page 1
background image
-- 2 --
English
Contents
Safety precautions.............................3
About GSM Hands Free Unit .............5
Notes on playing MP3 .......................6
Notes on Multi-function
Key System.....................................8
About CDs..........................................9
General features ..............................10
Power
Selecting the Source
Volume
Attenuator
System Q
Audio Control
Speaker Setting
Display Mode Switching
Text Display Switching
External Display Switching
Auxiliary Input Display Setting
Non-fading Output
Panel Position Setting
Theft Deterrent Panel
Hiding the Control Panel
TEL Mute
Dual Zone System
Tuner features..................................20
Tuning
Station Preset Memory
Auto Memory Entry
Preset Tuning
RDS features ....................................22
Traffic Information
Radio Text Scroll
PTY (Program Type)
Program Type preset
Changing Language for PTY Function
CD/MP3/External disc control
features.........................................25
Playing CD & MP3
Playing External Disc
Fast Forwarding and Reversing
Track/File Search
Disc/ Folder Search
Track/File/Disc/Folder Repeat
Scan Play
Random Play
Magazine Random Play
Folder Select
Disc Naming (DNPS)
Text/Title Scroll
GSM Hands Free Unit control
features.........................................31
Receiving a call
Phone Book Search
Direct Dial
SMS (Short Message Service) Mode
Phone Book/ Message (SMS) data synchronize
Menu system....................................34
Menu System
Security Code
Phone voice speaker setting
Microphone sensitivity adjust
Auto Response time Adjust
Touch Sensor Tone
Manual Clock Adjustment
Synchronize Clock
DSI (Disabled System Indicator)
Selectable Illumination
Contrast Adjustment
Dimmer
OFF Wait Time Setting
Eject angle setting
System Q Setting
Switching preout
Built-in Amp Mute Setting
B.M.S. (Bass Management System)
B.M.S. Frequency Offset
News Bulletin with Timeout Setting
Local Seek
Tuning Mode
Auto Memory Entry
AF (Alternative Frequency)
Restricting RDS Region
Auto TP Seek
Monaural Reception
Text Scroll
Power OFF Timer
CD Read Setting
Accessories ......................................42
Installation Procedure .....................42
Connecting Wires to Terminals .......43
Installtion .........................................44
Removing the Unit...........................45
Locking the Backpanel to the unit .46
Troubleshooting Guide ....................47
Specifications ..................................51
KDC-M7024_U.S
02.12.11
3:02 PM
Page 2
background image
-- 3 --
To prevent injury and/or fire, take the
following precautions:
· Insert the unit all the way until it is fully
locked in place. Otherwise it may fly out of
place during collisions and other jolts.
· When extending the ignition, battery, or
ground wires, make sure to use automotive-
grade wires or other wires with a 0.75mm2
(AWG18) or more to prevent wire
deterioration and damage to the wire
coating.
·To prevent short circuits, never put or leave
any metallic objects (e.g., coins or metal
tools) inside the unit.
·If the unit starts to emit smoke or strange
smells, turn off the power immediately and
consult your Kenwood dealer.
· Make sure not to get your fingers caught
between the faceplate and the unit.
· Be careful not to drop the unit or subject it to
strong shock.
The unit may break or crack because it
contains glass parts.
· Do not touch the liquid crystal fluid if the
LCD is damaged or broken due to shock. The
liquid crystal fluid may be dangerous to your
health or even fatal.
If the liquid crystal fluid from the LCD
contacts your body or clothing, wash it off
with soap immediately.
2WARNING
To prevent damage to the machine,
take the following precautions:
· Make sure to ground the unit to a negative
12V DC power supply.
· Do not open the top or bottom covers of the
unit.
· Do not install the unit in a spot exposed to
direct sunlight or excessive heat or humidity.
Also avoid places with too much dust or the
possibility of water splashing.
· Do not subject the faceplate to excessive
shock, as it is a piece of precision
equipment.
· When replacing a fuse, only use a new one
with the prescribed rating. Using a fuse with
the wrong rating may cause your unit to
malfunction.
·To prevent short circuits when replacing a
fuse, first disconnect the wiring harness.
· Do not place any object between the
faceplate and the unit.
· During installation, do not use any screws
except for the ones provided. The use of
improper screws might result in damage to
the main unit.
· Do not apply excessive force to the moving
faceplate. Doing so will cause damage or
malfunction.
· Do not apply excessive force to the open
faceplate or place objects on it. Doing so will
cause damage or breakdown.
2CAUTION
IMPORTANT INFORMATION
About CD players/disc changers
connected to this unit
KENWOOD disc changers/ CD players
released in 1998 or later can be connected to
this unit.
Refer to the catalog or consult your Kenwood
dealer for connectable models of disc
changers/ CD players.
Note that any KENWOOD disc changers/ CD
players released in 1997 or earlier and disc
changers made by other makers cannot be
connected to this unit.
Unsupported connection may result in
damage.
Setting the "O-N" Switch to the "N" position for
the applicable KENWOOD disc changers/ CD
players.
The functions that can be used and the
information that can be displayed will differ
depending on the models being connected.
You can damage both your unit and the CD
changer if you connect them incorrectly.
Do Not Load 3-in. CDs in the CD slot
If you try to load a 3 in. CD with its adapter
into the unit, the adapter might separate from
the CD and damage the unit.
Safety precautions
KDC-M7024_U.S
02.12.11
3:02 PM
Page 3
background image
-- 4 --
English
· If you experience problems during
installation, consult your Kenwood dealer.
· If the unit fails to operate properly, press the
Reset button. The unit returns to factory
settings when the Reset button is pressed.
If the unit still fails to operate properly after
the Reset button has been pressed, contact
your local KENWOOD dealer for assistance.
·Press the reset button if the Disc auto
changer fails to operate correctly. Normal
operation should be restored.
· Characters in the LCD may become difficult
to read in temperatures below 41 °F (5 °C).
NOTE
· The illustrations of the display and the panel
appearing in this manual are examples used
to explain more clearly how the controls are
used. Therefore, what appears on the display
in the illustrations may differ from what
appears on the display on the actual
equipment, and some of the illustrations on
the display may represent something
impossible in actual operation.
Lens Fogging
Right after you turn on the car heater in cold
weather, dew or condensation may form on
the lens in the CD player of the unit. Called
lens fogging, CDs may be impossible to play.
In such a situation, remove the disc and wait
for the condensation to evaporate. If the unit
still does not operate normally after a while,
consult your Kenwood dealer.
Safety precautions
Cleaning the Faceplate Terminals
If the terminals on the unit or faceplate get
dirty, wipe them with a dry, soft cloth.
Cleaning the Unit
If the faceplate of this unit is stained, wipe it
with a dry soft cloth such as a silicon cloth.
If the faceplate is stained badly, wipe the stain
off with a cloth moistened with neutral
cleaner, then wipe neutral detergent off.
Applying spray cleaner directly to the unit may
affect its mechanical parts. Wiping the
faceplate with a hard cloth or using a volatile
liquid such as thinner or alcohol may scratch
the surface or erases characters.
Cleaning the CD Slot
As dust can accumulate in the CD slot, clean it
occasionally. Your CDs can get scratched if
you put them in a dusty CD slot.
·We strongly recommend the use of the
<Security Code> (page 34) to prevent theft.
NAME.S
NF
RTN
NEXT
DAB
Reset button
KDC-M7024_U.S
02.12.11
3:02 PM
Page 4
background image
-- 5 --
About GSM Hands Free Unit
The marking of products using lasers
(Except for some areas)
The label is attached to the chassis/case and
says that the component uses laser beams
that have been classified as Class 1. It means
that the unit is utilizing laser beams that are of
a weaker class. There is no danger of
hazardous radiation outside the unit.
CLASS 1
LASER PRODUCT
Refer to the GSM Hands Free Unit control
features of this manual for the operation
method of GSM Hands Free Unit KCA-HF521
(optional accessory) when connected.
KDC-M7024_U.S
02.12.11
3:02 PM
Page 5
